OWNER'S MANUAL
26/32" TFT LCD DIGITAL TV WITH DVD PLAYER
L26HD32D
L32HD32D
This device contains a digital television tuner, so it should receive digital over the air TV programming, with a
suitable antenna, after the end of full-power analog TV broadcasting in the United States on February 17, 2009.
Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive over the air digital
programming, but should continue to work as before for other purposes (e.g., for watching low-power TV stations
still broadcasting in analog, watching pre-recorded movies, or playing video games). When a Converter is used
with an older television receiver, a signal splitter might be necessary to continue to receive low-power analog
broadcasts via an antenna. For more information, please see www.DTV.gov. For information on the TV Converter
program, and on government subsidized coupons that may be used toward the purchase of one, see www.
dtv2009.gov, or call the NTIA at 1-888-DTV-2009.
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
When shipped from the factory, the Signal Type option is set to the "Cable" (Cable Television) mode.
If not using Cable TV, set this menu option to the "Air" position.
Before operating the unit, please read this manual thoroughly.
51F0101B_eng.indd 1
Digital Television Transition Notice
ATTENTION
AIR/CABLE MODE SELECTION
4/4/08 10:04:02 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L26HD32D and is the answer not in the manual?

Questions and answers

Summary of Contents for RCA L26HD32D

  • Page 1 OWNER’S MANUAL 26/32” TFT LCD DIGITAL TV WITH DVD PLAYER L26HD32D L32HD32D Digital Television Transition Notice This device contains a digital television tuner, so it should receive digital over the air TV programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the United States on February 17, 2009.
  • Page 2 Disposal should be in compliance with local, state or federal laws. Product Registration Please fill out the product registration card (packed separately) and return it immediately. For US customers: Your RCA Consumer Electronics product may also be registered at www.rca.com/television. Registering this product allows us to contact you if needed.
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a clean dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 20) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards. 21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.
  • Page 5: Safety Precautions

    The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 10 cm (4 inches) free space around the entire unit. Notes when mounting the LCD TV/DVD on a wall If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/DVD for advice, and have the equipment professionally installed.
  • Page 6: Features

    Features LCD color TV With DVD/CD player Unique space saving design combines a 26/32” LCD color TV and a DVD/CD player. A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a DVD exceeds other software.
  • Page 7: Table Of Contents

    Before using your unit IMPORTANT SAFETY INSTRUCTIONS ...3 SAFETY PRECAUTIONS ...5 IMPORTANT NOTICE ...5 Features ...6 Contents ...7 Disc...8 Location of controls ...9 Remote control ...11 Power source ...12 Antenna connections ...13 Cable TV connections ...14 TV operation Setting the on-screen language ...15 Memorizing channels ...15 TV operation ...16 Labeling channels ...17...
  • Page 8: Disc

    Disc Playable discs Disc type and logo mark DVD Video CD-DA The following discs are also available. • DVD-R/RW discs of DVD video format. • CD-R/RW discs of MP3/WMA/JPEG. Region Number Region number (Regional restriction code) is built-in to the unit and DVD video discs. Region number “1”...
  • Page 9: Location Of Controls

    Front Remote sensor Left side DISC slot To display the menu screen. Press MENU button to display the menu screen. CHANNEL / buttons, VOLUME +/– buttons and INPUT/ENTER button can be used to select the desired setting during the menu screen operations. 51F0101A_eng.indd 9 Location of controls POWER indicator...
  • Page 10 Location of controls Rear side VAR (VARIABLE) AUDIO OUT jacks HDMI 1/DVI IN jack AC INPUT PC/DVI AUDIO IN jack AC INPUT jack (VIDEO/S-VIDEO/AUDIO(L/R)) 51F0101A_eng.indd 10 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING:SHOCK HAZARD-DO NOT OPEN. AVIS:RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR AC INPUT COAXIAL DIGITAL AUDIO OUT jack PC MONITOR IN jack...
  • Page 11: Remote Control

    ATTENTION If you purchase a universal remote from a local retailer, please contact the remote manufacturer for the correct programming code. 51F0101A_eng.indd 11 Remote control POWER Power On/Off DISPLAY/– Call TV information Call DVD information Input “–” for digital channels TV/DVD Switch between TV/AV and DVD (EJECT)
  • Page 12: Power Source

    Remote control Inserting Batteries Open the battery compartment cover in the direction of the arrow. Operation • Aim the remote control at the remote sensor and press control buttons to operate. • Operate the remote control within a 30° angle on either side of the remote sensor, up to a distance of approximately 15 feet.
  • Page 13: Antenna Connections

