- Page 1 INSTRUCTION MANUAL MANUAL INFLATION BLOOD PRESSURE MONITOR HEM-412CREL Model...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction …………………………………………………………… 3 Important Safety Notes ……………………………………………… 4 Know Your Unit ……………………………………………………… 5 Quick Reference Guide ……………………………………………… 6 A Few Words About Blood Pressure ………………………………7-10 Battery Installation/Replacement ………………………………… 11 Care and Maintenance……………………………………………… 12 Suggestions Before Taking A Measurement …………………………13 How To Apply The Arm Cuff ……………………………………... -
Page 3: Introduction
Thank you for purchasing the ReliOn HEM-412CREL Manual Inflation Blood Pressure Monitor. Fill-in for future reference DATE PURCHASED: ______________ SERIAL NUMBER: ________________ Staple your purchase receipt here. The monitor features an easy-to-squeeze inflation bulb that allows you to quickly inflate the cuff. The measurement reading is clearly displayed on a large digital panel. -
Page 4: Important Safety Notes
IMPORTANT SAFETY NOTES To assure the correct use of the product basic safety measures should always be followed including the precautions listed below: Read all information in the instruction book and any other literature included in the box before using the unit. Contact your physician for specific information about your blood pressure. -
Page 5: Know Your Unit
Systolic Blood Pressure Display Diastolic Blood Pressure / Pulse rate Display Arm Cuff Air Tube Air Tube (Connects to the air plug) KNOW YOUR UNIT Air Plug MEMORY Button ON/Off Button Air Release Button Inflation Bulb Air Tube (Connects to the air plug) Air Plug... -
Page 6: Quick Reference Guide
QUICK REFERENCE GUIDE 1. Avoid eating, smoking, and exercising for at least 30 minutes before taking a measurement. 2. Put your left arm through the cuff loop. The bottom of the cuff should be about 1/2 inch above the elbow. The cuff tab should lie over the brachial artery on the inside of the arm. -
Page 7: A Few Words About Blood Pressure
A FEW WORDS ABOUT BLOOD PRESSURE Blood pressure is the force on the walls of your blood vessels as blood flows through them. Your heart is like a pump. When it contracts, or beats, it sends a surge of blood through the blood vessels and pressure increases. - Page 8 When blood pressure is consistently above normal it is called hypertension (high blood pressure). Your new ReliOn HEM-412CREL Manual Inflation Blood Pressure Monitor measures your systolic and diastolic blood pressure for you, then displays the results on an easy-to-read digital panel!
- Page 9 For example, when you are exercising or angry your blood pressure increases, but when you are relaxing or sleeping your blood pressure decreases. These changes are completely normal. Your ReliOn HEM-412CREL Manual Inflation Blood Pressure Monitor is especially helpful when tracking changes in blood pressure because it travels anywhere and takes just seconds to use.
- Page 10 A FEW WORDS ABOUT BLOOD PRESSURE The World Health Organization (WHO) and The International Society of Hypertension (ISH) jointly developed the following Blood Pressure Classification. This classification, however, is only a general guideline because your optimum blood pressure depends on your age, morbidity, and treatment strategy by a physician.
-
Page 11: Battery Installation/Replacement
BATTERY INSTALLATION / REPLACEMENT 1. Slide the battery cover off in the direction of the arrow. 2. Install 4 “AA” size batteries so + (positive) and – (negative) polarities match the polarities of the battery compartment as indicated. 3. Replace the battery cover. NOTE: If the Low Battery Indicator appears on the display, replace all four batteries. -
Page 12: Care And Maintenance
CARE AND MAINTENANCE To keep your digital blood pressure monitor in the best condition and protect the unit from damage follow the directions listed below: Clean the monitor with a soft dry cloth. Do not use any abrasive or volatile cleaners. Do not attempt to clean the cuff. Never immerse the monitor or any components in water. -
Page 13: Suggestions Before Takinga Measurement
SUGGESTIONS BEFORE TAKING 1. Avoid eating, smoking, and exercising for 30 minutes before taking a measurement. Rest for at least 15 minutes before taking the measurement. 2. Stress raises blood pressure. Avoid taking measurements during stressful times. 3. Remove tight-fitting clothing from your left arm. 4. -
Page 14: How To Apply The Arm Cuff
HOW TO APPLY THE ARM CUFF 1. If the cuff is assembled correctly, the sewn hook material will be on the outside of the cuff loop and the metal D-ring will not touch your skin. 2. Pass the end of the cuff furthest from the tubing through the metal D-ring to form a loop. - Page 15 HOW TO APPLY THE ARM CUFF 4. Pull the cuff so that the top and bottom edges are tightened evenly around your arm. 5. When the cuff is positioned correctly, press the sewn hook material FIRMLY against the pile side of the cuff.
-
Page 16: How To Take A Measurement
HOW TO TAKE A MEASUREMENT Please read “A Few Suggestions Before Blood Pressure Measurement”and “How To Apply The Arm Cuff” before taking a reading. 1. Press the ON/OFF Button. a) All display symbols appear for about one second. This is the initial LCD Test. b) The display symbols disappear and the Deflation Indication Symbol ( ) starts to flash. -
Page 17: How To Take A Measurement
HOW TO TAKE A MEASUREMENT 3. Remain still. The cuff will begin to deflate automatically. 4. As the cuff deflates, decreasing numbers appear on the display. The Heart Symbol ) flashes at every heartbeat. 5. When measurement is complete, the Heart Symbol ( ) stops flashing and your blood pressure and pulse rate are displayed alternately. -
Page 18: How To Use The Memory Function
HOW TO USE THE MEMORY FUNCTION This monitor has a memory capable of storing fourteen (14) sets of readings. Every time you complete the measurement, the monitor automatically stores blood pressure and pulse rate. • Press the ON/OFF Button • Press the MEMORY Button to recall stored readings while the Heart Symbol ( ) is displayed. -
Page 19: Error Indicators
ERROR INDICATORS Error Symbol Cause Cuff under-inflated. Movement during Measurement No pulse or blood pressure reading due to very weak artery pulse. Residual air pressure in cuff. Cuff over-inflated (more than 300 mmHg). Batteries have run down. Correction Wait 2-3 minutes and take another measurement. -
Page 20: Fcc Statement
FCC STATEMENT Note: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 21: Warranty Information
WARRANTY INFORMATION Your HEM-412CREL Manual Blood Pressure Monitor, excluding the monitor cuff, is warranted to be free from defects in materials and workmanship appearing within 5 years, when used in accordance with the instructions provided with the monitor. The monitor cuff is warranted to be free from defects in materials and workmanship appearing within one year, when the monitor is used in accordance with the instructions provided with the monitor. -
Page 22: Specifications
Arm Circumference Range: Accessories: UPC Code: NOTE: These specifications, to improve performance, are subject to change without notice. SPECIFICATIONS HEM-412CREL LCD Digital Display Pressure: 0 to 280 mmHg Pulse: 40-180/min. Pressure: ±3mmHg or 2% of reading Pulse: ±5% of reading... -
Page 23: Blood Pressure Log
BLOOD PRESSURE LOG DATE: SYS/DIA./PULSE: SYS/DIA./PULSE:... - Page 24 Made in China Manufactured by: OMRON HEALTHCARE, INC. 300 Lakeview Parkway Vernon Hills, Illinois 60061 www.omronhealthcare.com Copyright © 2003 Omron Healthcare, Inc. 412CRELINST Rev A...
