Revolutionary Cooling Systems PURON 704B024 Specifications

704B Packaged Cooling

Premium Features

• Puron , the environmentally sound alternative
®
o
• 13 SEER and 11 EER at 95
• All sizes 2-5 tons are compliant with Energy
Star ® requirements
• Built-in Thermostatic Expansion Valve
(TXV) improves overall efficiency
• Variable-speed direct drive indoor blower is
standard on all models

Perfect Humidity Package

• Better dehumidification: up to 30 times
• Economical constant fan operation; as low
as $50/yr
• Improved indoor air quality
• Selectable airflow for installation flexibility
• Improved CFM up to .9 static pressure
• For best comfort; use with Thermidistat
control

Standard Features

• Envirotuff rust proof base with integrated
TM
drain
• Easily converts to down discharge
• One panel access for ease of installation and
serviceability
• Vertical condenser fan discharge
• Sound ratings as low as 72dB
• Copper tube, aluminum fin condenser and
evaporatior coils
• Scroll compressors on all sizes
• UL & c-UL (U.S. and Canada) certified
• Louvered grille for added coil protection
• High and low pressure switches to protect
compressor
• Filter drier to protect the refrigerant system
• Metal, insulated duct covers that remain in
place for downshot applications

Optional Field Installed Accessories

• Economizers
• Manual air dampers
• Filter rack
• Roof curbs
• Optional strip heat (5-20 kW)

Factory Options

• Tin-plated indoor coil
• Copper fin & coil coatings
• Vinyl coated condenser fins

Warranty

• 5-year limited warranty on parts
• 10-year limited warranty on compressors
• Extended warranty available
PURON, SMALL PACKAGED
AIR CONDITIONERS
PURON, SMALL PACKAGED AIR CONDITIONING PRODUCTS
Model
F OD
704B 2–5 TONS
704B024
704B030
704B036
704B042
704B048
704B060
TM
ARI Cooling
Nom
Performance
Tons
BTUH SEER
2.0 24,000 13.0
2.5 28,800 13.0
3.0 36,000 13.0
3.5 41,000 13.0
4.0 46,000 13.0
5.0 58,000 13.0
704B
37
Approx.
Standard Sound
Ship Wt.
CFM (dB)
(lbs)*
W
800 365 72 47
1,000 365 72 47
1,100 388 72 47
1,400 455 72 47
1,450 478 78 47
1,710 513 78 47
Dimensions (in)
H D
39 31.5
39 31.5
41 31.5
43 43
45 43
47 43
