- Page 1 ACKAGE ONDITIONERS FORM NO. S11-933 REV. 2 Supersedes Form No. S11-933 Rev. 1 RSNA-B SUPER HIGH EFFICIENCY 13-SEER SERIES NOMINAL SIZES 2-5 TONS [7.0-17.6 kW]...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Unit Features & Benefits ...3-4 Model Identification Options ...5-6 General Data RSNA-B Series ...7-9 General Data Notes ...10 Performance Data RSNA-B Series ...11-13 Airflow Performance RSNA-B Series ...14-15 Electrical Data RSNA-B Series...16 Electric Heater Kits ...17 Dimensional Data ...18-19 Typical Installations ...20... -
Page 3: Unit Features & Benefits
UNIT FEATURES & BENEFITS—RSNA-B These quality features are included in the Rheem Package Air Conditioner... - Page 4 UNIT FEATURES & BENEFITS—RSNA-B SERIES [ ] Designates Metric Conversions Features Below Correspond to Photos on Page 3 1. All models feature Copeland ® Scroll ® mum efficiency and quiet operation. 2. Louvered condenser compartment for protecting the coil against yard hazards and/or weather extremes.
-
Page 5: Model Identification Options
MODEL IDENTIFICATION—RSNA-B SERIES R S N A — B 036 J K 010 X X Factory Installed Options (See Next Page) Heating Capacity (Factory Installed) 000 = No Resistance Heat 005 = 05 KW Resistance Heat (018-030) 010 = 10 KW Resistance Heat (024-048) - Page 6 OPTIONS—RSNA-B SERIES Instructions for Factory Installed Option(s) Selection Note: Two characters following the model number will be utilized to designate a factory-installed option or com- bination of options. If no factory option(s) is required, nothing follows the model number. Step 1. After a basic rooftop model is selected, choose a two-character option code from the FACTORY INSTALLED OPTION SELECTION TABLE.
-
Page 7: General Data Rsna-B Series
NOMINAL SIZES 2-5 TONS [7.0-17.6 kW] Model RSNA-B Series Cooling Performance Gross Cooling Capacity Btu [kW] EER/SEER Nominal CFM/ARI Rated CFM [L/s] ARI Net Cooling Capacity Btu [kW] Net Sensible Capacity Btu [kW] Net Latent Capacity Btu [kW] Net System Power kW Compressor No./Type... -
Page 8: Rsna-B Series
GENERAL DATA—RSNA-B SERIES NOMINAL SIZES 2-5 TONS [7.0-17.6 kW] Model RSNA-B Series Cooling Performance Gross Cooling Capacity Btu [kW] EER/SEER Nominal CFM/ARI Rated CFM [L/s] ARI Net Cooling Capacity Btu [kW] Net Sensible Capacity Btu [kW] Net Latent Capacity Btu [kW]... - Page 9 NOMINAL SIZES 2-5 TONS [7.0-17.6 kW] Model RSNA-B Series Cooling Performance Gross Cooling Capacity Btu [kW] EER/SEER Nominal CFM/ARI Rated CFM [L/s] ARI Net Cooling Capacity Btu [kW] Net Sensible Capacity Btu [kW] Net Latent Capacity Btu [kW] Net System Power kW Compressor No./Type...
-
Page 10: General Data Notes
ARI capacity is net and includes the effect of fan motor heat. Units are suitable for operation to 20% of nominal cfm. Units are certified in accordance with the Unitary Air Conditioner Equipment certification program, which is based on ARI Standard 210/240 or 360. - Page 11 Total —Total capacity x 1000 BTUH dbE —Entering air dry bulb Sens —Sensible capacity x 1000 BTUH wbE—Entering air wet bulb Power—KW input SYSTEMS PERFORMANCE—RSNA-B SERIES ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 800 [378]...
- Page 12 SYSTEMS PERFORMANCE—RSNA-B SERIES GROSS SYSTEMS PERFORMANCE DATA—RSNA-B036 CFM [L/s] 1320 [623] DR ➀ Total BTUH [kW] 44.4 [13.01] Sens BTUH [kW] 25.5 [7.47] [23.9] Power Total BTUH [kW] 43.6 [12.78] Sens BTUH [kW] 25.0 [7.33] [26.7] Power Total BTUH [kW] 42.8 [12.54]...
-
Page 13: Performance Data
Total —Total capacity x 1000 BTUH dbE —Entering air dry bulb Sens —Sensible capacity x 1000 BTUH wbE—Entering air wet bulb Power—KW input SYSTEMS PERFORMANCE—RSNA-B SERIES ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀ 71°F [21.7°C] 67°F [19.4°C] 1600 [755]... -
Page 14: Airflow Performance Rsna-B Series
AIRFLOW PERFORMANCE—RSNA-B SERIES... - Page 15 AIRFLOW PERFORMANCE—RSNA-B SERIES...
