RCA RS2058 User Manual

RCA RS2058 User Manual

5cd audio system with mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

RS2058 EN_Sirius
8/5/06
10:55 AM
Page 3
u s e r
m a n u a l
RS2058
It is important to read this instruction book prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS2058 and is the answer not in the manual?

Questions and answers

Related Manuals for RCA RS2058

Summary of Contents for RCA RS2058

  • Page 1 RS2058 EN_Sirius 8/5/06 10:55 AM Page 3 u s e r m a n u a l RS2058 It is important to read this instruction book prior to using your new product for the first time. Es importante leer este manual antes de usar por vez primera su euipo.

  • Page 2: Fcc Information

    RS2058 EN_Sirius 8/5/06 FCC Information FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 RS2058 EN_Sirius 8/5/06 FCC Information Technical specification Product: 5CD Audio System with mp3 Player Brand: RCA Model: RS2058(Audio System)/RD2058A(mp3 player) Electrical Consumption: Power Supply: 120V~60Hz Power consumption: 150 Watts IMPORTER Comercializadora Thomson de México, S.A. de C.V. Álvaro Obregón No. 151. Piso 13.

  • Page 4: Important Information

    RS2058 EN_Sirius 8/5/06 Important Information Safety Precautions • Never open the cabinet under any circumstances. Any repairs or internal adjustments should be made only by a trained technician. • Never operate this product with the cabinet removed. • Do not use your System immediately after...
  • Page 5 RS2058 EN_Sirius 8/5/06 Important Information Important Battery Information • Remove the batteries to avoid leakage if you do not use your remote control for more than one month. • Discard leaky batteries immediately as leaking batteries may cause skin burns or other personal injuries.

  • Page 6: Table Of Contents

    RS2058 EN 8/5/06 3:13 PM Table of Contents FCC Information Important Information Table of Contents ....1 Getting Started ....2 Content of Box .

  • Page 7: Getting Started

    RS2058 EN_Sirius 8/5/06 Getting Started Content of Box • one main unit (with 2 main speakers); • one remote control; • one AM loop antennas; • one mp3 Player; • one set of earphones; • one user manual; • one safety leaflet;...

  • Page 8: Connecting The Sirius Connect

    RS2058 EN_Sirius 8/5/06 Getting Started Using the FM and AM Antennas Before you use your audio system, you’ll want to make sure both the FM and AM antennas are positioned properly. Uncoil the FM antenna at the back of the unit, making sure it is fully extended (you may even want to tape it to the wall behind the unit if possible.

  • Page 9: General Controls

    RS2058 EN_Sirius 8/5/06 General Controls Main Unit - Front View ON/STANDBY - Turns power on or off (STANDBY mode). Tips: In STANDBY mode, press ON/STANDBY to turn the system on in the previously used mode. Press SOURCE to select the corresponding mode.

  • Page 10: Remote Control

    RS2058 EN_Sirius 8/5/06 General Controls Main Unit - Top View PHONES PHONES - Jack for connecting headphones DEMO - Activates and deactivates demonstration. Note: Refer to “mp3 Player” section on page 23- 25 for mp3 player operation details. 10:55 AM...
  • Page 11 RS2058 EN_Sirius 8/5/06 General Controls EQ - Selects equalizer presets. (MUTE) - Mutes audio output. - Decreases or Increases volume level. (PLAY/PAUSE) - In CD / USB / memory card mode - Starts and pauses playback. (SKIP BACKWARD) - In clock and timer setting mode - Goes to the previous setting option.

  • Page 12: Display

    RS2058 EN_Sirius 8/5/06 Display TUNER USB MEMCARD AUX ROCK POP JAZZ CLASSIC CUSTOM INTRO REPEAT I ALL DISC MP3WMA FM AM STEREO RECORD CD / TUNER / USB / MEMCARD / AUX - indicates the current mode. - Random playback is activated in CD mode.

