Husqvarna BLi520x BLi940x Battery Operator's Manual page 2

A
1
2
B
15
What is what?
1 Mains plug
2 Battery charger Husqvarna QC 330 (Accessory)
3 Power-LED
4 Error-LED
5 Adapter
6 Battery indicator button
7 Display
8 Error-LED
9 Battery
10 Power switch
11 Battery indicator button
12 Indicates battery status
2 – English
WHAT IS WHAT?
3
4
17
15
15
16
16
7
8
5
6
12
11
13 14
13 Power-LED
14 Error-LED
15 Hooks for the battery pack
16 Button to secure the battery pack
17 Shoulder strap
18 Shoulder strap attachment
19 Button for shoulder strap adjustment
20 Fuse cover
21 Fuse
22 Branch protection (optional)
23 Trimmer plate (Accessory)
9
10
17
15
16
