① Install star cap to project patterns, and take off star cap to be a single
dot laser.
② On/Off button.
③ Mind the battery type and direction.
l
Green laser: 1x16340 batteries. Positive side face to the button.
l
Red laser and Violet laser: 1x16340 batteries. Positive side face to the
spring.
Technical Specs
Name
Size
Laser Class
Laser Type
Wavelength
Output Power
Beam Divergence
Beam Diameter At Aperture
Laser Body
Laser Finish
facebook @ laserpointerstore
JD 851 Laser Pointer Manual
1.5mm At Aperture
<13mm at 10 meters
www.laserpointerstore.com
JD 851 Laser Pointer
13*2*2 cm
Class 3
Direct Diode
532nm green
<40mw
2.4mRad
Aircraft-Grade Aluminum
Black
650nm red
200mw
1.2mRad
4mm At Aperture
<8mm at 10 meters
Made in China
Advertisement
Related Manuals for laserpointerstore JD 851
Summary of Contents for laserpointerstore JD 851
- Page 1 532nm green 650nm red Output Power <40mw 200mw Beam Divergence 2.4mRad 1.2mRad 1.5mm At Aperture 4mm At Aperture Beam Diameter At Aperture <13mm at 10 meters <8mm at 10 meters Laser Body Aircraft-Grade Aluminum Laser Finish Black www.laserpointerstore.com facebook @ laserpointerstore Made in China...
- Page 2 2. Don’t light up over 2 minutes each time, totally cool down before you use it again, if or, it may be damaged by overheated. 3. Keep away from children, don’t direct to eyes. User is responsible for any improper using way. www.laserpointerstore.com facebook @ laserpointerstore Made in China...
