Habey HB131 User Manual

Mini-itx
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HABEY HB131
Mini-ITX Motherboard
User Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HB131 and is the answer not in the manual?

Questions and answers

Related Manuals for Habey HB131

Summary of Contents for Habey HB131

  • Page 1 HABEY HB131 Mini-ITX Motherboard User Manual V1.0...

  • Page 2: Safety Instructions

    Safety Instructions 1．Please read this manual carefully before using this product. 2．Put all unused or uninstalled boards/cards in a static dissipative surface or static shielding bag. 3．Always ground yourself to remove any static discharge before touching the board , to place your hands on grounding metal object for a while or wear a grounding wrist strap at all times.

  • Page 3: Table Of Contents

    Contents Chapter 1 Product Introduction......................1 1.1 Specifications .........................1 Chapter 2 Installation Instructions ....................3 2.1 Interfaces Location & Dimension ..................3 2.2 Installation Steps.......................3 2.3 Install Memory........................4 2.4 Jumper Settings ........................4 2.4.1 CMOS Clear/Hold Jumper Setting（JCC） ............4 2.4.2 Hardware Switch for System Auto Boot upon Power On（JAT）......6 2.4.3 COM2 Jumper Setting（J1，J2）................6 2.4.4 LVDS Rated Voltage Select Jumper（J8）............7 2.5 Interfaces Description.......................8...
  • Page 4 AMI BIOS Description......................25 BIOS Settings........................25 3.1 Main Menu ........................26 3.2 Advanced Menu ......................27 3.2.1 ACPI Settings .......................27 3.2.2 APM Configuration ....................28 3.2.3 CPU Configuration ....................29 3.2.4 SATA Configuration ....................30 3.2.5 USB Configuration....................31 3.2.6 Supper IO Configuration ..................33 3.2.7 H/W Monitor......................35 3.2.8 Serial Port Console Redirection................36 3.3 Chipset Menu........................36 3.3.1 North Bridge ......................37...

  • Page 5: Chapter 1 Product Introduction

    Chapter 1. Product Introduction...

  • Page 6: Specifications

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Chapter 1 Product Introduction 1.1 Specifications Form Factor ● Standard Mini-ITX Motherboard Dimension ●170mm×170mm（L×W） ● Onboard Cedar Trail- D Chipset ●Intel NM10 Display ●GPU: VGA + LVDS ●VGA: 1x standard DB15 VGA, resolution up to 1920×1200@60Hz ●LVDS: 1x standard single channel 18/24bit LVDS.
  • Page 7 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard ● External 4x standard USB 2.0 ports; two 2×5Pin USB 2.54 header, to be converted to standard 4x USB 2.0 ports. ● Adopt W83627DHG-P I/O Chip ●6x serial ports: 1x DB9 serial ports and five 2*5PIN Header. COM1_COM6 support RS232.

  • Page 8: Chapter 2 Installation Instructions

    Chapter 2. Installation Instructions...

  • Page 9: Interfaces Location & Dimension

    Intel Cedar Trail Powered Mini-ITX Motherboard Chapter 2 Installation Instructions 2.1 Interfaces Location & Dimension Following picture illustrates the interfaces location and dimension of board HB131. Please take care of some components during the installation. Improper installation may leads to system failure.

  • Page 10: Install Memory

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 4．Connect all signal lines, cables, control panel circuit and power supply unit. 5．Start the computer and complete BIOS Settings. Key components of this motherboard are Integrated circuit, and these components could be easily damaged by electrostatic influence. So, before installing this unit, please always keep the following precautions in mind: 1．Hold the board by edges and don’t touch any components, plugs or socket pins.
  • Page 11 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard with Pin2-3 connected. （3）Start the computer, then press “Del” to enter BIOS setting and reload optimal defaults. （4）Save and Exit JCC： Setting Clear CMOS, BIOS back to factory default Normal status, system default...

  • Page 12: Hardware Switch For System Auto Boot Upon Power On（Jat

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 2.4.2 Hardware Switch for System Auto Boot upon Power ON（JAT） JAT: Setting Open Disable auto boot Close Enable Auto Boot 2.4.3 COM2 Jumper Setting（J1, J2） J1, J2 jumpers are used to configure COM2 transmission mode. COM2 supports...

  • Page 13: Lvds Rated Voltage Select Jumper（J8

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard COM2 RS232（default） COM2 RS485 1-3 2-4 3-5 4-6 3-4 5-6 2.4.4 LVDS Rated Voltage Select Jumper（J8） Please first check the LVDS rated work voltage before using it.

