Your screwdriver has been engineered and manufactured to our high standards for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
9.6 VOLT PIVOTING SCREWDRIVER
VARIABLE SPEED/REVERSIBLE
R81030
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R81030 and is the answer not in the manual?

Questions and answers

Related Manuals for RIDGID R81030

Summary of Contents for RIDGID R81030

  • Page 1 When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE OPERATOR’S MANUAL 9.6 VOLT PIVOTING SCREWDRIVER...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS n Introduction ...2 n General Safety Rules ... 3-4 n Specific Safety Rules...4 n Safety Rules for Charger ...5 n Symbols... 6-7 n Features... 8-9 n Assembly ...9 n Operation ... 10-15 n Maintenance ...16 n Warranty ...17 n Customer Service Information...18 INTRODUCTION This tool has many features for making its use more pleasant and enjoyable.

  • Page 3: General Safety Rules

    Use battery only with charger listed. MODEL BATTERY PACK R81030 130252007 PERSONAL SAFETY n Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES n Use the power tool, accessories and tool bits etc., in accordance with these instructions and in the manner intended for the particular type of power tool, taking into account the working conditions and the work to be performed.

  • Page 5: Safety Rules For Charger

    SAFETY RULES FOR CHARGER WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. n Before using battery charger, read all instructions and cautionary markings in this manual, on battery charger, battery, and product using battery to prevent misuse of the products and possible injury or damage.

  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current...
  • Page 7 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL DANGER: WARNING: CAUTION: CAUTION: SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we suggest you return the product to the nearest AUTHORIZED SERVICE CENTER for repair.

  • Page 8: Product Specifications

    FEATURES PRODUCT SPECIFICATIONS Motor ...9.6 Volt DC Switch...Variable Speed No Load Speed ... 0-530/min. Coupler... 1/4 in. Hex TORQUE ADJUSTMENT RING COUPLER SCREWDRIVER BIT Charger Input ... 120 V, 60 Hz, AC only Charge Rate ...20 min. Torque... Maximum 100 in.lb. VIEW OF SCREWDRIVER IN PISTOL POSITION SWITCH TRIGGER STICK/PISTOL...

  • Page 9: Assembly

    FEATURES KNOW YOUR SCREWDRIVER See Figure 1. Before attempting to use this product, familiarize yourself with all operating features and safety rules. DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE/CENTER LOCK) Your screwdriver has a direction of rotation (forward/reverse/ center lock) selector located above the switch trigger for changing the direction of bit rotation.

  • Page 10: Operation

    OPERATION WARNING: Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating tools. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury.
  • Page 11 OPERATION LED FUNCTION OF CHARGER See Figure 3. INDICATOR Power Evaluate Evaluate Evaluate Evaluate Charging Full POWER INDICATOR EVALUATE INDICATOR CHARGING INDICATOR FULL INDICATOR BATTERY PACK Without battery pack Hot battery pack Flashing Cold battery pack Flashing Deeply discharged Flashing Thermistor shorted Flashing or open...

  • Page 12: Variable Speed

    OPERATION TO INSTALL BATTERY PACK See Figure 4. n Place the battery pack in the screwdriver, aligning raised rib on battery pack with groove in the tool’s battery port. n Make sure the latches on each side of the battery pack snap into place and the battery pack is secured to the screwdriver before beginning operation.

  • Page 13: Adjusting Torque

    OPERATION DIRECTION OF ROTATION SELECTOR See Figure 6. The direction of bit rotation is reversible and is controlled by a selector located above the switch trigger. With the screwdriver held in normal operating position, the direction of rotation selector should be positioned to the left of the switch trigger for driving.

  • Page 14: Installing Bits

    OPERATION STICK/PISTOL POSITION See Figures 8 - 9. The screwdriver has been designed so that it can be used as a stick screwdriver or a pistol screwdriver. A pivot locking button is located on the side of the screwdriver. To place the screwdriver in stick position: Hold in normal operating position, slide pivot locking button down and twist front housing fully to the right.

  • Page 15: Using The Screwdriver

    OPERATION REMOVING BITS See Figure 10. n Lock the switch trigger by placing the direction of rotation selector in the center position. n Remove the battery pack from the screwdriver. n Pull the coupler away from the screwdriver. n Remove screwdriver bit from the coupler. WARNING: Do not drive a screw where there is likely to be hidden wiring behind the surface.

  • Page 16: Maintenance

    Only the parts shown on the parts list are intended to be repaired or replaced by the customer. All other parts should be replaced at a RIDGID authorized service center. BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING...

  • Page 17: Warranty

    2/1/04 and after. This product is manufactured by One World Technologies, Inc. The trademark is licensed from RIDGID, Inc. All warranty communications should be directed to One World Technologies, Inc., attn: RIDGID Hand Held and Stationary Power Tool Technical Service at (toll free) 1-866-539-1710.

  • Page 18: Customer Service Information

    R81030 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
