Rikaline E-705 User Manual

Rikaline gps receiver user's guide e-705
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rikaline
E-705

GPS Receiver

User's Guide
Oct. 06, 2002
Rikaline
Marketing Corp.
4F-11, 26, Tai Yuen St., Chu Pei, Hsin Chu, Taiwan
Phone: +886-3-552-6001 Fax: +886-3-552-6002
E-Mail: info@rikaline.com.tw Web: www.rikaline.com.tw
All Right Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-705 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rikaline E-705

Summary of Contents for Rikaline E-705

  • Page 1: Gps Receiver

    Rikaline E-705 GPS Receiver User’s Guide Oct. 06, 2002 Rikaline Marketing Corp. 4F-11, 26, Tai Yuen St., Chu Pei, Hsin Chu, Taiwan Phone: +886-3-552-6001 Fax: +886-3-552-6002 E-Mail: info@rikaline.com.tw Web: www.rikaline.com.tw All Right Reserved...

  • Page 2: Table Of Contents

    5. Software Interface …………………………………………………………………………….… 5.1 NMEA Transmitted Sentences 6. Ordering Information 6.1 Product Options 6.2 Accessories ……………………………………………………………………………………………… 7. Warranty Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 TABLE OF CONTENTS ……………………………………………………………….. ……………………………………………………………….… …..……………………………………………………………….…… ……………………………………………………..…………….. ……………………………………………………..…...

  • Page 3: Introduction

    It communicates with other electronic utilities via compatible RS-232. With low power consumption, the E-705 tracks up to 12 satellites at a time, re-acquires satellite signals in 100 ms and updates position data every second. The fast time-to-first-fix (TTFF) allows the unit operates with low power consumption.
  • Page 4 3) NMEA 0183 Version 2.2 ASCII output : GPGGA, GPGSA, GPGSV, GPRMC). 1.3.5 Coordinates System 1) WGS84. Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 meters / second (1000 knots) max 5F-1, 125, Roosevelt Road, Sec. 5, Taipei, Taiwan 116 E-Mail: info@rikaline.com.tw...

  • Page 5: Operational Characteristics

    4) Error estimates 5) Satellite and receiver status The E-705 will perform 3D navigation when 4 or more satellites are tracked. When 3 or fewer satellites are tracked, altitude-hold is enabled using the last computed altitude and 2D navigation mode is entered.

  • Page 6: Hardware Interface

    46.0(W) x 31.0 (D) x 15.6(H) (mm) 1.81"(W) x 1.22"(D) x 0.61"(H). 3.2 Hardware Interface The E-705 includes an antenna in a unique style water resistance gadget. Simply connect PS-2 female connector to your notebook PC, PDA or other devices. 3.3 Connector Standard cable: 2 meters with COM port and male PS-2 connectors.
  • Page 7 3.4.1.2 PS2 composite connector function definition (to PC): 3.4.2 A-6012 Cigarette adapter and PDA connector: Part No. A-6017-A A-6017-B A-6012-H A-6017-L A-6017-M A-6017-N Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 Application Part No. ASUA A-6012-P BESTA I-WINNA A-6012-Q HP Jornada...
  • Page 8 3.4.4 A-6014 High power connector 3.4.5 A-6016 Cigarette Adapter Input power: 12-26VDC Cable Length: 2 meter core type Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 5F-1, 125, Roosevelt Road, Sec. 5, Taipei, Taiwan 116 E-Mail: info@rikaline.com.tw...

  • Page 9: Usb Driver

    4.2 Installation 1. Copy entire <E-705 USB> folder from CD to hard disk. 2. Connect E-705 USB connector to computer. While the computer automatically starts the installation program, please direct the driver to the <E-705 USB> folder. 3. After the installation is complete, go to <Device Manager> and select <Ports (COM & LPT)> to verify if a virtual COM port <USB to Serial Port>...

  • Page 10: Software Interface

    5. Software Interface The E-705 interface protocol is based on the National Marine Electronics Association's NMEA 0183 ASCⅡ interface specification, which is defined in NMEA 0183, Version 2.2. 5.1 NMEA Transmitted Messages The E-705 outputs data in NMEA-0183 format as defined by the National Marine Electronics Association (NMEA), Standard.
  • Page 11 Value Fix Not Available 5.1.4 GNSS Satellites in View (GSV) Table 5-8 contains the values for the following example: $GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71 Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 Units GLL protocol header ddmm.mmmm N=north or S=south dddmm.mmmm...
  • Page 12 Example Message ID $GPVTG Course 309.62 Reference Course Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 Units GSV protocol header Range 1 to 3 Range 1 to 3 Range 1 to 12 Channel 1 (Range 1 to 32)
  • Page 13 114523.62 Month Year 2001 Local Zone Hours Local Zone Minutes Checksum <CR> <LF> Rikaline Marketing Corp. Tel: ++886 2 2934 5456 Fax: ++886 2 2934 4373 Magnetic (1) Knots Measured horizontal speed Knots Km/hr Measured horizontal speed Kilometers per hour...

  • Page 14: Ordering Information

    7. Warranty The E-705 is warranted to be free from defects in material and functions for one year from the date of purchase. Any failure of this product within this period under normal conditions will be replaced at no charge to the customers.
