Dynojet Power Commander V Installation Manual page 3

FIG.A
Remove
FIG.B
Remove
FIG.C
Remove
Remove
Remove
16-044 www.powercommander.com
Remove
Remove
Remove
Remove
1 Remove the side panels directly below the seat on both sides of the bike.
2 Remove the rear engine covers on both sides.
3 Remove the passenger grip handles on both sides of the seat.
4 Remove the seat (Fig. A).
5 Remove the upper dash panel that has the speaker grills (Fig. B).
6 Remove both of the long thin plastic panels on the outer edges of the lower
dash panel.
7 Remove both of the glove compartments on both sides and the small panels
directly below the glove compartments (Fig. B).
2009-2013 Honda Goldwing/FB6 - PCV - 3
