Overview of the Speedway Mini4 Pro

► Contents Checklist
- Charger (2A), Tools for assembly, Mini 4 Pro
* Battery comes pre-installed
* Scan QR Code
to download an
electrical wiring
diagram.
Electrical Wiring Diagram
QR Code
Rear Wheel Brake Lever
Thottle Lever
Quick-Release
(+Electric Brake) LCD
Dashboard Lever
Handle /
(height adjust)
Grip
Handlebar Upper Post
Handlebar Post
(T-bar)
(steering tube)
High-strength Retractable
Standing Deck
Folding / Unfolding
Battery
Rear Fender Locking Shaft Lever
(internal)
Taillight (Brake Light)
Charging Port
Front Suspension
Rear Suspension Arm
Rear Suspension
Front Fender
Rear Wheel Motor
Light
Button
8" Solid Rubber
Headlight
Rear Tire
8" Pneumatic Front Tire

Dashboard Functionality

► ► Main Mode Select
Speed Mode Select to control
,
Speed Mode
Speed
Accelerator
Power
Trigger
Unit of Button
Speed
Battery Meter
/ Remaining
Charge
Time Elapsed
Mode Button
With dashboard powered on, pressing will display currently selected
speed mode, and pressing will cycle through speed modes (3 in total).
Once mode is selected, pressing will complete the selection.
* When battery remaining is 10%, meter will flash 3x every 10 sec. When
battery remaining is 0%, meter will continue to flash non-stop.
► Dashboard Settings
enters settings mode
Turn on dashboard. With pressed
and held for 2~3 sec., press to enter
settings mode.
8(fixed) 48(fixed) 15(fixed)
In settings mode, pressing once allows
settings value changes, where
and increase and decrease values.
Setting
Mode
Cruise Control Slow Start Max Power
0(disabled) 0(off:power) Select
1(enabled) ~5(slow) 1~100
1. Unit measurement - P4 : 0(Km/h), 1(mp/h) displayed
2. Start Mode selection - P5 : 0(instant), 1(kick push start)
3. Cruise Control - P6 : 0(disabled), 1(enabled)
Setting
Value
4. Slow Start - P7 : 0(off : power start) ~ 5(smooth start)
* If default settings for P0(8), P1(48), P2(15), P3(0) are 5. Max Power Select - P8 : 1 ~ 100
changed, correct info will not display. 6. Battery Eco Mode - P9 : 1(max), 2(mid), 3(off)
* In Low Speed(1) mode, changing to Slow Start(P7)
7. Electric Brake Sensitivity Select - PA : 0(disable) ~ 5(strongest)
function will not enable feature.
8. LCD Brightness - Pb : 0(off) ~ 5(max)

