Design of the Watch
Thank you for selecting the Fila Watch. This User Guide is the
recommended source of information about your Watch.
Please read it carefully and follow all the instructions.
[EL] [S/S]
[M] [L/R]
EL Button [EL]
• To turn on the EL back light.
Mode Button [M]
• Change to different modes.
• To decrease the setting value.
Reset [R]
• To select among sub modes: Step, Distance, Calorie and
Exercise Time.
• To reset the counter.
• To increase the setting value.
Start/Stop Button [S/S]
• To 'start' or 'stop' the pedometer and chronograph.
• Hold to enter the setting mode: time, unit, step length, weight
and the target number of steps.
2
Specifications
Current Time Mode Daily Record Mode
• Time System: am, pm, hour, • Past 7-day records
minute
• Steps, Distance, Calories
• Time Format: 12-hour or 24-hour and Exercise time records
Exercise Mode
Odometer Mode
• Daily Countable Steps Range: • Accumulated values of
0-99999 steps
Steps, Distance, Calories
and Exercise time records
• Distance display:
0-999.99 km / 0-999.99 mile Back Light
• Exercise Timer: 0- 99999 min • Back Light Type:
Electro-Luminescent (EL)
• Calorie Burnt Range:
back light
0-9999.9 calorie
• Memory: 7 days and current day Power Saving Mode
• Low battery indication
• 10- segment workout gauge
• Unit selection: Metric
(Kg,Km)/Imperial (Lb,Mile)
Chronograph Mode
• Resolution: 1 second
• Measuring Range: 99 hours 59
minutes and 59 seconds
• Synchronization with pedometer
Paper size: 210mm(W) x 280mm(H)
Finish size: 70mm(W) x 70mm(H)
3
Major Function Modes
Exercise Mode
[M]
FM-754.1
Odometer Mode
4
Setting Mode
Exercise Mode
hold
[S/S]
Hour Format
12/24 hr
[S/S]
Hour
[S/S]
Minute
Press [R] to increase or press [M] to decrease the setting.
Hold [R] or [M] to make the setting faster.
How to make the setting
• In Exercise Mode, hold the [S/S] button to enter the setting
selection
• Press the [S/S] button to move the display among different
settings
• When the target setting is displayed, press the [R] button to
increase or switch the setting. Hold the [R] button to increase
the setting faster. Press the [M] button to decrease the setting,
hold it to decrease the setting faster.
• To exit the setting mode, press the [S/S] button until you return
to the Exercise mode.
NOTE
• If no button is pressed for 1 minute, it will return to the exercise
mode automatically.
• Select the desired metric or imperial unit first before using and
recording data. All data in the Exercise, Daily Record and
Odometer modes will be reset to 0 if the user changes the unit
(metric and imperial).
5
Exercise Mode - Pedometer
[M]
Chronograph Mode
[M]
[M]
Daily Record Mode
[S/S]
Target Step
[S/S]
Weight
[S/S]
Stride length
[S/S] [S/S]
Unit
Metric/Imperial
6
Exercise Mode - Workout Gauge
Workout Gauge Display
• To monitor your workout, a 10-segment indicator at the left of
the watch shows the percentage of your preset target steps
accomplished. (Check chapter 3.0 for detailed setting )
• When the target steps (100%) are done, the 10-segment
indicator will flash with a 30-second 'beep beep' audio alert.
NOTE
• The Pedometer and Chronograph can be synchronized.
• If the number of target steps is greater than 1000, it is
adjusted at a multiple of 1000.
• If the number of target steps is less than 1000, it will be
adjusted at a multiple of 100.
(FRONT)
1st row
2nd row
Pedometer
ON [R]
Distance view
[R] [R]
[R]
Exercise Time Calories view
view
Exercise Mode Display
• The sub-views: Steps, Distance, Calories and Exercise
time will be exhibited in the 1st row of the display.
• Press the [R] button to select the sub-views.
• The current time (hour and minute) is exhibited in the 2nd
row of the display.
• Hold the [R] button to erase the data in the Exercise
mode.
Pedometer
• In the exercise mode, press the [S/S] button to start or
stop the pedometer.
• When the pedometer is ON, the colon will flash. It stops
flashing and stays steadily ON when the pedometer is
stopped.
NOTE
• The Pedometer and Chronograph can be synchronized.
• If the synchronization is turned ON, turning ON or OFF the
Pedometer or Chronograph will activate or stop the other
one simultaneously.
• To synchronize the Pedometer and Chronograph, please
check chapter 7.
Target steps
Exercise Mode
accomplished