  • Page 13: Setting The Timer

    RS2058 EN_Sirius 8/5/06 Settings Setting the Timer You can turn on/off the unit or record TUNER at preset times by setting the timer. 1. Press and hold TIMER on the remote control until Timer On and the clock hour flashes on the display.

  • Page 14: Sleep Mode

    RS2058 EN_Sirius 8/5/06 Settings Sleep Mode You can select the time interval in minutes before the unit turns off automatically. Press SLEEP to select among OFF, 120, 90, 60, 45, 30, 15 and 5 minutes. The SLEEP icon lights on the display when sleep mode is activated.

  • Page 15: Cd And Mp3 Disc Playback

    RS2058 EN_Sirius 8/5/06 CD and mp3 Disc Playback Important CD and mp3/WMA Information CD-R / RW This unit is compatible with CD-RW/ CD-R discs for playback. Notes on CD-R/RW Disc: • Do not affix any type of labels to either...

  • Page 16: Play/Pause Discs

    RS2058 EN_Sirius 8/5/06 CD and mp3 Disc Playback Loading Discs 1. Press SOURCE repeatedly to select CD mode. 2. Press OPEN/CLOSE to open the disc compartment. 3. Insert up to 5 discs with label face up. 4. Press OPEN/CLOSE again to close the disc compartment.

  • Page 17: Searching Disc

    RS2058 EN_Sirius 8/5/06 CD and mp3 Disc Playback Tips: In CD stop mode, press navigation mode and show disc menu. In CD navigation mode, press to stop mode. Selecting a Disc Press DISC 1, DISC 2, DISC 3, DISC 4 or DISC 5 on the main unit or DISC SKIP on the remote control to skip discs.

  • Page 18: Selecting Usb Or Mp3 Player Mode

    RS2058 EN_Sirius 8/5/06 USB and Memory Card Playback Selecting USB or Memory Card Mode Press SOURCE repeatedly to select USB or Memory Card mode. USB / Memory Card Playback Features Start and Pause Playback Press to start and pause playback.

  • Page 19: Radio

    RS2058 EN_Sirius 8/5/06 Radio Selecting Tuner Band 1. Press SOURCE to enter Tuner mode. 2. Press BAND to select between FM or AM Radio band. Tips: Your audio system has 32 preset stations. Tuning to a Station Press to select frequencies. Press and hold to scan frequecies.

  • Page 20: Sirius Satellite Radio

    RS2058 EN_Sirius 8/5/06 Sirius Satellite Radio What is Siriuis? Sirius Satellite Radio has over 125 channels including 100% commercial-free music, plus sports, news, talk and entertainment. For more information, visit www.sirius.com. Sirius Satellite Radio Subscription This unit is Sirius-ready. It requires a Sirius...

  • Page 21: Operation In The Three Operation Modes

    RS2058 EN_Sirius 8/5/06 Sirius Satellite Radio Operation in the Three Operation Modes All mode You can select from all available channels under this mode. Press previous or next channels. Category mode • To change category, press SELECT/BACK (CAT +/CAT-) on the main unit or on the remote.

  • Page 22: Recording To The Mp3 Player

    RS2058 EN_Sirius 8/5/06 Recording to the mp3 Player You can record CD, Tuner or AUX files to the mp3 player. Recording CD to mp3 Player Normal/High Speed Recording 1. Connect the mp3 player to the USB port, “USB Connected” will show on the display.

  • Page 23: Recording Tuner/Aux To Mp3 Player

    RS2058 EN_Sirius 8/5/06 Recording to the mp3 Player Tips: Recording stops automatically when CD stops (For example: end of disc is reached). Recording Tuner/AUX to mp3 Player 1. In Tuner or AUX mode, press RECORD to start recording. In Tuner mode 90.50MHz...

