Summary of Contents for RCA VR663HF
- Page 1 OWNER’ S MODEL ‘ .,I( 1’ .$...
-
Page 2: Product Registration
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the VCR. Model No. VR663HF Serial No. -
Page 3: Table Of Contents
Attach Power Cord to VCR Insert Batteries in Remote Turn on TV and VCR Place Channels in VCR’ s Memory Add OI Erase Channels from VCR’ s Memory Use N/VCR Button Set the Time and Date Using the Remote Control... -
Page 4: Choosing A Hookup
It is the easier of the two and additional accessories may not be needed. The advanced hookup shows the VCR hooked up to a monitor/receiver (TV with audio and video jacks) using a signal splitter. This connection may improve the picture quality as well as convenience of operation. -
Page 5: Antenna 01 Cable System Without A Cable Box
A. Basic hookup. Use this hookup for a simple connection which requires fewer accessories. 1. Set the CH4 CH3 switch on back of VCR to either channel 3 or 4. You will tu,e the TV to this channel and use the NNCR button on remote to watch the VCR. -
Page 6: Cable System With Cable Box To Unscramble Au Channels
Basic hookup. this hookup for a simple connection which requires fewer accessories. 1. Set the CH4 CH3 switch on back of VCR to either channel 3 or 4. You will tune the TV to this channel and use the TVNCR button on remote to watch the VCR. -
Page 7: Cable System With Cable Box To Unscramble Pay Channels
Basic hookup. this hookup for a simple connection which requires fewer accessories. 1. Set the CH4 CH3 switch on back of VCR to either channel 3 or 4. You will tune the TV to this channel and use the NNCR button on remote to watch the “CR. -
Page 8: Connecting Two Vcrs For Copying Tapes
You will tune ttle recording “CR to this channel Playback “CR. to receive the signal from the 4. Plug in power cords of VCRs and TV. 5. Turn to page 8 for “Setting Up the VCR.” Option B Hookup. hookup for slightly improved copy this quality and more convenient operation - use of TVNCR button not required. -
Page 9: Connecting A Stereo Amplifier/Receiver
VCR, and TV. 4. Turn to page 25 for “Recording Audio Only.” You will select the line input (audio/video) the VCR to receive the audio signal born the ~lllplifiW/~K~iW. Play Back Stereo Tapes or Receive a Stereo Broadcast Through an Amplifier/Receiver... -
Page 10: Check Accessories With Vcr
6. Place channels in the VCR’ s memory (AutoProgram). Channels 2 through 13 are in the VCR’ s memory when you first hxn it on. Pressing CHANNEL up or down stops on these channels. channels available on your antenna or cable system, you must AutoProgram the VCR. -
Page 11: Add Oi Erase Channels From Vcr' S Memory
* Press 0 before single-digit numbers. Example: * Press CLEAR on the remote to change incorrect entries. D. Press PROG/VCR+ to start the clock and display the time in the VCR’ s display panel. from the VCR’ s memory. on the remote to see the VCR MAIN MENU on the D&is... -
Page 12: Compor
VCR when it has been seh~p. see page 12. VCR Function Buttons Press VCR1 (VCR2) to set remote to control the VCR to use the function buttons. Turns off VCR when remote is set to control the VCR. NNCR... -
Page 13: Tv Function Buttons
Select a channel over 99 by pressing the 100 button and then two number buttons for compatible TVs. PROGNCR+ Displays the VCR MAIN MENU or VCR PLUS men” on TV screen. CLEAR Resets time counter to 0:OO:OO when it is displayed. -
Page 14: Controlling A Vcr
Controlling a VCR The VCR’ s remote controls two compatible RCA VCRs with the VCR1 and VCR2 buttons. Most RCA VCRs automatically respond to VCR1 without being programmed. If you own two RCA VCRs, test them to see if VCR1 turns on both VCRs. If it does, then program the REMOTE CONT feature on this VCR to respond to VCR2 if you want to control VCRs separately. -
Page 15: Operating Instructions
The VCR will automatically rewind the tape if it reaches the end of the tape during playback. press POWER on the VCR or OFF on the remote and the VCR will turn off after rewinding. 8. Press STOP/EJECT on the VCR to eject the tape once it is completely rewound. -
Page 16: Using The Playback Feahmes
If streaks or bars appear, press SLOW . and then TRACKING . or . . 3. Press PLAY/PAUSE on the VCR or PAUSE (or PLAY) on the remote to return to playback. The VCR will automatically switch from pause to stop after a few minutes. -
Page 17: Time Search
Press CLEAR on the remote to clear an enh’ y 5. Press F.FWO to search forward. search in reverse. 6. The amount of tape time the VCR will search is displayed on the TV screen. 7. Press STOP/EJECT on the VCR or STOP on the remote to stop a search in progress. -
Page 18: Time Counter With Memory-Stop Feature
It helps to quickly the programs you taped. The time counter ejected from the VCR. For example, if a 30-minute program was recorded would: 1. Insert the pre-recorded tape. 2. Press DISPLAY twice to display 3. -
Page 19: Audio Play Feature
Using the Playback Features AUDIO PLAY (HIFl/MIX/LINEAR) The VCR has hvo separate audio recording systems - VHS Hi-Fi that records on separate left and right stereo channels and standard linear that records monaural sound. The same audio is recorded on both systems. The AUDIO PLAY feature lets you select the audio you play back. -
Page 20: Types Of Recordings
The VCR will automatically switch from pause to stop after a few minutes. Basic Recgrding - To make a recording Turn on the TV and tune it to the VCR viewing channel, either 3,4, or TV’ s video input channel. insert a tape with safety tab in place. The cassette-in indicator m Press VCR1 (VCRZ) to set remote to control VCR. -
Page 21: Recording Broadcast Stereo Tv Or Sap
Select STEREO to record stereo. Select SAP to record SAP. Select MONO if the stereo signal is not strong enough and too noisy for quality reception. record stereo broadcast Turn on the TV and tune it to the VCR viewing channel, either 3,4, or TV’ s video input. Insert a tape with safety tab in place. - Page 22 Recording While You’ re Away (VCR Plus+ Recording) VCR Plus+’ lets you record a program by entering a PlusCode’ number from your TV listing. Because each area has different cable. TV and broadcasting systems, some setup may be required before using VCR Plus+ for the first time.