    If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 14 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Antenna Jack Antenna...
  • Page 14: Cable Tv Connections

    Cable TV connections This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.
  • Page 15: Setting The On-Screen Language

    Setting the on-screen language You can choose from three different languages (English, French and Spanish) for the on-screen displays. Select the language you prefer first, then proceed with the other menu options. To turn on the TV, press POWER. (POWER indicator on the front of the unit changes green.
  • Page 16: Tv Operation

    NOTE: • Memorizing channels is best accomplished during evening “PRIMETIME” hours, as more stations are broadcasting digital signals. Memorizing channels can only be accomplished while a station is broadcasting a digital signal to set that channel into memory. • If you are unsure of the digital channels available in your area, you may visit www.antennaweb.org to receive a list based on your address or zip code.
  • Page 17: Labeling Channels

    VHF/UHF/CABLE CHANNELS Cable 2-13 2-13 STD/HRC/IRC 14-69 14-36 (A) (W) 37-59 (AA) (WW) 60-85 (AAA) (ZZZ) 86-94 (86) (94) 95-99 (A-5) (A-1) 100-125 (100) (125) (5A) NOTE: • If a channel with no broadcast is selected, the sound will automatically be muted. •...
  • Page 18: Labeling Video Inputs

    Press to select “Ch Label”, then press or ENTER. The “Ch Label” menu will appear. Press to select a channel you want to label, then press . Ch Label Channel Number 15-1 Ch Label Label Clear >> : Select : Adjust Press repeatedly until the character you want appears in the first space.
  • Page 19 Press to select “V-Chip”, then press to select “On” . Press to select “V-Chip Set”, then press or ENTER. The V-Chip Set Menu appears. Press to select which rating will be used, then press or ENTER. Each rating below will appear.
  • Page 20: Closed Caption

    Closed Caption WHAT IS CLOSED CAPTIONING? This television has the capability to decode and display Closed Captioned television programs. Closed Captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language. Captions: This Closed Caption Mode will display text on the screen in English or another language.
  • Page 21: Adjusting The Picture Preference

    Press EXIT/CANCEL to return to the normal screen. NOTE: • You cannot set both “Text Color” and “Background Color” as a same color. • You cannot set both “Text Opacity” and “Background Opacity” to “Transparent”. Adjusting the picture preference You can select four picture modes—Sports, Standard, Movie and Memory—as described in the following table: Press SETUP/TV MENU in the TV mode.
  • Page 22: Setting The Picture Size

    Press EXIT/CANCEL to return to the normal screen. Setting the picture size You can view 480i and 480p format programs in a variety of picture sizes— Natural, Cinema Wide1, Cinema Wide2, Cinema Wide3 and Full. Selecting the picture size Press SETUP/TV MENU in the TV mode. The TV menu screen will appear.
  • Page 23: Picture Control Adjustment In The Pc Mode

    Picture Picture Setting >> Picture Preference Sports Picture Size >> Film Mode PC Setting >> : Select : Adjust Press EXIT/CANCEL to return to the normal screen. Picture control adjustment in the PC mode You can adjust to optimize the performance of the TV in the PC mode.
  • Page 24: Selecting The Audio Language

    Press SETUP/TV MENU in the TV mode. The TV menu screen will appear. Press to select “Audio”, then press ENTER. Press to select “MTS”, then press to select “Stereo”. Audio Bass Treble Balance Stereo Audio Language No Info. HDMI1 Audio HDMI Speakers : Select...
  • Page 25: Setting The Auto Shut Off

    Setup Closed Caption >> Language English Video Label >> Backlight Auto Shut Off Reset >> : Select : Adjust Press to adjust the setting. Press EXIT/CANCEL to return to the normal screen. Setting the Auto Shut Off If the Auto Shut Off feature is On, a station being viewed stops broadcasting and the TV is not operated, the TV will automatically shut itself off after 15 minutes.
  • Page 26: Playback Procedure

    Playback procedure Press TV/DVD to select DVD mode. Place the disc in the disc slot with the label side facing forward. (If the disc has a label.) Hold the disc without touching either of its surfaces, align it with the guides, and place it in position.
  • Page 27: Mp3/Wma/Jpeg And Audio Cd Playback

