- Page 1 PCA7438FF-100 Flash memory programming adapter for 38000 Series User's Manual Rev.1.00 September 1, 2003 REJ10J0251-0100Z...
- Page 2 • These materials are intended as a reference to assist our customers in the selection of the Renesas Technology product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corporation, Renesas Solutions Corporation or a third party.
-
Page 3: Table Of Contents
Contents 1. Precautions for Safety ... 4 1.1 Safety Symbols and Meanings ... 4 2. Introduction ... 6 2.1 Things to Check When Unpacking ... 6 3. Specifications ... 7 4. How to Write the Program ... 8 4.1 Programming Procedures ... 8 4.2 Attaching Adapter to PROM Programmer ... -
Page 4: Precautions For Safety
1. Precautions for Safety In both the user's manual and on the product itself, several icons are used to insure proper handling of this product and also to prevent injuries to you or other persons, or damage to your properties. This chapter describes the precautions which should be taken in order to use this product safely and properly. -
Page 5: Warning For Use Environment
Warning for Use Environment: • This equipment is to be used in an environment with a maximum ambient temperature of 35˚C. Care should be taken that this temperature is not exceeded. • Select the proper programming mode of the PROM programmer. Cautions to Be Taken for This Product: •... -
Page 6: Introduction
2. Introduction This product is a flash memory programming adapter for Renesas 38000 Series of 8-bit microcom- puters. The adapter is a tool that can be used to write programs into internal flash memory of microcomputers using a commercially available PROM programmer. -
Page 7: Specifications
3. Specifications Table 3.1 lists specifications of the programming adapter. Table 3.1 Specifications of the programming adapter Operating clock frequency Board configuration Applicable MCU M38B79FFFP (100-pin 0.65mm-pitch QFP) 1MHz (Supplied by the ceramic oscillator mounted on the adapter) Power supply Supplied from Vcc of the PROM programmer IC socket IC51-1004-814-6 (made by Yamaichi Electronics Co., Ltd.) -
Page 8: How To Write The Program
4. How to Write the Program This chapter describes how to write programs using a PROM programmer. For details on how to operate the PROM programmer, refer to the user's manual of the PROM programmer. 4.1 Programming Procedures Follow procedures (1) to (8) to write programs into the MCU. (1) Read the program into the PROM programmer. -
Page 9: Attaching Adapter To Prom Programmer
4.2 Attaching Adapter to PROM Programmer As shown in Figure 4.1, attach the No. 1 pin of the PCA7402E connector (standard-pitch 32-pin pin- header mounted) to the No. 1 pin of the IC socket of the PROM programmer. Be careful when attaching to the PROM programmer because incorrect insertion can cause fatal damage to the MCU. -
Page 10: Inserting Mcu Into Programming Adapter
4.3 Inserting MCU into Programming Adapter As shown in Figure 4.2, insert the No. 1 pin of the MCU into the No. 1 pin of the IC socket on the main unit. Be careful when inserting the MCU because incorrect insertion can cause fatal damage to the MCU. -
Page 11: Setting Jumper Switches
4.4 Setting Jumper Switches (1) Jumper Switch SW1 Set the jumper switch SW1 according to the output format of the MCU ports P2 of switch settings are shown in Table 4.1 and Figure 4.3. • When ports P2 • When ports P2 •... -
Page 12: Precautions When Opening And Closing Ic Socket
4.5 Precautions When Opening and Closing IC Socket When opening and closing the IC socket, hold the adapter horizontally as shown in Figure 4.4. Otherwise the inside of the IC socket may become damaged and cause an electrical insulation failure. Side view Figure 4.4 Holding the adapter in a horizontal position 4.6 Precautions When Handling Adapter... -
Page 13: Recommended Prom Programmers
5. Recommended PROM Programmers The PROM programmers listed in Table 5.1 are recommended for this product. Using the actual products, we have verified that these PROM programmers can be used to write programs without problem. Nonconformity occurring by using any other PROM programmers can not be supported. For the latest type of PROM programmers, contact the manufacturer to confirm whether it can be used for your product. -
Page 14: Memory Maps
6. Memory Maps Figure 6.1 shows memory maps of the MCU and the PROM programmer. 0000 0FFF 1000 FFFF Figure 6.1 Memory maps Internal flash memory area (60K bytes) ( 14 / 18 ) 00000 00FFF 01000 Programming area 0FFFF 10000 1FFFF PROM programmer... -
Page 15: Troubleshooting
7. Troubleshooting The table below summarizes errors to be checked carefully before you determine them to be a fault. 7.1 Errors That Occur When Writing to ROM 7.1.1 When Newly Purchased Cause Programming adapter PROM programmer Contact failure 7.1.2 Previously Written Normally Cause Programming adapter PROM programmer... -
Page 16: Mcu Does Not Function Normally
7.2 MCU Does Not Function Normally The program operates normally on the emulator, but when the MCU that has normally been written is attached the same program does not function normally. (1) Is the offset address specified correctly when copying data into the PROM programmer? (2) In the emulator, NOPs are often inserted in the area where the program has not been read, therefore the program happens to appear functioning normally even though it may have gone wild. - Page 17 PCA7438FF-100 User's Manual Rev.1.00 September 1, 2003 REJ10J0251-0100Z COPYRIGHT ©2003 RENESAS TECHNOLOGY CORPORATION AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED...
