- Page 1 Item No. : 7010 3-in-1 Electric Jack, Impact Wrench & Air Compressor User’s Manual We are constantly improving our products so specifications are subject to change without notice. Visit our website for the latest product information.
- Page 2 3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® Thank you for purchasing the 3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech . With normal care and proper treatment, it will ® provide years of reliable service. Please read all operating instructions carefully before use.
-
Page 3: Safety Warnings
Do not operate for an overly extended period. When not using, please turn off the power. • Avoid dropping the machine into the water or using in bad condition. ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation. - Page 4 3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® • Check the power Car Cigarette Lighter socket uses 12V DC/15A power before use. • Take notice of the smooth floor and loading capacity when using. Also pay attention to locating the exact loading position of the car before the lifting operation.
-
Page 5: Specifications
Inflator Pump: Input Voltage 12V DC Inflating Speed 35 L/min Working Current Pressure 10 BAR/150 PSI Length of Air Hose 600 mm Cylinder Diameter 25 mm ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation. -
Page 6: Product Parts
3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® PRODUCT PARTS Diagram One: Switches See Diagram Three Storage Box Air hose storage Pressure Rod For lifting Top Light Illumination for Chassis Front Light For illumination Protective Pad... - Page 7 Cable Socket Connect the 12V DC power cable 12V DC Power Cable Power cable with car cigarette lighter socket head Warning Light Safety and warning indicator ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation.
- Page 8 3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® Diagram Three: NAME DESCRIPTION Direction Switch Up/Close/Down Pressure Gauge Pressure display Function Switch Inflate/Close/Lift Light Switch On/Off Down Inflate Lift Close www.wagan.com...
- Page 9 Disconnect the power plug from the cigarette lighter socket and collect the cables into the tool box. NOTE: when inflating, do not use continuously for more than 10 minutes. ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation.
-
Page 10: Troubleshooting
3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® TROUBLESHOOTING Jack is not working: 1. Check whether the vehicle power is on. 2. Check whether the function switch is in the correct function position. 3. Check if the indicator LED for the cigarette lighter plug is lit or not. If not, please re-connect the plug. - Page 11 4. Remove the head of safety valve(See Diagram Two, point 3), loosen the safety valve with hex key (rotate about half circle counterclockwise) till the pressure rod falls to the lower position, then tighten it again. ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation.
-
Page 12: Operating Instructions
3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® Electric Impact Wrench SPECIFICATIONS • Voltage: 12V DC • Max. Current: 12A • Rated Power: 100W • Max Torque: 340N.M • Weight: 1.9 kg ACCESSORIES • Fuse •... -
Page 13: Operation Diagrams
Apply the wrench to wheel nut and press the upper side of the switch (with mark ) to start, the nut will be loosened in 3 seconds. ©2018 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks of Wagan Corporation. - Page 14 3-in-1 Electric Jack, Impact Wrench & Air Compressor by Wagan Tech ® CAUTION • This electric wrench is only usable with 12V vehicle power systems. • Do not use the electric wrench continuously for more than 10 minutes at a time.
- Page 15 WAGAN Corporation disclaims any liability for consequential damages. In no event will WAGAN Corporation be responsible for any amount of damages beyond the amount paid for the product at retail.
- Page 16 31088 San Clemente Street Hayward, CA 94544, U.S.A. Tel: +1.510.471.9221 U.S. & Canada Toll Free: +1.800.231.5806 customerservice@wagan.com www.wagan.com ©2018 Wagan Corporation. All Rights Reserved Wagan Tech and wagan.com are trademarks of Wagan Corporation REV20180305-E...
