8 Technical data

8.1 FEM classification

1/1 2/1 4/1 6/1
2/2-1 4/2-1
500 1000 2000
630 1250 2500
800 1600 3200
1000 2000 4000
1250 2500 5000
1600 3200 6300
2000 4000 8000
2500 5000 10000
3200 6300 12500
4000 8000 16000
5000 10000 20000
6300 12500 25000
8000 16000 32000 50000
10000 20000 40000 63000
12500 25000 50000 80000

8.2 Conditions of use

58
Classification of mechanism, rope drive and motor in acc. with FEM for SH
Type FEM 9.661
8/1
SH 3005-25 3m
SH 3005-40
SH 3006-25 2m
SH 3006-40
SH 3008-20 2m
SH 3006-32
SH 4010-25 2m
SH 4010-40
SH 4012-20 2m
SH 4012-32
SH 4016-16 1Am
SH 4016-25
SH 5020-25 2m
SH 5020-40
SH 5025-20 2m
SH 5025-32
SH 5032-16 1Am
SH 5032-25
SHR 6040-12 1Am
SHR 6040-20
SHR 6040-32
SH 6050-16 2m
SH 6050-25
SH 6063-12 1Am
SH 6063-20
63000
80000
100000
The hoist is designed for use in industry and for the ambient conditions usual in
industry in non-hazardous areas.
Special measures must be taken for particular applications such as e.g. high degree
of chemical pollution, outdoor use, offshore application, etc.
The manufacturer will be pleased to advise you.
Protection against dust and moisture to EN 60 529
IP 55
Permissible ambient temperatures
-20°C ... +40°C (standard)
-20°C ... +60°C (option
-5°C ... +80°C (option)
-40°C ... +40°C (off-standard design)
