Regency H2100 Specification Sheet

Firebox height is 22-1/2" at highest point
6" Dia.
Flue
1-3/8"
Minimum Fireplace Opening
Height
Width
Depth
Faceplate Dimensions
Standard
Oversize
June 2007 Regency Product Specifi cations Book
Wood Inserts
H2100 Hearth Heater
Faceplate
28"
20" (508mm)
N/A
N/A
40-1/4" (wide) x 30" (height)
48" (wide) x 33" (height)
Dimension Description
A Adjacent Side Wall (to side)
B Mantle (to top)**
C Top Facing (to top)
D Side Facing (to side)
E Minimum Hearth Extension*
F Minimum Heath Thickness*
G Minimum Hearth Side Extension
Side and Top facing is a maximum of 1-1/2" thick.
Floor protection must be non-combustible, insulating material with an
R value of 1.1 or greater.
* If the hearth extension is fl ush with the fl oor (F) it must extend
19-1/2" in front of the body face (E).
Note: Hearth Extension Width (G) is measured from edge of fuel
door to side of hearth.
** A non-combustible mantel may be installed at a lower height if the
framing is made of metal studs covered with a non-combustible
board.
H2100 Wood Insert
H2100
10" (255mm)
25" (635mm)
14" (355mm)
8-1/2" (216mm)
18" (455mm)
1-1/2" (38mm)
6" (152mm)
191
