- Page 3 H8S/2169Series TFP-144 User System Interface Cable (HS2169ECN61H) for E6000 Emulator User’s Manual...
- Page 4 1. Renesas neither warrants nor grants licenses of any rights of Renesas’s or any third party’s patent, copyright, trademark, or other intellectual property rights for information contained in this document. Renesas bears no responsibility for problems that may arise with third party’s rights, including intellectual property rights, in connection with use of the information contained in this document.
- Page 5 The HS2169ECN61H is a user system interface cable that connects an H8S/2148 series E6000 emulator (HS2148EPI61H; hereinafter referred to as the emulator) to the IC socket for a TFP-144 package and expansion I/O board (HS2169EIO61H) for the H8S/2169 series MCU on the user system.
-
Page 6: Table Of Contents
Section 1 Configuration...1 Section 2 Connection Procedures ...3 Connecting User System Interface Cable to Expansion I/O board ... 3 Connecting User System Interface Cable to User System ... 5 2.2.1 Installing IC Socket ... 5 2.2.2 Soldering IC Socket ... 6 2.2.3 Inserting Cable Head ... -
Page 7: Section 1 Configuration
Section 1 Configuration CAUTION Use an NQPACK144SE socket (manufactured by Tokyo Eletech Corporation) for the TFP-144 package IC socket on the user system. Figure 1 shows the configuration of the HS2169ECN61H user system interface cable for the TFP-144 package. Figure 1 HS2169ECN61H User System Interface Cable... - Page 8 Table 1 lists the HS2169ECN61H components. Please make sure you have all of these components when unpacking. Table 1 HS2169ECN61H Components No. Component Cable body Cable head IC socket Socket cover Screws (M2.0 x 10 mm) Screws (M2.0 x 6 mm) Guide pins (φ...
-
Page 9: Section 2 Connection Procedures
Section 2 Connection Procedures Connecting User System Interface Cable to Expansion I/O board Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. - Page 10 Emulator station Expansion I/O board Cable body connector User system interface cable Figure 2 Connecting User System Interface Cable to Expansion I/O Board...
-
Page 11: Connecting User System Interface Cable To User System
Connecting User System Interface Cable to User System Always switch OFF the user system and the emulator product before the USER SYSTEM INTERFACE CABLE is connected to or removed from any part. Before connecting, make sure that pin 1 on both sides are correctly aligned. -
Page 12: Soldering Ic Socket
Use the guide pins provided to determine where to install the IC socket, as shown in figure 3. Pin 1 4 projections to apply epoxy resin adhesive to Bottom view of IC socket Figure 3 Location Setting of IC Socket 2.2.2 Soldering IC Socket After fastening, solder the IC socket for a TFP-144 package to the user system. -
Page 13: Inserting Cable Head
2.2.3 Inserting Cable Head Check the location of pin 1 before inserting. Align pin 1 on the IC socket for an TFP-144 package on the user system with pin 1 on the user system interface cable head, and insert the user system interface cable head into the IC socket on the user system, as shown in figure 4. - Page 14 Fasten the user system interface cable head to the IC socket for an TFP-144 package on the user system with the four screws (M2.0 10 mm) provided. Each screw should be tightened a little at a time, alternating between screws on opposing corners. Take special care, such as manually securing the IC socket soldered area, to prevent the soldered IC socket from being damaged by overtightening the screws or twisting the components.
-
Page 15: Fastening Cable Body
2.2.5 Fastening Cable Body Connect the cable body to the cable head. Cable body Removing Push the unfastening jig Unfastening jig Cable head User system Figure 5 Fastening Cable Body... -
Page 16: Recommended Dimensions For User System Mount Pad
Recommended Dimensions for User System Mount Pad Figure 5 shows the recommended dimensions for the mount pad (footprint) for the user system with an IC socket for an TFP-144 package (NQPACK144SE: manufactured by Tokyo Eletech Corporation). Note that the dimensions in figure 6 are somewhat different from those of the actual chip's mount pad. -
Page 17: Dimensions For User System Interface Cable Head
Dimensions for User System Interface Cable Head The dimensions for the user system interface cable head are shown in figure 7. Figure 7 Dimensions for User System Interface Cable Head... -
Page 18: Resulting Dimensions After Connecting User System Interface Cable
Resulting Dimensions after Connecting User System Interface Cable The resulting dimensions, after connecting the user system interface cable head to the user system, are shown in figure 8. Figure 8 Resulting Dimensions after Connecting User System Interface Cable... -
Page 19: Section 3 Installing The Mcu To The User System
Section 3 Installing the MCU to the User System 1. Check the location of pin 1 before inserting. 2. Use a screwdriver whose head matches the screw head. 3. The tightening torque must be 0.054 N•m or less. If the applied torque cannot be accurately measured, stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening. - Page 20 Figure 9 Installing MCU to User System...
-
Page 21: Section 4 Verifying Operation
EXTAL terminal on the cable head or connecting a crystal oscillator to the EXTAL and XTAL terminals. For details, refer to the Clock Pulse Generator section, in the H8S/2169 Series Hardware Manual. Figure 10 shows the oscillator circuit on the user system interface cable. -
Page 22: Section 5 Notice
1. Make sure that pin 1 on the user system IC socket is correctly aligned with pin 1 on the cable head before inserting the cable head into the user system IC socket. 2. The dimensions of the recommended mount pad for the user system IC socket are different from those of the MCU.
