Intel® Server System S7000FC4UR TPS
Offset Name
07h Processor
Manufacturer
08h Processor ID
10h Processor
Version
11h Voltage
12h External Clock
14h Max Speed
16h Current Speed
18h Status
19h Processor
Upgrade
1Ah L1 Cache
Handle
1Ch L2 Cache
Handle
1Eh L3 Cache
Handle
20h Serial Number
21h Asset Tag
Revision 1.0
Length Value
Byte String
QWord Varies
Byte String
Byte Varies
Byte Varies
Word Varies
Word Varies
Word Varies
Byte 04h
Word Varies
Word Varies
Word Varies
Byte String
Byte String
BIOS Role in Server Management
Description
Section 3.3.5.2 for values.
Number of null terminated string. String
contains "Intel Corporation".
Contains the results of the CPUID
instruction with EAX = 1 as follows:
Offset 08h-0Bh: EAX
Offset 0Ch-0Fh: EDX
Number of Null terminated string that
describes the processor. This string is
returned from the processor.
Bit 7 - 1
Bits [6:0]
Current processor voltage * 10 - 1.8V
= 92h
External clock speed in MHz.
Maximum internal processor speed in MHz.
Current internal processor speed in MHz.
Bit 7
0 = Reserved
Bit 6
0 = Socket unpopulated
1 = Socket populated
Bits 5:3
0 = Reserved
Bits 2:0
0h = Unknown
1h = CPU enabled
2h = CPU disabled by user
3h = CPU disabled by BIOS
4h = CPU idle, waiting to be enabled
5h, 6h = Reserved
7h = Other
04h - ZIFF socket.
Handle of the cache information structure
for L1 cache for this processor. Set to
0FFFFh if the cache information structure is
not supported.
Handle of the cache information structure
for L2 cache for this processor. Set to
0FFFFh if cache information structure is not
supported.
Handle of cache information structure for
L3 cache for this processor. Set to 0FFFFh
if cache information structure is not
supported.
String number for the serial number of this
processor. This value is set by the
manufacturer and normally not changeable.
String number for the asset tag of this
processor.
