( 2 ) GAIN (Video gain)
GAIN has three modes; AUTO, MANUAL, OFF.
Move the "
OFF. In the OFF mode, gain is fixed to 0dB.

(2. 1) Changing the setting in AUTO (AGC: Automatic gain control) mode

Move up and down
by pushing
MENU UP, DOWN
-- 2 GAIN --
MODE
MAX GAIN
(a) Changing the maximum gain
Move the "
1
2

(2. 2) Changing gain in MANUAL mode

Move up and down
by pushing
MENU UP, DOWN
-- 2 GAIN --
MODE
MANUAL
Move the "
1
2
Select the desired
value by pushing
DATA UP, DOWN
(FILE A)
AUTO
18dB
0dB
Select the desired
value by pushing
DATA UP, DOWN
(FILE A)
MANUAL
0dB
0dB
22
Gain mode AUTO, MANUAL, OFF
AGC maximum gain setting
0dB to 18dB (1dB step)
18dB
Gain mode AUTO, MANUAL, OFF
Manual gain setting
0dB to 18dB (1dB step)
18dB
