- Page 1 Mirage Liberty™ FULL FACE MASK User Guide English 61850/2 07 04 MIRAGE LIBERTY USER APAC ENG Global leaders in sleep and respiratory medicine www.resmed.com...
- Page 2 312981, AU 312982, AU 312983, AU 312984, AU 313118, AU 313120, AU 313121, AU 313122, AU 313123, AU 313124, AU 313125. Others pending. Mirage and Mirage Liberty are trademarks of ResMed Ltd and Mirage is registered in U.S. Patent and Trademark Office.
- Page 3 Mask parts Mouth cushion Cushion alignment guide Nasal pillows Valve hinge Elbow Exhaust vents Valve flap Mask frame Valve Ports cap Valve clip Inlet tube Swivel Headgear parts Upper straps Right upper clip Left upper clip Lower straps Lower clip Lower clip Fitting the mask Disassembling for cleaning...
- Page 4 Mirage Liberty Full Face Mask Illustrations Sheet Note: For complete instructions, please read the text section in conjunction with the illustrations on this sheet. Component of: 61850/2 Reassembling the mask Reassembling the headgear...
-
Page 5: Intended Use
Mirage Liberty™ FULL FACE MASK Thank you for choosing ResMed’s Mirage Liberty. The Mirage Liberty is a full face mask that combines nasal pillows and a mouth cushion, creating a mask that is both unobtrusive and easy to use without compromising seal, stability and comfort. -
Page 6: Using The Mask
Using the Mask Select ‘Mir Full’ or ‘Full Face’ as the mask option when using the Mirage Liberty with ResMed flow generators that have mask setting options. Fitting the mask The diagrams in section A on the illustrations sheet show how the parts of the mask fit together. -
Page 7: Removing The Mask
5 To tighten or loosen the headgear straps, peel the Velcro headgear and reposition it. Gently and evenly adjust the upper headgear straps (B-3), then the lower straps (B-4). Alternate the adjustment of each set of straps until they are comfortable and firm and so that the upper headgear clips rest between your eye and your ear. -
Page 8: Cleaning The Mask In The Home
Note: You can detach the elbow from the mask frame and leave the mask on your face. You may prefer to do this when briefly stopping therapy, for example to go to the bathroom. Disassembling the Mask See section C on the illustrations sheet. 1 Unclip the upper headgear clips from the frame (C-3). -
Page 9: Reassembling The Mask
The Mirage Liberty should be disinfected or sterilised when used between patients. Detailed disinfection and sterilisation instructions are available from the ResMed website, www.resmed.com/masks/sterilization, and must be consulted before multipatient use. Reassembling the Mask See section D on the illustrations sheet. - Page 10 5 Assemble the elbow assembly: a Push the tab of the valve up through the slot in the valve clip (D-7). Ensure that the valve locks into the slot. b Feed the flap of the valve through the slot in the elbow (D-8). c Press the valve clip onto the elbow until you hear both sides click into place (D-9).
-
Page 11: Troubleshooting
Troubleshooting Problem Mask won’t seal properly or is uncomfortable Mask is too noisy Possible reason Mouth cushion or pillows may be dirty. Mask may have been fitted incorrectly. Mask is incorrectly adjusted. Mouth cushion is wrong size. Mouth cushion is skewed in mask frame. -
Page 12: Technical Specifications
Technical Specifications Note: The mask system does not contain latex, PVC or DEHP materials. Pressure–Flow Curve 70.0 60.0 50.0 40.0 30.0 20.0 10.0 Mask Pressure (cm H Note: As a result of manufacturing variations, the vent flow may vary from that indicated in the graph. - Page 13 Mask sizes (excludes inlet tube and headgear) size width (mm) small large Symbols System and Packaging Caution, consult accompanying documents Lot number Part number/Product code No latex Humidity limitation Temperature limitation Manufacturer User Guide Indicates a warning or caution and alerts you to a possible injury or explains special measures for the safe and effective use of the device.
-
Page 14: Ordering Information
60014 Swivel (10 pk) Limited Warranty ResMed warrants that your ResMed mask system, including its components: mask frame, cushion, headgear, tubing and other accessories (“Product”) shall be free from defects in material and workmanship for a period of ninety (90) days from the date of purchase by the initial consumer.
