OWNER'S/OPERATOR'S
MANUAL
POLE SAW
PSZ2460S
WARNING
The engine exhaust from this
product contains chemicals
known to the State of California to
cause cancer, birth defects or
other reproductive harm.
WARNING
Before using our products,
please read this manual carefully
to understand the proper use of
your unit.
This spark ignition system complies with
the Canadian standard ICES-002.
MODE D'EMPLOI
SCIE POLAIRE
AVERTISSEMENT
Les échappements du moteur de
ce produit contiennent des
produits chimiques connus par
l'Etat de Californie comme étant
responsables de cancers,
d'anomalies congénitales et
d'autres atteintes à l'appareil
reproducteur.
AVERTISSEMENT
Avant d'utiliser cette
ce produit
veuillez lire attentivement ce
manuel afin de bien comprendre le
bon fonctionnement de cet
appareil.
Ce système d'allumage par étincelle de véhicule
est conforme à la norme NMB-002 du Canada.
MANUAL DE
INSTRUCCIONES
SIERRA DE MANGO
ADVERTENCIA
Los gases de escape del motor de
este producto contienen
sustancias químicas conocidas
por el Estado de California como
causantes de cáncer,
malformaciones en recién nacidos
y otros problemas de
reproducción.
ADVERTENCIA
,
Antes de usar nuestros productos,
lea detenidamente este manual a
fin de familiarizarse con el uso
correcto de este aparato.
Este sistema de ignición por chispa de vehículo
es conforme con la norma ICES-002 del Canadá.
115 35 78-10 (003)
U
S
F
R
E
S
