RS2120i EN
27/3/07
It is important to read this instruction book prior to using your new product for the first time.
Nous vous recommandons de lire ce manuel d'instructions avant d'utiliser votre nouveau produit pour la première fois.
Es importante leer este manual antes de usar por vez primera su euipo.
11:04 AM
Page 3
Sleep
CD
CD
user manual
guide de l'utilisateur
manual de usuario
RS2120i
iPod not included.
iPod non inclus.
iPod no incluido.

Advertisement

   Related Manuals for RCA 5643738A

   Summary of Contents for RCA 5643738A

  • Page 1

    RS2120i EN 27/3/07 11:04 AM It is important to read this instruction book prior to using your new product for the first time. Nous vous recommandons de lire ce manuel d’instructions avant d’utiliser votre nouveau produit pour la première fois. Es importante leer este manual antes de usar por vez primera su euipo.

  • Page 2: Fcc Information

    RS2120i EN 27/3/07 11:04 AM FCC Information FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Important Safety Instructions

    RS2120i EN 27/3/07 11:04 AM Important Safety Instructions Please read and save for future reference Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. •...

  • Page 4: Important Information

    RS2120i EN 27/3/07 11:04 AM Important Information Technical Specification Product: Audio System Brand: RCA Model: RS2120i Electrical Consumption: Power Supply: 120V~60Hz Power consumption: 110 Watts Importer Comercializadora Thomson de México, S.A. de C.V. Álvaro Obregón No. 151. Piso 13. Col. Roma. Delegación Cuauhtémoc C.P.

  • Page 5

    RS2120i EN 27/3/07 11:04 AM Please Respect the Environment! Please help protect the environment by recycling or disposing of batteries according to federal, state, and local regulations. Don’t Infringe This product should only be used for the purposes for which it is sold, that is, entertainment, violating no copyright law.

  • Page 6: Table Of Contents

    RS2120i EN 27/3/07 11:04 AM Contents Getting Started Content of Box Connections General Controls Main Unit Remote Control .....5 Display and Settings Setting the Clock/Timer Sleep Mode Sound Features...

  • Page 7: Getting Started

    RS2120i EN 24/4/07 11:15 AM Getting Started Content of Box Sleep one main unit one AM loop antenna Connections of Antennas and Speakers 1. AUX IN. 2. AM loop antenna jack. 3. FM pigtail antenna. 4. Main speaker jacks. 5. iPod dock socket. Page 9 two main speakers one iPod dock and...

  • Page 8: Ipod Compatibility

    RS2120i EN 27/3/07 11:04 AM Getting Started Installation To ensure sufficient ventilation, keep the space shown below free from other surfaces: Front View 4 inches Sleep 4 inches 4 inches Side View 4 inches 2 inches iPod Compatibility Made for: •...

  • Page 9: General Controls

    RS2120i EN 27/3/07 11:04 AM General Controls Main Unit - Front View Sleep ON/STANDBY • Turns power on or off (STANDBY mode). DEMO/DIMMER • Turns the demonstration on/off. • Adjusts the brightness of the display. SOURCE • Allows selection of the following modes: CD player, Tuner, iPod, USB and AUX.

  • Page 10: Remote Control

    RS2120i EN 27/3/07 11:05 AM General Controls Remote Control Page 12 ON/STANDBY • Turns the power on or off (STANDBY mode). SOURCE • Selects the CD player, Tuner, iPod, USB and AUX. BAND • In Tuner mode, it selects radio band. FM ST •...

  • Page 11: Installing Batteries

    RS2120i EN 27/3/07 11:05 AM TUNE/PRESET • In CD or USB mode, it stops playback. • In Recording mode, it stops recording. • In Tuner mode, it selects the Tune or Preset mode. • Opens or closes the disc tray. PROG •...

  • Page 12: Display And Settings

    RS2120i EN 27/3/07 11:05 AM Display and Settings Setting the Clock 1. Press and hold CLOCK on the remote control until the hour flashes on the display. 2. Press to set the hour and then press CLOCK to shift to minute digits. 3.

  • Page 13: Sound Features

    RS2120i EN 27/3/07 11:05 AM Sound Features Volume Control Turn the volume control on the main unit or press VOL on the remote control to adjust volume level. The volume level shows briefly on the display. Bass Boost Press B.BOOST to turn on/off boosting the bass frequency.