  • Page 14: Interfaces Description

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Setting 3.3V 2.5 Interfaces Description Please read this manual carefully before installing any external connectors, in case of any damage to the motherboard! 2.5.1 SATA Ports（SATA1, SATA2, PWR_OUT） Board provides 2x standard 7 Pin SATA ports. One 5Pin SATA_PWR interface（PWR_OUT）to...
  • Page 15 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard SATA: Signal Name PWR_OUT: Signal Name +12V...

  • Page 16: Serial Ports（Com1, Com2-Com6

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard VCC3 Note: SATA2 & MINIPCI SSD are alternative. If MINIPCIE port supports SSD, then SATA2 port will be disabled. System defaults [SATA2] port is enabled, MINIPCIE SSD disabled. 2.5.2 Serial Ports（COM1, COM2-COM6）...

  • Page 17: Display Interfaces（Vga, Lvds, Jvga

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard COM2_COM6: Signal Name Signal Name SOUT PIN10 COM2( RS232/RS485), Pins defined as below: RS232（Default） RS485 DATA- DATA+ PIN10 PIN10 Note: PIN10 define can select 12V, 5V or GND. 12V / 5V is provided via J9 jumper.
  • Page 18 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard JVGA LVDS VGA: Signal Name Signal Name Signal Name GREEN BLUE HSYNC VSYNC LVDS: Signal Name Signal Name VDD_PANEL VDD_PANEL LVDS_TX0_DN LVDS_DDC_DATA LVDS_TX0_DP LVDS_DDC_CLK LVDS_TX1_DN LVDS_CLK_DN LVDS_TX1_DP LVDS_CLK_DP LVDS_TX2_DN LVDS_TX3_DN...

  • Page 19: Lvds Backlight Control Interface（J5, J8

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard LVDS_TX2_DP LVDS_TX3_DP JVGA: Signal Name Signal Name GREEN BLUE HSYNC VSYNC VGA_PIN5 VGA_SCL_R 2.5.4 LVDS Backlight Control Interface（J5, J8） Signal Name +12V BKLT_EN BKLT_CTRL...
  • Page 20 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard For J8 definition, please refer to Chapter 2-section 2.4.4 LVDS rated voltage select jumper setting. 2.5.5 LAN_USB （USB_LAN1, USB_LAN2, USB56, USB78， ） External USB & LAN ports, two separate sockets provide 2x standard USB 2.0 ports and 1x standard RJ45 LAN port.

  • Page 21: Keyboard And Mouse Interface（Kbms

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Signal Name Signal Name USBD_N5 USBD_P5 USBD_P6 USBD_N6 USB_78: Signal Name Signal Name USBD_N7 USBD_P7 USBD_P8 USBD_N8 Note: USB7 port and MINIPCIE (alternative). If MINIPCIE uses USB7 interface, then the USB7Pin is disabled. System defaults USB78 is enabled, but MINIPCIE USB function is disabled.

  • Page 22: Gpio（Jgp

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard KB/MS PS/2 KBMS: Signal Name Signal Name VCC5 MS_CLK MS_DATA KB_DATA KB_CLK VCC5 2.5.7 GPIO（JGP） General purpose Input/Output Port, 8bit GPIO. One 2×5Pin header.

  • Page 23: Power Interface（Atx

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard GPIO: Signal Name Signal Name SGPI06 SGPI07 SGPI033 SGPI034 SGPI038 SGPI033 SGPI039 GPIO26 2.5.8 Power Interface （ATX） Board provides one standard ATX 20Pin Power Interface.

  • Page 24: Fan Interface（Cpu_Fan

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard ATX: Signal Name Signal Name +3.3V +3.3V +3.3V -12V PS-ON PW-OK +5V SB +12V 2.5.9 FAN Interface （CPU_FAN） Board provides one CPU_FAN interface. Keep the following two points in mind when using this...

  • Page 25: Jlpc Interface（Jlpc

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard (1)FAN Current ≤350mA（4.2W, 12V） (2) Pls confirm if the FAN cable matches the socket cable. Power cable（red） is in the middle. GND （black） & FAN speed pulse signal line （other color） .Recommend to use Fans with speed detection function.

  • Page 26: Audio（Jack_Hda, Fp_Audio

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard JLPC: Signal Name Signal Name CLK_LPC LFRAME_N CLK_LPC_48M LPC_RST# LPC_AD3 LPC_AD2 VCC3 LPC_AD1 LPC_AD0 SMB_CLK SMB_DATA 3.3VSB SIO_SERIRQ NC(预留 A20GATE) PM_SUS_STAT# LDRQ_1 2.5.11 Audio（JACK_HDA, FP_AUDIO） Board provides one set Audio interface. The green one is Line-out. The red one is Mic-in.

