HD74UH04
Inverter
Description
The HD74UH04 is high-speed CMOS inverter using silicon gate CMOS process. With CMOS low power
dissipation, it provides high-speed equivalent to LS-TTL series. The internal circuit of three stages
construction with buffer provides wide noise margin and stable output.
Features
Encapsulated in very small 5pins package of 2.9
significantly improved.
The basic gate function is lined up as Renesas uni logic series.
Supplied on emboss taping for high-speed automatic mounting.
Electrical characteristics equivalent to the HD74HC04
Supply voltage range: 2 to 6 V
Operating temperature range: –40 to +85°C
| I
| = I
= 2 mA (min)
OH
OL
Ordering Information
Part Name
Package Type
HD74UH04EL
MPAK-5 pin
Rev.4.00, Feb.02.2004, page 1 of 1
1.6
1.1 mm, the efficiency to mount on substrate is
Package Code
Package
Abbreviation
MPAK-5V
REJ03D0201–0400Z
(Previous ADE-205-016B (Z))
Rev.4.00
Feb.02.2004
Taping Abbreviation
(Quantity)
EL (3,000 pcs/reel)