  • Page 14

    RS2120i EN 27/3/07 11:05 AM CD and mp3 Disc Playback Notes: • See pages 15 – 16 for details on Navigation Mode. • In CD stop mode, press SELECT/ enter Navigation mode and show disc menu. In CD Navigation mode, press /BACK to return to stop mode.

  • Page 15: Usb Playback

    RS2120i EN 27/3/07 11:05 AM USB Playback Connecting USB drive to the Main Unit Lift the cover on the front panel. Connect the USB drive to the main unit’s USB Jack on the front panel. Selecting USB Mode Press SOURCE repeatedly to select USB mode.

  • Page 16: Suppressing Stereo Signal

    RS2120i EN 27/3/07 11:05 AM Radio 4. If a different program location is preferred, press desired preset number (1-32). 5. Press PROG to store the selected frequency at that preset. Auto Preset Programming (FM only) Press and hold the BAND button for 2 seconds to scan stations in the FM band.

  • Page 17: Deleting Files From Usb Drive

    RS2120i EN 27/3/07 11:05 AM Deleting Files from USB drive 1. In USB Navigation mode, select the file for deletion using the navigation buttons (Refer to “Advanced Navigation Controls” on page 15 – 16 for details.) 2. Press DELETE on the main unit or DEL on the remote control.

  • Page 18: Ipod Mode

    RS2120i EN 28/3/07 10:09 AM iPod Mode In iPod mode, you can navigate and playback music on your iPod. Connecting your iPod to the Unit • Ensure the iPod dock is connected to the unit as described on page 3. •...

  • Page 19: Advanced Playback Controls

    RS2120i EN 27/3/07 11:05 AM Advanced Playback Controls In CD and USB mode, advanced playback controls allow you to sample, repeat and random playback files and set up a Program List. In USB mode, it allows you to rename tracks. Sampling Tracks Press INTRO on the remote control to play the first 10 seconds of each track on the...

  • Page 20: Advanced Navigation Controls

    RS2120i EN 27/3/07 1:17 PM Advanced Playback Controls Renaming Tracks You can rename files in the USB drive. 1. In the USB stop mode, press select folder. 2. Press to select the file in the current folder. 3. Press PROG to enter rename mode. 4.

  • Page 21: Remote Control

    RS2120i EN 27/3/07 11:05 AM Remote Control Page 23 • From stop mode, enters Navigation mode. • In Navigation mode, plays selected track or enter selected folder. /MENU • In Navigation mode, exits current folder and return to a higher level. •...

  • Page 22: Tips On Playback Sequence Of Disc

    RS2120i EN 27/3/07 11:05 AM Advanced Navigation Controls Tips on Playback Sequence of Disc • Check that the mp3/WMA disc is created with a single folder structure. Refer to the diagram below for playback sequence details on multi-level folder structure. •...

  • Page 23: Troubleshooting Tips

    RS2120i EN 27/3/07 11:05 AM Troubleshooting Tips Unit will not turn on • Check the power cord for a secure connection. • Unplug the unit for a moment, and then plug into power source again. • Check the outlet by plugging in another device.

  • Page 24: Maintenance

    RS2120i EN 27/3/07 11:05 AM Maintenance Disconnect the unit from the power source before performing any maintenance. Cleaning Clean the exterior of the unit using a soft dust cloth. CD Player CAUTION! This unit operates with a laser. It must be opened by only a qualified technician.

  • Page 25: Limited Warranty

    RS2120i EN 27/3/07 11:05 AM Limited Warranty (U.S.) What your warranty covers: • Defects in materials or workmanship. For how long after your purchase: • One year from date of purchase. • The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first.

  • Page 26: Product Registration

    RS2120i EN 27/3/07 11:05 AM Limited Warranty (U.S.) Product Registration: • Please complete and mail the Product registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

  • Page 27

    RS2120i EN 27/3/07 11:05 AM Limited Warranty (Canada) Thomson multimedia Ltd. warrants to the purchaser or gift recipient that if any manufacturing defect becomes apparent in this product within 1 year from the original date of purchase, it will be replaced free of charge, including return transportation. This warranty does not include damage to the product resulting from accidents, misuse or leaking batteries.

  • Page 28

    C.P. 06700. México, D.F. Telefono: 52-55-11-020360 RFC: CTM-980723-KS5 EXPORTER Thomson Inc. P.O. Box 1976 Indianapolis, IN 46206-1976 © 2007 Thomson Inc. Trademark(s) ® Registered Marca(s) ® Registrada(s) Marque(s) ® Deposée(s) www.rcaaudiovideo.com Printed In China / Impreso en China 5643738A (EN/F/E)
