Your reciprocating saw has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
RECIPROCATING SAW
VARIABLE SPEED
R3001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R3001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIDGID R3001

Summary of Contents for RIDGID R3001

  • Page 1 When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE OPERATOR’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS n General Safety Rules... 3-4 n Specific Safety Rules ...4 n Symbols ... 5-6 n Electrical...7 n Features...8 n Assembly...9 n Operation... 9-12 n Maintenance... 12-13 n Warranty ...15 n Customer Service Information ...16 INTRODUCTION This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate.

  • Page 3: Electrical Safety

    GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS WORK AREA n Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERVICE n Tool service must be performed only by qualified re- pair personnel. Service or maintenance performed by unqualified personnel may result in a risk of injury. SPECIFIC SAFETY RULES n Hold power tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord.

  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current...

  • Page 6: Save These Instructions

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL DANGER: WARNING: CAUTION: CAUTION: SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we suggest you return the product to your nearest AUTHORIZED SERVICE CENTER for repair.

  • Page 7: Electrical Connection

    ELECTRICAL DOUBLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded.

  • Page 8: Product Specifications

    FEATURES PRODUCT SPECIFICATIONS Input ... 120 V, 60 Hz, AC Only, 11.0 Amps Switch... Variable Speed No Load Speed ... 0-2,800/min. Stroke Length... 1-1/8 in. Net Weight...8.4 lbs. INSULATED GRIPPING BASE (SHOE) ASSEMBLY SAW BLADE KNOW YOUR RECIPROCATING SAW See Figure 1. Before attempting to use this product, familiarize yourself with all operating features and safety rules.

  • Page 9: Assembly

    ASSEMBLY UNPACKING This product has been shipped completely assembled. n Carefully remove the tool and any accessories from the box. Make sure that all items listed in the packing list are included. n Inspect the tool carefully to make sure no breakage or damage occurred during shipping.

  • Page 10: Base Assembly

    OPERATION TO INSTALL BLADE See Figure 2. n Unplug the saw. WARNING: The tool should never be connected to a power supply when you are assembling parts, making adjustments, cleaning, performing maintenance, or when the tool is not in use. Disconnecting the tool will prevent accidental starting that could cause serious injury.

  • Page 11: General Cutting

    OPERATION WARNING: Cutting into electrical wiring in walls can cause metal surfaces of the saw to become electrically live. Do not touch metal parts when cutting into a wall; grasp only the insulated gripping surfaces provided on the tool. Make sure hidden electrical wiring, water pipes, and mechanical hazards are not in the blade path when cutting into a wall.

  • Page 12: General Maintenance

    MAINTENANCE WARNING: When servicing use only identical RIDGID replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust.

  • Page 13: Brush Replacement

    MAINTENANCE BRUSH REPLACEMENT See Figure 8. NOTE: The reciprocating saw is equipped with externally accessible brushes. n Unplug the saw. WARNING: Failure to unplug the tool could result in accidental starting causing possible serious injury. NOTE: Brush caps (2) are located on the top and bottom of the motor housing in front of the handle.
  • Page 14 NOTES...

  • Page 15: Warranty

    2/1/04 and after. This product is manufactured by One World Technologies, Inc. The trademark is licensed from RIDGID, Inc. All warranty communications should be directed to One World Technologies, Inc., attn: RIDGID Hand Held and Stationary Power Tool Technical Service at (toll free) 1-866-539-1710.

  • Page 16: Reciprocating Saw

    VARIABLE SPEED Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