-
Page 16: Electrical Data Rsna-B Series
2. Amp Draw Per Motor. Multiply Value By Number of Motors to Determine Total Amps. Copper Wire Size—AWG (1% Voltage Drop) Notes: 1. Wire size based on 60°C. type copper conductors below 100 ampacity. [ ] Designates Metric Conversions ELECTRICAL DATA – RSNA-B SERIES -B030JK -B036CK -B036JK -B042CK... -
Page 17: Electric Heater Kits
ELECTRIC HEATER KITS—RSNA-B SERIES... -
Page 18: Dimensional Data
UNIT DIMENSIONS—RSNA-B SERIES UNIT DIMENSIONS PACKAGE AIR CONDITIONERS FILTER ACCESS PANEL (FOR UNIT MOUNTED FILTER ACCESSORY) OUTDOOR COIL PROTECTIVE GRILLE THREADED PVC CONDENSATE DRAIN CONNECTION N.P.T. IMPORTANT: UNIT MUST BE LEVEL TO PREVENT WATER MIGRATION TOP VIEW " [1209 mm] OUTDOOR FAN GRILLE &... -
Page 19: Front View
CONDENSATED DRAIN SERVICE PORT CONNECTION (3/4 N.P.T.) IMPORTANT: INSTALLATION MUST NOT INTERFERE WITH DRAINAGE OPENINGS IN BOTTOM OF UNIT UNDER OUTDOOR COIL. UNIT DIMENSIONS—RSNA-B SERIES FILTER ACCESS PANEL (FOR UNIT MOUNTED FILTER ACCESSORY BLOWER/ EVAPORATOR ACCESS PANEL CONTROL ACCESS PANEL... -
Page 20: Typical Installations
TYPICAL INSTALLATIONS... -
Page 21: Accessories
ACCESSORY EQUIPMENT Accessory Description Roofcurbs Supply & Return Diffusers Economizers (Downflow ONLY) Fresh Air Damper Rectangular to Round Transition (Downflow) Filter Kit Low Ambient Control High Pressure Control Low Pressure Control Sideflow Rectangular to Round Transition LP Conversion Kits Canadian High Altitude Kit (for Natural Gas only*) *If a particular unit is to be converted to operate on LP (propane) for elevations above 2000 ft. - Page 22 ACCESSORIES DUCT ADAPTERS RECTANGULAR TO ROUND TRANSITIONS (DOWNFLOW) RXMC-CA02 RXMC-CA03 [ ] Designates Metric Conversions...
- Page 23 ACCESSORIES FRESH AIR DAMPER FOR USE ON RSNA-B SERIES RXRF-FAA1 (Fixed - 0-35%) The 0-35% manual outside Air Damper is designed to replace the unit return air duct cover. No drilling or damper assembly is required. The amount of outside air (0-35%) is controlled by sim- ply adjusting the side damper.
- Page 24 ACCESSORIES FILTER KIT INSTALLATION RXRY-B01 For use in either vertical or horizontal discharge. CFM [L/s] Minimum Nominal Model No. Airflow Airflow RSNA-B 510 [241] 600 [283] RSNA-B 680 [321] 800 [378] RSNA-B 850 [401] 1000 [472] RSNA-B 1020 [481] 1200 [566] RSNA-B 1190 [562] 1400 [661]...
- Page 25 ACCESSORIES DUCT ADAPTER SIDEFLOW SQUARE TO ROUND TRANSITION RXMC-BA01 Adapts the side rectangular supply and return openings to 14" [356 mm] diameter round openings. Adapters provided with same finish as unit and also provided with thermal insulation.
- Page 26 ACCESSORIES ROOFCURB (Full Perimeter) RXSG-AAA08, RXSG-AAA14 and RXSG-AAA24 for RSNA-B Series Hinged corners make for fast, easy set-up. RXSG-AAA08 (8" [203 mm] High) NOT for use with RQKA/RQLA/RQMA Package Heat Pumps. [ ] Designates Metric Conversions RXSG-AAA14 (14" [356 mm] High)
- Page 27 ACCESSORIES ROOFCURB (Full Perimeter) (Cont.) RXSG-AAA24 (24" [610 mm] High) [ ] Designates Metric Conversions...
- Page 28 ACCESSORIES PACKAGE AIR CONDITIONERS & GAS/ELECTRIC PACKAGE UNITS ROOFCURB INSTALLATION (Full Perimeter) [ ] Designates Metric Conversions ROOFCURB ADAPTERS Fabricated from galvanized steel to adapt the New cabinet to the old style curb. All are furnished with a New gasket. OLD MODEL SMALL CABINET -2 TON) [5.28-7.03 kW]...
- Page 29 ACCESSORIES LIFT KIT—MODEL NO. RXML-A01 The lift kit is intended for temporary installation while the unit is being lifted into position. Kit includes 4 lift brackets.
-
Page 30: Accessories
ACCESSORIES ELECTRIC HEATER KITS—RSNA-B Unit Model Application RSNA-B024JK RSNA-B030JK RSNA-B036JK RSNA-B042JK RSNA-B048JK RSNA-B036CK RSNA-B042CK RSNA-B048CK, RSNA-B060CK [ ] Designates Metric Conversions ONLY ELECTRIC HEATER KITS SUPPLIED BY THIS MANUFACTURER AS DESCRIBED IN THIS PUBLICATION HAVE BEEN DESIGNED, TESTED, AND EVALUATED BY A NATIONALLY RECOGNIZED SAFETY TESTING AGENCY FOR USE WITH THIS UNIT. USE OF ANY OTHER MANUFACTURED ELECTRIC HEATERS INSTALLED WITHIN THIS UNIT MAY CAUSE HAZARDOUS CONDITIONS RESULTING IN PROP- ERTY DAMAGE, FIRE, BODILY INJURY OR DEATH. -
Page 31: Typical Wiring
WIRING SCHEMATICS—RSNA-B SERIES... - Page 32 WIRING SCHEMATICS—RSNA-B SERIES...
- Page 33 WIRING SCHEMATICS—RSNA-B SERIES...
- Page 34 WIRING SCHEMATICS—RSNA-B SERIES...
- Page 35 WIRING SCHEMATICS—RSNA-B SERIES...
- Page 36 WIRING SCHEMATICS—RSNA-B SERIES...
- Page 37 NOTES...
- Page 38 NOTES...
- Page 39 NOTES...
-
Page 40: Limited Warranty
Federal, State, Provincial, and Local codes, regulations, and practices. “In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.” PRINTED IN U.S.A. 11-05 DC Condenser Coil and Evaporator Coil leaks caused by factory defects ...Five (5) Years...
