PCI Expansion Slots

The K1SPE has the following available expansion ports on the motherboard:
•
Two (2) PCI Express 3.0 x16 slots (CPU Slot4/Slot6)
•
One (1) PCI Express 2.0 x4 (in x8) slot (PCH Slot2)

Onboard Controllers/Ports

Both the motherboard and chassis include the following I/O ports:
•
Four (4) USB 3.0/2.0 ports on the rear I/O panel (USB 2.0 0/1, USB 2.0 5/6 or
USB 3.0 2/3, USB 3.0 7/8)
•
One (1) Onboard USB header with two USB 3.0 connections (USB 3.0 8/9) for
front control panel
•
One Intel i350 Gigabit (10/100/1000 Mb/s) Ethernet controller for a Gigabit
(GbE) LAN port
•
One (1) Serial port on the IO back panel (COM1)
•
One (1) Fast UART 16550 connection header (COM2)
•
VGA port on the IO back panel
•
One (1) TPM header

Other Features

Other onboard features of the motherboard include:
•
BIOS features such as DMI 2.3, PCI 3.0, ACPI 3.0/4.0, USB Keyboard, Plug
& Play (PnP), BIOS Rescue hot-key, Real Time Clock (RTC), UEFI 2.3.1, and
SMBIOS 2.7 or later,
•
CPU 6-Phase switching voltage regulator
•
CPU/System overheat LED and control
•
CPU Thermal Trip support
•
Thermal Monitor 2 (TM2) support
•
PECI (Platform Environment Confi guration Interface) 2.0 support
•
Fan status monitoring with fi rmware 4-pin fan speed control
•
Low noise fan speed control
•
ACPI Power Management
•
Power-on mode for AC power recovery
•
®
Intel
Intelligent Power Node Manager (available when the NMView utility is
installed)
•
Management Engine
•
Riser card auto-detection
1-3
Chapter 1: Introduction