    MP3/WMA/JPEG and Audio CD playback This player can play back MP3/WMA/JPEG-data which has been recorded on CD-R or CD-RW. To produce MP3/WMA/JPEG-data, you need a Windows-PC with CD-ROM drive and MP3/WMA/ JPEG-encoding software (not supplied). The Apple-HFS-System cannot be played. MP3/WMA/JPEG CD information Limitations on MP3/WMA/JPEG CD playback •...
  • Page 28: Setting The Jpeg Interval

    JPEG playback: In the file browser, press / to select the desired JPEG file. To display a thumbnail list, press DVD MENU. Press / / / to select the desired file. (To return to the file browser, press TOP MENU.) /Picture-01.JPG Picture-01 Select Files...
  • Page 29: Repeat Playback (Cd)

    Folder-1 Edit Mode Folder-2 Program View MP3-1 Add To Program MP3-2 MP3-3 WMA-1 JPEG Preview WMA-2 WMA-3 Press / to select “Program View”, then press ENTER. Program View shows only the programmed files that you have added in Step 2. Folder-1 MP3-1 Edit Mode...
  • Page 30: Repeat Playback

    Press ENTER. • Playback starts. • When you change the title, playback starts from Chapter 1 of the selected title. • Some discs may not work in the above operation. Repeat playback Title, Chapter Playback: Press PLAY MODE during playback or stop mode.
  • Page 31: Subtitles

    Press AUDIO during playback. The current soundtrack language will appear. 1/2 Eng Dolby Digital Press AUDIO repeatedly until the desired language is selected. The on-screen display will disappear after a few seconds. NOTE: • If the desired language is not heard after pressing AUDIO several times, the language is not recorded on the disc.
  • Page 32: Setting The Language

    Setting the language You can select the language of “Menu”, “Subtitle” and “Audio” if more than one languages are recorded onto the disc. Press SETUP/TV MENU in the stop mode. Press to select option, then press / or ENTER. Press to select desired option, then press or ENTER.
  • Page 33: Night Mode

    Press SETUP/TV MENU in the stop mode or No Disc. Press to select option, then press / or ENTER. Press to select “Picture Mode”, then press or ENTER. Press to select your desired picture mode, then press ENTER. TV Screen : 16:9 Display : On...
  • Page 34: Temporary Disabling Of Rating Level By Dvd Disc

    Parental : Off Password : Change Enter Password The parental level list will appear. Press select the level 1 to level 8. The limitation will be more severe as the level number is lowered. Then press ENTER. Parental Password • Level Off : The parental control setting does not function.
  • Page 35: Language Code List

    Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” (see page 32). Language Name Code Language Name Abkhazian 1112 Fiji Afar 1111 Finnish Afrikaans 1116 French Albanian 2927 Frisian Amharic 1123 Galician Arabic 1128 Georgian Armenian 1835 German Assamese 1129 Greek...
  • Page 36: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to this unit is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. To connect the LCD TV/DVD to a VCR Rear of the unit To LINE 2 VIDEO/AUDIO IN...
  • Page 37 Connections to other equipment To connect a HDMI or a DVI device to the unit The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital video from a DVI device. When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate analog audio cords required.
  • Page 38 Connections to other equipment To connect an audio system This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the TV’s remote control. To control the audio, turn on the unit and the stereo amplifier, and turn off the unit’s built-in speakers (see “Turning off the built-in speakers”...
  • Page 39: Reception Disturbances

    Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.
  • Page 40: Problems And Troubleshooting

    Problems and troubleshooting Use the following check list for troubleshooting when you have problems with your TV/DVD. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POWER •...
  • Page 41 Problems and troubleshooting SYMPTOMS • No disc is inserted. Playback doesn’t start. • The disc may be dirty. Clean up the disc. • The unit cannot play CD-ROMs, etc. No picture. • TV/DVD selector is not set correctly. • Check the input selector of the amplifier is set properly. No sound.
  • Page 42: Specifications

    95-99 (A-5)-(A-1) 100-125 (100)-(125) 01 (5A) Inputs S-Video: Y-Input:1.0 V (p-p), 75 ohms C-Input:0.3 V (p-p), 75 ohms Video: (RCA) 1 V p-p/75 ohms Audio: (RCA) –8 dBm/50K ohms Component video: HDMI: HDMI compliant (type A connector) HDCP compliant E-EDID compliant...
  • Page 43: Limited Warranty

    • What we will do: • At TTE’s discretion, pay an Authorized RCA Service Center for both labor charges and parts to repair your television, or replace your television with a new or refurbished/remanufactured unit. • See “How to get service”...
  • Page 44 Product Registration: • Please complete and mail the Product Registration Card packed with your unit or register on-line at www.rca. com/television. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.