  • Page 24: Advanced Playback Controls

    RS2058 EN_Sirius 8/5/06 Advanced Playback Controls In CD / USB / mp3 mode, advanced playback controls allow you to sample, repeat and radom playback files, set up a Program List. In USB mode, allow you to rename tracks. Sampling Tracks...

  • Page 25: Rename Tracks

    RS2058 EN_Sirius 8/5/06 Advanced Playback Controls Playing a Program List While in PROGRAM stop mode , press If you are not currently in program mode, press PROG to enter program mode. Program playback begins automatically. Display Program List 1. While the CD player is stopped, press PROG to enter PROGRAM mode.

  • Page 26: Advanced Navigation Controls

    RS2058 EN_Sirius 8/5/06 Advanced Navigation Controls File Navigation Main Unit SELECT - Enters navigation mode from mp3 / WMA / USB / memory card stop mode. Enters selected folder in navigation mode. Begins playback of the selected file in navigation mode.

  • Page 27: Tips On Playback Sequence Of Disc

    RS2058 EN_Sirius 8/5/06 Advanced Navigation Controls Tips on Playback Sequence of Disc • Check that the mp3/WMA disc is created with a single folder structure. Refer to the diagram below for playback sequence details on multi-level folder structure. • For example, folders and songs from level 2 are played before moving on to play folders and songs from level 3.

  • Page 28: Mp3 Player

    RS2058 EN_Sirius 8/5/06 mp3 Player Insert battery into the player 1. To insert battery, push the battery door away from the unit and lift the battery door out. 2. Insert a “AAA”(UM4) battery with polarities corresponding to the indications in the compartment.

  • Page 29: Turn On/Off The Player

    RS2058 EN_Sirius 8/5/06 mp3 Player Top View Headphones Jack - Insert headphones here. Back View USB port - Use the USB port to connect to the Audio System. Battery Compartment - Insert battery here. Display Overview 1. Shows current volume level.

  • Page 30: Adjusting The Volume

    RS2058 EN_Sirius 8/5/06 mp3 Player Skipping Tracks • To skip to the next track, press and release the NEXT button. • To go to the previous track, press and release the LAST button. Note: If the elapsed time of the playing track is less than 0:04, pressing Skip backward once will return to previous track.

  • Page 31: Troubleshooting Tips

    RS2058 EN_Sirius 8/5/06 Troubleshooting Tips Main Unit Problem Solution System will • Check power cord for a secure not turn connection. • Unplug the unit for a moment, and then plug into power source again. • Check the outlet by plugging in another device.

  • Page 32: Mp3 Player

    For more information on the Microsoft PlaysForSure program, visit www.PlaysForSure.com. For more information on RCA PlaysForSure devices, visit www.rca.com. • Check connection between your unit and the computer. • To reset the unit, turn the player off by removing the battery.

  • Page 33: Maintenance

    RS2058 EN_Sirius 8/5/06 Maintenance Disconnect the audio system from the power source before performing any maintenance. Cleaning Clean the exterior of the system using a soft dust cloth. CD Player CAUTION! This system operates with a laser. It must be opened by only a qualified technician.

  • Page 34: Warranty

    What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit. • Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts required to repair your unit.
  • Page 35 RS2058 EN_Sirius 8/5/06 Limited Warranty (U.S.) Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES...
  • Page 36 What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit. • Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts required to repair your unit.
  • Page 37 RS2058 EN_Sirius 8/5/06 10:55 AM Page 39 Limited Warranty (Canada) Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA LTD., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
  • Page 38 RS2058 EN_Sirius 8/5/06 IMPORTADOR Comercializadora Thomson de México, S.A. de C.V. Álvaro Obregón No. 151. Piso 13. Col. Roma. Delegación Cuauhtémoc C.P . 06700. México, D.F. Telefono: 52-55-11-020360 RFC: CTM-980723-KS5 EXPORTER Thomson Inc. P .O. Box 1976 Indianapolis, IN 46206-1976 ©...
