PSZ2450S
848-A59-93A0 (909)
OWNER'S/OPERATOR'S
MANUAL
POLE SAW
WARNING
The engine exhaust from this
product contains chemicals
known to the State of California to
cause cancer, birth defects or
other reproductive harm.
WARNING
Before using our products,
please read this manual carefully
to understand the proper use of
your unit.
APPLICABLE SERIAL NUMBERS :
90200101 and up
PSZ2450S
U
S
US-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RedMax PSZ2450S
Summary of Contents for RedMax PSZ2450S
- Page 1 PSZ2450S PSZ2450S 848-A59-93A0 (909) OWNER'S/OPERATOR'S MANUAL POLE SAW WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products, please read this manual carefully to understand the proper use of your unit.
-
Page 2: Table Of Contents
PSZ2450S Contents US-2 SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 3: Parts Location
(9) Saw chain (10) Guide bar (11) Grip (12) Drive shaft housing (13) Sholder strap hanger (14) Throttle trigger (15) Stop switch (16) Throttle cable (when using RedMax genuine oil) Specifications are subject to change without notice. PSZ2450S (rpm) (rpm) US-3... -
Page 4: Warning Labels On The Machine
PSZ2450S 3. Warning labels on the machine ( 1 ) ( 2 ) ( 3 ) (1) Read owner's manual before operating this machine. (2) Wear head, eye and ear protection. (3) Warning! Danger of kickback. (4) Beware of thrown objects. -
Page 5: For Safe Operation
PSZ2450S ■ WORKING PLAN 1. You should never use the product when under the influence of alcohol, when... -
Page 6: Starting The Engine
If it continues to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized RedMax servicing dealer for repair. ■ USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer. -
Page 7: Handling Fuel
■ HANDLING FUEL 1. The engine of the RedMax product is designed to run on a mixed fuel which contains highly flammable gasoline. Never store cans of fuel or refill the tank of the... - Page 8 PSZ2450S 5. For safe operation • Never use a cracked or warped guide bar: replace it with a serviceable one and make sure it fits properly. • If a saw blade should bind fast in a cut, shut off the engine immediately. Push the branch or tree to ease the bind and free the blade.
-
Page 9: Set Up
■ BALANCE UNIT 1. Put on strap and attach unit to strap. 2. Depending on the working posture, slide clamp up or down until unit balances and the strap fits your body. PSZ2450S US-9... -
Page 10: Fuel And Chain Oil
• Poor quality gasolines or oils may damage sealing rings, fuel US-10 lines or fuel tank of the engine. • Failures caused by operating engines on gasoline with octane rating lower than 89 are not covered by the RedMax Two- Stroke engine warranty. WARNING • Alternative Fuels (Not Gasoline) -
Page 11: Chain Oil
Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel stabilizer is added. RedMax Air-Cooled "Max Life" Synthetic blend Premium two-stroke engine oil "Contains fuel stabilizer" and will automatically extend your gasoline/oil mixture life up to 60 days. -
Page 12: Operation
PSZ2450S 8. Operation ■ STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Feed fuel and chain oil into their respective tanks and tighten the caps securely. (OP1) (1) Fuel (2) Chain oil 2. Rest the unit on a flat, firm place. Keep... - Page 13 • Falling branches may fall onto the face or into the eyes, resulting in injuries, scratches, and cuts, and for this reason you should always be sure to wear a helmet and face protector when using your polesaw. PSZ2450S US-13...
-
Page 14: Maintenance
PSZ2450S 9. Maintenance Maintenance, replacement, or repair of the emission control device and systems may be performed by any non-road engine repair establishment or individual. ■ MAINTENANCE CHART System/compornent fuel leaks, fuel spillage fuel tank, air filter, fuel filter idle adjusting screw... -
Page 15: Spark Plug
Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type specified by RedMax. (MA11) • REPLACEMENT PLUG IS A .025 in 0.655mm CHAMPION RZ7C. - Page 16 PSZ2450S 9. Maintenance TIGHTENING TORQUE: 87–121 (in-lbs) (9.8–13.7 N.m.) ■ MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, stop using the machine and have it repaired immediately.
-
Page 17: Storage
➞ ➞ carbon is built-up ➞ ➞ clogged with dust ➞ ➞ clogged with dust PSZ2450S ACTION drain it and with correct fuel clean adjust to normal range clean/dry correct (GAP: 0.6 – 0.7 mm) retighten ACTION drain it and with correct fuel... - Page 18 As the small off-road engine owner, you should however be aware that the RedMax may deny you warranty coverage if your small off-road engine or a part has failed due to abuse, neglect, or improper maintenance or unapproved modifications.
- Page 19 Add-on or modified parts that are not exempted by CARB or EPA may not be used. The use of any non- exempted add-on or modified parts will be grounds for disallowing a warranty claim. RedMax will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
