ASG TLB-D412LH Manual

TLB-D Brushless Electric Screwdrivers
• Read these instructions for the proper use of the tool.
• After having read these instructions, keep them in a convenient place so you or
the operator can refer to them whenever necessary.
PLEASE NOTE: When repairing or replacing tools or components on any TLB
Series purchased in 2016 or prior, please contact ASG representative
ASG, Division of Jergens, Inc.
S. Waterloo Road | Cleveland, OH
15700 44110-3898
| Phone: ( | Fax: ( | Email: asginfo@asg-jergens.com | Web: www.asg-jergens.com | Revision Date: 01/03/18
888) 486-6163 216) 481-4519

Table of Contents

Overview ................................................................................................................. 1
General Safety Rules ................................................................................................ 2
Safety Instructions ................................................................................................... 3
Description of Operation .......................................................................................... 3
Grounding Instructions ............................................................................................ 3
Installation Instructions ........................................................................................... 4
Panel Specifications ................................................................................................. 4
Counting Set-Up Instructions ................................................................................... 5
Torque Adjustment Operation .................................................................................. 8
Servicing .................................................................................................................. 8
Product Specifications ............................................................................................. 9
Warranty .................................................................................................................. 9

Overview

Thank you very much for selecting the TLB-D Brushless Electric Screwdriver.
Read this manual before placing tool in service or operation. Save
these instructions for future reference. It is the responsibility of the
employer to place the information in this manual into the hands of
the operator. Failure to observe the following warnings could result
in injury. When using electric tools, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and
personal injury.
Note: ASG is not responsible for customer modification of tools for applications on
which ASG was not consulted.
1
