Green Brook SHAS Installation & Operating Instructions

INSTALLATION /OPERATING
INSTRUCTIONS FOR
DUAL VOLTAGE SHAVER
MODEL NUMBER: SHAS
Please read these instructions fully
before attempting installation.
1) This product should be installed
and wired by a qualified electrician
in accordance with the current IEE
regulations. Ensure the power
supply is disconnected before
proceeding with the installation.
2) This product must be earthed.
3) All bare earth wires must be
covered with appropriate
green/yellow sleeving, not
supplied.
4) Please check with manufacturers
instructions for suitability with
rechargeable shavers.
INSTALLATION & WIRING
1. This shaver supply unit is suitable
for surface mounting, using a
49mm 2 gang surface back box or
flush mounting using a 47mm 2
gang metal back box.
2. Remove and retain the 2 fixing
screws located at the back of the
fascia plate.
3. Feed supply cable through the
installation box appropriate
knockout, in the case of the metal
back box fit a 20mm rubber
grommet.
4. Strip outer sheath of the supply
cable to suitable length and then
remove 10mm of the insulation
from the Live (brown or red) and
Neutral (blue or black) conductors
to expose inner cores.
5. Insert neutral (blue or black)
conductor into the terminal
marked N and fully tighten the
screw.
6. Insert live (brown or red)
conductor into the terminal
marked L and fully tighten the
screw.
7. Insert the earth conductor,
ensuring it has been sleeved with
green/yellow sleeving, into the
terminal marked
8. Ensure that an additional earth
cable is connected between the
shaver supply unit earth terminal
and the earth terminal in the back
box being used.
9. Fit socket to back box with the 2
fixing screws provided.
10.Re-fit the supply fuse (if removed)
for isolation and switch supply
back on.
SUPPLY UNIT
SAFETY
INSTRUCTIONS
INSTRUCTIONS