  • Page 27: Parallel Port（Lpt)

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard FP_AUDIO FP_AUDIO: Signal Name Signal Name MIC2*L AGND MIC2*R LINE1*L LINE2*R LINE1*R AGND LINE2*L AGND 2.5.12 Parallel Port（LPT) Board provides one standard parallel port.

  • Page 28: Front Panel Connector（Jfp

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard LPT: Signal Name Signal Name LPT_STB# LPT_AFD# LPT_PDQ0 LPT_ERR# LPT_PDQ1 LPT_INIT# LPT_PDQ2 LPT_SLIN# LPT_PDQ3 LPT_PDQ4 LPT_PDQ5 LPT_PDQ6 LPT_BUSY LPT_PDQ7 LPT_PE LPT_ACK# LPT_SLCT 2.5.13 Front Panel Connector （JFP） One 2×5Pin Front panel header, to connect the function buttons and LED lamps on the front...
  • Page 29 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard JFP: Signal Name Signal Name POWER LED+ POWER LED- HD LED+ HD LED- BUZZDATA- RESET BUTTON POWER BUTTON Please follow the table below to connect, pay attention to the anode (+) and cathode (-), otherwise, some function can not be realized.

  • Page 30: Expansion Interface（Pci, Mini_Pcie)

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 1）System power LED pins (pin1, pin2 for PWLED) Connect system power LED cable with these pins. （ pin 1 is LED anode） When system is power on, power LED is on；when system is power off, power LED is off.

  • Page 31: Chapter 3 Bios Setup

    Chapter 3. BIOS SETUP...

  • Page 32: Ami Bios Description

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Chapter 3 BIOS SETUP AMI BIOS Flash BIOS functions as a bridge connecting hardware and operating system. Hardware and software are upgrading all the time, so when your system goes wrong, for example, your system can not support the newest CPU, you need to upgrade BIOS to keep up with the latest technology.

  • Page 33: Main Menu

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 2. When system pops out the prompt "Press <Del> to enter setup" , please press <Del> key to enter BIOS setup interface. 3. Use the “←↑→↓” to select the option which your want to modify, press <Enter> to go to the sub-menu.

  • Page 34: Advanced Menu

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard System Date System Date Format: Week / Month/ Day/ Year 3.2 Advanced Menu Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Legacy OpROM Support Enabled or Disabled Boot Option Launch LAN1 PXE OpROM [Disabled] for Legacy Network Devices.
  • Page 35 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard F9：Optimized Defaults F10：Save&Exit ESC：Exit Version 2.14.1219. Copyright（C）2011 American Megatrends，Inc. ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. S1（CPU Stop Clock）:CPU stops working while other equipments are still power up.
  • Page 36 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.2.3 CPU Configuration Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc CPU Configuration Enabled for Windows XP and Linux （OS optimized for Hyper-Threading Technology） Processor Type Intel(R) Atom(TM) and Disabled for other OS（OS...
  • Page 37 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard generation CPU by Intel, which can help reduce system exposure to viruses and malicious code. EDB allows the processor to classify areas in memory where application code can or cannot execute. To use Execute Disable Bit you must have Windows XP SP2 operating system to support this function.
  • Page 38 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Version 2.14.1219. Copyright（C）2011 American Megatrends，Inc. Serial-ATA Controller（S） Enable or disable Serial-ATA controller. SATA Mode To setup SATA mode: [AHCI] or traditional [IDE]. Serial ATA Port1/2 To enable or disable the two ports (SATA & CF) under AHCI mode.
  • Page 39 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard →←：Select Screen ↑↓：Select Item UHCI #1 (ports 0 and 1) [Enabled] Enter：Select UHCI #2 (ports 2 and 1) [Enabled] +/-：Change Opt. UHCI #3 (ports 4 and 1) [Enabled] F1：General Help UHCI #4 (ports 6 and 1) [Enabled] F9：Optimized Defaults...

  • Page 40: Supper Io Configuration

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.2.6 Supper IO Configuration Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Super IO Configuration Set Parameters of Parallel Parallel Port Configuration Port (LPT/LPTE) →←：Select Screen Serial Port 1 Configuration ↑↓：Select Item...
  • Page 41 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Device Setting（Read Only） Device setting: parallel port IRQ and Address. Change Setting Change parallel port setting, including its IRQ & Address. Recommend to select default setting [Auto]. Device Mode Setup parallel device mode, including [Standard],[EPP],[ECP], [ECP+EPP], etc.

