Summary of Contents for Alcatel-Lucent OmniStack 6200
- Page 1 Alcatel-Lucent OmniStack 6200 Stackable LAN Switches...
- Page 2 Every OmniStack 6200 switch comes with two 10/100/1000 copper ports that can be used with standard Ethernet cabling for fault-tolerant dedicated stacking links or as Gigabit ports in a standalone configuration. They also come with two additional Gigabit combo ports that provide ports for upstream connectivity to the network or to high-speed servers.
- Page 3 The 24 SFP ports accept industry standard 100Base-X optical transceivers. The OmniStack 6200 family uses a modular external backup power solution that provides redundant chassis and PoE power on a 1:1 basis. The OmniStack 6200 family complements the existing portfolio of Alcatel-Lucent...
- Page 4 6850 families of switches. Cost effective, enterprise workgroup switch The OmniStack 6200 family offers small, medium or large enterprise networks a cost-effective and secure means of deploying PoE on every port, providing users mobility across the campus. By providing wire-speed QoS and security to the edge, Alcatel-Lucent is able to ensure a highly available network for important applications such as IP voice communications.
- Page 5 21st century applications at a tremendous value. The OmniStack 6200 is a great alternative when L3 routing or Gigabit speed is not needed on every port. Alcatel-Lucent | Alcatel-Lucent OmniStack 6200...
- Page 6 Alcatel-Lucent | Alcatel-Lucent OmniStack 6200 Simplified manageability Dual image and multiple configuration file storage provides backup Industry standard CLI with a familiar interface reduces training costs Easy-to-use point-and-click web based element manager with built-in help for easy configuration of new technology features...
- Page 7 A l c a t e l - L u c e n t OmniStack 6200 Stacking ports Alcatel-Lucent OmniStack 6200: Two 10/100/1000 copper RJ-45 ports. Alcatel- Lucent OmniStack 6200 supports a fault tolerant looped stacking configuration. In a standalone configuration, these ports can be used as normal network ports. Combo ports...
- Page 8 EN55022 Class A FCC Class A, VCCI Class A Safety CSA/NRTL (UL60950, CSA 22.2.No 60950-00) Alcatel-Lucent | Alcatel-Lucent OmniStack 6200 OS 6212P: 3.0 kg, 6.61 lbs OS 6248: 4.1 kg, 9.01 lbs -40 to 70 degree C (Non-operation) Vibration: IEC 68-2-36, IEC 68-2-6...
- Page 9 WEEE - Waste Electrical and Electronic Equipment Number of power supplies OmniStack 6200 family supports one internal AC power supply for chassis power and an external connector on rear of chassis for use with the backup power supply solution Input voltage & current ratings OS-LS-6212: Input, AC 100~240V 50Hz~60Hz.
-
Page 10: Product Description
Ships with chassis connection cable and country specific power cord. OS-LS-6200 modular AC backup power supply. Provides backup power to one OS-LS-6200 PoE capable switch. Ships with chassis connection cable and country specific power cord. OS LS-6200 modular DC backup power supply. Provides backup power to one non-PoE OmniStack 6200 switch. - Page 11 SFP-GIG-LH70 SFP-GIG-LH40 SFP-GIG-LX SFP-GIG-SX Alcatel-Lucent OmniStack 6200 Service and Support SupportBasic One year 7x24 phone support, includes eService web access and free software releases SupportPlus One year 7x24 phone support, includes eService web access, free software releases and next business day arrival of replacement hardware SupportTotal (Available only in N.
- Page 12 IP Networking Infrastructure Alcatel, Lucent, Alcatel-Lucent and Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information present- ed is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccu- racies contained herein. ©...
