Patent Pending
Model No. RBTL10500
USER'S MANUAL
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.workoutwarehouse.com
this equipment. Save this man-
®
new products, prizes,
ual for future reference.
®
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RBTL10500 and is the answer not in the manual?

Questions and answers

Related Manuals for Reebok RBTL10500

Summary of Contents for Reebok RBTL10500

  • Page 1 ® Patent Pending Model No. RBTL10500 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    3. This treadmill is intended for home use only. Do not use this treadmill in any commercial, rental, or institutional setting. 4. Place the treadmill on a level surface, with at least eight feet of clearance behind it. Do not place the treadmill on any surface that blocks air openings.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown below have been placed on your treadmill. If a decal is missing or illegible, please call our Customer Service Department toll-free to order a free replacement decal (see HOW TO ORDER REPLACEMENT PARTS on page 31).

  • Page 5: Before You Begin

    The model number is RBTL10500. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location).

  • Page 6: How To Set Up The Treadmill

    Upright (65) and tighten the Lock Knob onto the Lock Pin. 3. Make sure that all parts are tightened before you use the treadmill. Place a mat under the treadmill to protect the floor or carpet. If you purchase the optional heart rate monitor (see page 20), follow the steps below to install the receiver included with the heart rate monitor.

  • Page 7: Treadmill Operation

    READMILL PERATION THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. Such substances will deteriorate the walking belt and cause excessive wear.

  • Page 8: Features Of The Console

    When the console is in the manual mode, the speed and incline of the treadmill can be changed with a touch of a button. As you exercise, the LED displays will provide continuous exercise feedback.
  • Page 9 If the key is pulled from the console, the power will automatically turn off. J. INCLINE Buttons—These buttons control the incline of the treadmill. Each time a button is pressed, the incline will change by 0.5%. The incline range is 1.5% to 10%.

  • Page 10: How To Use The Manual Mode

    HOW TO TURN ON THE POWER Attach the clip to the waistband of your clothes. Stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 8), and slide the clip onto the waistband of your clothes.
  • Page 11 Step onto the foot rails and press the STOP button. Next, change the incline of the treadmill to the lowest setting. The incline must be at the low- est setting when the treadmill is folded to the storage position or the treadmill will be dam- aged.
  • Page 12 HOW TO USE FAT BURN PROGRAMS AND AEROBIC PROGRAMS The six preset workout programs automatically control the speed and incline of the treadmill as they guide you through effective workouts. Follow the steps below to use a fat burn program or an aerobic program.

  • Page 13: How To Create Custom Programs

    Custom programs 1 and 2 are workout programs that you create. The programs control both the speed and the incline of the treadmill, and can be up to 40 minutes long. The programs are stored in memory and can be changed as many times as desired.

  • Page 14: How To Use Custom Programs

    CURRENT PERIOD column and the speed and incline of the treadmill will adjust to the sec- ond settings that you programmed previously. The program will continue in this way until the...
  • Page 15 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your CD player.
  • Page 16 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the LINE OUT jack on your stereo.
  • Page 17 Simply follow your personal trainer’s instructions. Note: If the TIME display is flashing, press the START button or the SPEED + button on the con- sole. The treadmill will not respond to a CD or video Adapter program when the TIME display is flashing.
  • Page 18 STOP button or remove the key and go to step 1 on page 17. Note: If the speed or incline of the treadmill does not change when a “chirp” is heard: • make sure that the iFIT.com indicator is lit and that the TIME display is not flashing.
  • Page 19 Our new internet site at www.iFIT.com allows you to access a selection of programs that interactively con- trol your treadmill to help you achieve your specific ex- ercise goals. In addition, you can play iFIT.com audio and video programs directly from the internet. By adding an optional iFIT.com module to the console,...
  • Page 20 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles per hour to kilometers per hour.

  • Page 21: How To Fold And Move The Treadmill

    2. Move your right hand to the position shown and hold the treadmill firmly. Hold the lock knob with your left hand and pull it to the side. Raise the treadmill until the lock knob is aligned with the catch. Slowly release the lock knob.
  • Page 22 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, slide the lock knob to the left. Pivot the treadmill down until the frame is past the lock pin.

  • Page 23: Trouble-Shooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 24 3 to 4 inches off the walking platform. Be care- ful to keep the walking belt centered. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is properly tightened.
  • Page 25 SOLUTION: a. With the key in the console, press one of the INCLINE buttons. While the incline is changing, remove the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level. This will recalibrate the incline system.

  • Page 26: Reebok University

    EEBOK NIVERSITY Reebok University was launched in 1993 to fulfill a vision to establish a “university without walls” that develops quality, researched, state-of-the-art fitness programming for the fitness industry throughout the world. Working with the world’s best professionals, Reebok University has created a host of original programs, such as Step Reebok ®...
  • Page 27 Several studies have reported that regular walking at moderate to brisk speeds appears to increase bone density. Specifically, Fradin and his colleagues that 70-year-old subjects who walked at least 30 min- utes per day had higher bone mineral content than subjects who walked less than 30 minutes per day.

  • Page 28: Exercise Guidelines

    For maximum fat burning, adjust the speed or incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 29: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 30: Part List

    Motor Belly Pan Belt Guide Screw Plastic Fastener Frame Belly Pan 12” Audio Wire Ground Screw Rear Foot Isolator Washer Isolator Nut RBTL10500 Key No. Qty. 51** R1200A Description Heart Rate Strap Roller Adj. Washer Rear Roller Adjustment Bolt Rear Endcap Frame...

  • Page 31: How To Order Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information: • The MODEL NUMBER of the product (RBTL10500) • The NAME of the product (REEBOK • The SERIAL NUMBER of the product (see the front cover of this manual) •...

  • Page 32: Limited Warranty

    IMITED ARRANTY WHAT IS COVERED—The entire REEBOK ® RBX 475s (“Product”) is warranted to be free of all defects in material and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser. HOW LONG IS IT COVERED—ICON Health &...
  • Page 33 —M RBTL10500 XPLODED RAWING ODEL R1200A...
  • Page 34 —M RBTL10500 XPLODED RAWING ODEL R1200A...