- Page 23 Press two numbers on the remote to enter the output channel of your cable box. Press 0 before a single-digit number. If you connected your cable box to the VCR using the cable box’ s AUDIONIDEO INPUT on the remote to select the VIDEO OUT option.
-
Page 24: Recording While You' Re Away Vcr Plus+ Recording
Recording While You’ re Away (VCR Plus+ Recording) The VCR Plus+ and timer program features let you program the VCR to record up to eight different programs within a one year period. Before using VCR Plus+ to record a program, make sure that: * Cable box set up has been completed if you use a cable box. -
Page 25: Timer Recording
Recording While You’ re Away (Timer Recording) The VCR Plus+ and timer program features let you program the VCR to record up to eight different programs within a one year period. Before setting the timer, make sure that: * Cable box set up has been completed if you use a cable box. -
Page 26: Express Recording
Each press of RECORD on the VCR or REC/XPR on the remote increases the time from 30 minutes up to 4 hours. REC and the amount of time the VCR will record appears in the VCR’ s display panel. Additional... -
Page 27: Recording Audio Only
Recording Audio Only You can record audio only from an amplifier/receiver stereo audio, connect the VCR to a stereo TV or amplifier/receiver. audio only record Connect the audio equipment to the VCR. Turn it on and prepare it to play. -
Page 28: Using Two Vcrs For Copying Tapes
Using Dual Remote with AutoEditTM this VCR as the recording VCR and set it to respond to VCR2 on the remote as demikd on page 12. Use your other compatible VCR as the playback VCR which should respond to Follow steps 1 - 4 in “Operating... -
Page 29: Specifications
VCR Use a soft cloth or dusting attachment of your vacuum cleaner to dust your VCR. Remove dust from the ventilation holes on the top, back, sides, and bottom of the cabinet. Plastic surfaces are easily scratched and can be marred by alcohol and solvents. -
Page 30: Location Of Controls
VCR or camcorder, when it is connected to these jacks. Use the INPUT button on the remote to display L in the VCR’ s display panel and VIDEO IN on the TV screen. VIDEO OUT and AUDIO (R and L) OUT Jacks... -
Page 31: Display Panel
PLAY (HIFI/MWLINEAR) MIX in the SET UP VCR menu. Cassette-in Indicator ( m Lights when a tape is in the VCR. Tape Speed Indicators (SP, LP, or SLP) Press SPEED on remote to change. STEREO Indicator The STEREO indicator lights when the station... - Page 32 ‘ BVouble Checks Sometimes problems can be easily solved by checking a few basic things. Check below before you call for help or take your VCR to an Authorized RCA VCR Servicenteer. Trouble __-._.-,_ ,,,..,.,. ,.,. _,_ .,,,.,, .,., ,., ,,~.,...
-
Page 33: Trouble Checks
Time counter display appears in VCR’ s display panel. Press DISPLAY on remote. VCR is removing tape from heads. This is normal. The head cylinder inside the VCR will continue to rotate for a few minutes after you put the VCR in the stop mode. ,.,., .,, * Check antenna connections. -
Page 34: Limited Warranty
What we will do: Pay any Authorized RCA VCR Servicenter the labor charges to repair your VCR. Pay any Authorized RCA VCR Servicenter for the new or, at our option, rebuilt replacement parts required to repair youx VCR. How you get service: Take your VCR to any Authorized RCA VCR Servicenter. -
Page 35: Index
Index Y..~.~ .2,6 TWO VCRS..~~ ... IN FROM ANT connecfor ..2,3-6.28... - Page 36 Attention: Canadian Operations P.O. Box 0944 Indianapolis. IN 46206-0944 If your VCR needs service, please contact your dealer or the nearest Servicema from tbe yellow pages. Please do not send any pmducts to tbe Indianapolis address listed in this manual or on the carton.
