Introduction
Includes
Setup/Remote Control Diagram
Warranty & Disclaimers
K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2
4K DVR Manual
Table of Contents
2
2
4
4
5
6
7
11
11
12
14
19
21
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SleuthGear ZONE SHIELD 4K DVR
Summary of Contents for SleuthGear ZONE SHIELD 4K DVR
-
Page 1: Table Of Contents
4K DVR Manual Table of Contents Introduction Includes Quick Setup Guide Features Setup/Remote Control Diagram DVR Menu Quick Start Guide DVR Menu & Settings LED Chart Specifications Frequently Asked Questions Products Warnings & Precautions Warranty & Disclaimers Page 1 K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2... - Page 2 ® All of our SleuthGear line of hidden cameras are designed and assembled in Nashville, TN USA ® backed by our 1 year warranty. Visit our website to see the full line of SleuthGear hidden cameras at www.mysleuthgear.com Includes ...
- Page 3 Compatible Memory Storage For the camera to function properly, below memory card brands of class 6 and above are recommended: Apacer Toshiba SanDisk Kingston For 64 & 128GB cards, the below memory card brands of class XCI or above are recommended: ...
-
Page 4: Quick Setup Guide
Quick Setup Guide Take the unit from the box and ensure you have received all included items (pg 3). Open the device to insert the memory card into the memory card slot and connect the power supply or battery, turning it on after the connection is made. ®... -
Page 5: Remote Control Diagram
Setup Remote Control Diagram Description(s) Icon Button Function Start/Stop Recording Manual/Continuous Recording Remote control key lock/ unlock. Lock/ Unlock Locks the buttons from accidental operation. Menu Enter or Exit the settings menu Up/ Down Menu navigation Left/ Right and settings changes Enter Confirm selection Enter Playback Menu... -
Page 6: Dvr Menu Quick Start Guide
DVR Menu Quick Start Guide K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 6... -
Page 7: Dvr Menu & Settings
DVR Menu & Settings Connect your camera system to a monitor or TV using the cable included to begin customizing your DVR Settings. Press on the remote to get into the On Screen Menu from the camera live view. From there you can modify the system settings. - Page 8 Triggering PIR Detection/M.D. Recording: Depending on Triggering the model, the Triggering menu will have motion detection settings for either PIR (Xtreme Life) or Camera (Zone Shield) detection. PIR Detection Manual/Continuous Recording: If you wish to PIR Sensitivity manually control recording instead, set either PIR Detection or M.D.
- Page 9 Storage Total Space, Total Time and Time Left will be Storage calculated automatically Format Memory Card Total Space Total Time Total Left Mode Set Up Menu Buzzer Setup: Turns the confirmation sound on Setup Menu or off. Status Display: Turns the live view Buzzer Setup On-Screen-Display on or off.
-
Page 10: Playback Menu
In the Time & Date setting, press to navigate and press to change the setting. Date & Time format options: YYYY/MM/DD, 2018 / 01 / 01 00 : 04 : 59 MM/DD/YYYY, or DD/MM/YYYY YY/MM/DD Playback Menu For live view, press to enter the Playback Menu directly. -
Page 11: Led Chart
LED Chart Power Indicator Blinking (Red LED) Power on Recording Power off Specifications Operation Temperature -20ºC~60ºC (-4ºF~140ºF) 4K [2880x2160] | 2K [2560x1440] | 1296P [2304x1296] Video Resolution 1080P [1920x1080] | 720P [1280x720] Video Format MPEG4 Video Compression H.264 Video Recording Schedule PIR | Motion Detection | Continuous Recording Frame Rate 24, 30, 60, 120 fps... -
Page 12: Frequently Asked Questions
Frequently Asked Questions Q. How do I playback my video? A. From the device, go to Playback Menu to view on your television, using on screen playback functions. You must have the output cable plugged in to your television, then select the proper input on your television to display the video from the unit. - Page 13 ® While SleuthGear makes a concerted effort to test Night Vision products in different low-light situations; we cannot replicate every possible lighting environment at a customer’s location.
-
Page 14: Products
Products Wall Clock Smoke Detector Rock Clock Radio K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 14... - Page 15 Bluetooth Speaker Memory Card Slot Infra-red Remote Sensor Electrical Box Outdoor Power Strip Air Freshener K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 15...
-
Page 16: Dvd Player
Plant Teddy Bear Mantel Clock DVD Player K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 16... - Page 17 Bird Feeder Oscillating Fan Air Purifier Auxiliary Video Out Memory card slot Rectangle Clock K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 17...
- Page 18 LED Desk Lamp Infrared Remote Sensor Memory Card Slot Auxiliary Video Output Room Freshener Memory Card Slot Cable Box Memory card slot K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 18...
-
Page 19: Warnings & Precautions
Warnings & Precautions K J B S e c u r i t y P r o d u c t s | w w w . m y s l e u t h g e a r . c o m | 8 0 0 . 5 9 0 . 4 2 7 2 Page 19... - Page 20 TRAVELING WITH BATTERIES Batteries and battery-powered devices are safe to travel with if you follow these simple guidelines from the U.S. Department of Transportation: If possible, keep spare batteries in the original retail packaging, to prevent unintentional activation or short-circuiting.
- Page 21 Manufacturer’s Limited Warranty ® Manufacturer warrants all Covert Video and SleuthGear Hidden Video Products (Product) assembled and sold by Manufacturer to be free of defects in material and workmanship, subject to the following conditions. The duration of Manufacturer's warranty with respect to the Product is limited to one (1) year from the date of sale to the original consumer purchaser only for Products delivered within the fifty (50) states of the United States, District of Columbia, or the possessions and territories of the United States No other express warranties are made with respect to any Product.