  • Page 42: H/W Monitor

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Change Setting Change serial port setting, including its IRQ and Base Address. Recommend to select the default setting [Auto]. Serial Port 2/3/4/5/6 Configuration follows the steps mentioned above 3.2.7 H/W Monitor Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc...

  • Page 43: Serial Port Console Redirection

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.2.8 Serial Port Console Redirection Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc COM1 Console Redirection Enable or Console Redirection [Disabled] Disable. Console Redirection Settings →←：Select Screen Serial Port for Out-of-Band Management/ ↑↓：Select Item...
  • Page 44 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.3.1 North Bridge Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Boot Display Device [VBIOS Default] Select the video Device which will Active LFP [ LVDS] be activated during POST. Flat Panel Type...
  • Page 45 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.3.2 South Bridge Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Audio Controller [Enabled] Audio Controller LAN1 Controller [Enabled] →←：Select Screen LAN2 Controller [Enabled] ↑↓：Select Item Enter：Select Restore AC Power Loss [Power On] +/-：Change Opt.

  • Page 46: Boot Menu

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.4 Boot Menu Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Boot Configuration Number of seconds to wait for setup activation key. 65535(0× Setup Prompt Timeout Bootup Numlock State [On] FFFF) means indefinite waiting.

  • Page 47: Security Menu

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Hard Drive BBS Priorities This option contains HDDs that can be used as boot device. If multiple HDDs in this option, priority should set for these HDDs, then the prior one will show in Boot Option #1.

  • Page 48: Save & Exit Menu

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard 3.6 Save & Exit Menu Aptio Setup Utility - Copyright (C) 2011 American Megatrends,Inc Load Defaults Restore/Load Default values for all Save Changes and Exit the setup options. Discard Changes and Exit →←：Select Screen...

  • Page 49: Appendix

    Appendix...

  • Page 50: Appendix 1: Watchdog Programming Guide

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Appendix Appendix 1: Watchdog Programming Guide watchdog reference code（ASM） -------------------------------------------------------------------------------------------------------------- Set the port to realize watchdog function through DEBUG order, so that it can carry out Watchdog Timer’s various functions. Port Instructions: void main() int indexp = 0x2e,datap = 0x2f;...

  • Page 51: Appendix 2: Irq & System Memory Map,1St Mb Memory Map

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Appendix 2: IRQ & System Memory Map,1st MB Memory Map IRQ： Priority Interrupt# Interrupt source Parity error detected System timer Available Interrupt from controller 2 (cascade) System CMOS/real time clock Microsoft ACPI-Compliant System...
  • Page 52 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard DFD00000 – DFD03FFF Realtek PCIe GBE Familly Controller DFD00000 – DFDFFFFF Intel (R) N10/ICH7 Family PCI Express Root Port – 27D2 DFD04000 – DFD04FFF Realtek PCIe GBE Familly Controller DFE00000 – DFE03FFF Realtek PCIe GBE Familly Controller #2 DFE00000 –...

  • Page 53: Appendix 3: Glossary

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Appendix 3: Glossary ACPI Advanced Configuration and Power Management。ACPI specifications allow O/S to control most power of the computer and its add-ons BIOS Basic input/output system. It is a kind of software including all in/out control code interface in PC.
  • Page 54 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard memory bus width. DRAM Dynamic Random Access Memorizer. It’s a normal type of memory often with a transistor and a capacitance to store 1 bit. With the development of the technology, more and more types of DRAM with different specifications exist in computer applications.
  • Page 55 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard normal situation and work well. PS/2 A keyboard & mouse connective interface specification developed by IBM.PS/2 is a DIN interface with only 6PIN; it also can connect other devices, like modem It is the Universal Serial Bus for short. A hardware interface adapts to low speed peripherals, and is always used to connect keyboard, mouse etc.

  • Page 56: Appendix 4: Install Driver

    HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard Appendix 4: Install Driver Please install the driver as per the following steps: Insert the programmed disk into CD-ROM, so installation of the driver can be made either automatically or manually. Now manually installation instructions are given as below. (take...
  • Page 57 HABEY HB131 Intel Cedar Trail Powered Mini-ITX Motherboard For more information, please visit WWW.norco-group.com The product information in this user manual is subject to change without prior notice. NORCO reserves the right to revise and to explain finally.