Getting Started with Your Speedway Mini4 Pro

Unfolding (Steps)
Tools
Folding lever
Charger
1. Raising handlebar post
How to Start
Handlebar
Width
Light Button
21"
46.5"
(height
Standing platform adjustable)
Step 1) Light Button Check
Width 7"
Rear Fender
Kickstand
40"
Step 3) Riding
Keep record of VIN
Note
number!
Enhancements
On the Speedway Mini 4, the folding
supports have been upgraded.
Both the front and rear suspension have
been significantly enhanced for improved
riding comfort.
Periodically check front & rear suspensions
for warping or strain (caused by hard
impact while riding), along with tightness of
suspension nuts and bolts.
short press
► Cruise Control
cycle through modes
Cruise Control for Convenience. Please use safely!
Mode Description Cruise control automatically maintains the current speed. Using cruise control eliminates the need to continually hold the
throttle on those longer rides, while also increasing the overall battery efficiency.
Current Trip Mileage (long
TRIP
press mode button to reset) ● Engage Cruise Control
After enabling cruise control function, holding the thottle lever for
ODO
Total Mileage
approx. 7 sec at desired speed will automatically engage cruise
CHA (unused)
control.
VOL
Current Voltage ● Disengaging Cruise Control
Once cruise control is engaged, by squeezing, then releasing
DST
(unused)
the brake lever, will deactivate it.
TIME
Time Elapsed
► Electric Brake Sensitivity Settings
0(fixed) Units (speed) Start Mode
Disabled
0(Km/h) 0(instant)
1(mp/h) 1(kick push)
► Dashboard Diagnostics
Battery Eco Mode Electric Brake LCD Brightness
1(max) Sensitivity 0(off)
2(mid) 0(off) ~5(max)
3(off) ~5(strongest)
Press the lock groove to
adjust handlebar height,
Press folding lever
then lock in place with
down and raise
the quick-release lever.
handlebar post.
Quick-
release
lever
2. Handle T-bar height adjustment 3. Unfolding handles
1. If light button is enabled, the dashboard will not
power on, and the Scooter will not start. This is
by design as an anti-theft feature.
* Dashboard will automatically power off after a few
minutes of inactivity. Since the light is also turned off,
completely power off unit (via light switch) before
powering back on.
Step 2) Turning on the Dashboard
2. With light button OFF, press and hold the dashboard
power button for 2 sec. to turn unit on. You can now
Brake Lever
switch between the different modes: Start, Cruise
Accelerator Trigger
Control, Electric Brakes, etc.,.
3. With the kickstand folded up, grip the handles
comfortably while placing one foot on the foot
platform. Please be careful not to place a foot on
rear fender.
Step 4) Apply the throttle
4. To set off, gentlely pull the accelerator level. To
brake and/or stop, squeeze brake lever.
Before riding, make sure the folding support
!
handlebar post, are fastening & locked
into position. Make sure handlebar is fully
Caution
extended by pulling until lock clicks.
Dashboard Functionality, Cont.
! When cruise control is activated, be prepared to
brake at any time in case of emergency. Cruise
Caution
control can only be cancelled via braking, not via
accelerator trigger.
!
Electric Braking on Full Charge
Be aware that electric braking will not
Warning
function while device is fully charged, ride
accordingly. Electric brakes will resume
operating as normal when battery is partially
depleted.
Moderate Strong
(1~4 Adjustable)
Failure
Diagnostic Method Solution
Type
System Error
②
④ Motor Error
*If these error messages appear,
Accelerator Error please contact us at support@
⑤
ewheels.com
Controller Error
⑥
(Other)
⑦⑧⑨⑩
* ① Displayed when cruise control is engaged.
* ③ Displayed when brake lever is engaged. (Accelerator is disabled)
Getting Started with Your Speedway Mini4 Pro, Cont.
Recommend Braking Practices
Unfold and raise
Rule 1
handles. Rear Brake Deceleration
Always decelerate before coming to a complete stop. Practice safe
braking by decelerating with rear brake lever first, coming to a gradual
and complete stop.
Rule 3
Electric Braking and Deceleration
When you enable the electric brake and set brake strength on dashboard it enhances the effectiveness of the
stopping distance. If enabled, when applying the brake both the motor & drum brake automatically work in tandem.
Tip
Brake Inspection
Please periodically check the brake cable (connection points, wire damage, twisting, etc.) and drum brake (for excessive wear, loosening
of inner wire) to ensure safe and proper braking function.
● At speed, sound may occur from accelerated sections under load (this is torsional vibration), due to vibration from motor
!
and chassis components. At approx. 6~15 mph, this is a common phenomenon of all rotors at specific rotational RPM (eg.
fans, cars, motor boats, etc.), and is not a product defect. However, in event of continuous noise or overly loud metallic noise,
Advisory
supporting bolts may have loosened. Please inspect before use.
● After use, the motor & rear drum brake may produce significants amount of heat, pleaes do not touch!
Folding (Steps)
Folding Lever
Press folding lever
and fold down
handlebar stem.
1. Folding handlebar stem
Speedway Mini 4 (ERT-
Product
0836)
Motor Type 48V 500W nominal BLDC HUB Motor
Battery Type 48V 15Ah
Battery Capacity 748 Wh
Scooter Weight
36 lbs
Charging Time 6~8 hours*
with regular charger
Range
30 miles
(Continuous)
Max Speed 28 mph
Max Incline 15 degrees (approx 27% grade)
Max Load 265 lbs
One-touch folding /
Folding Features
Handlebar: one-touch slide & fold
Dimensions 40" x 20.9" x 46.5"
Throttle trigger-mounted
Dashboard
backlit LCD Display
Lights LED Headlight, Tail-light
Suspension Front and Rear Suspension
Brake Drum Brake (Rear)
Tires 8" (200 x 50)
Aluminum alloy (frame, handlebar),
Materials
PP (cover)
* Range and max speed may vary according to rider weight, climate, wind resistance, road conditions, hill grade, tire pressure, battery
condition, and overall riding manner.
Rule 2
Stop Safely
Extreme hard and sudden emergency braking may cause Scooter to skid
out. Please apply progressive gradual braking. Do not apply extreme
force to the brake lever.
Fold down
Press the locking
handles.
groove & push the
handlebar down.
Locking
Groove
2. Retracting handlebar 3. Folding handles

Specifications

Model
Notes
Name
Rear-Wheel Drive / MAX 1300W
Lithium Polymer
battery cycle life dependent
165±10lbs rider weight,
15.5 mph (flat, level ground)
Length x Width x Height
Power On/Off (Battery %, Trip, Odometer,
Time Elapsed, Speed, Volt Meter)
Tail-light also functions as Brake Light
Built-in electric braking (on/off), regenerative
Pneumatic Tire (Front) / Solid Rubber Tire (Rear)
