It's important to read this instruction prior to using your new product for the fi rst time.
English IB(A5).indd 1
English IB(A5).indd 1
USER MANUAL
RTB1100
4/15/2010 20:19:09
4/15/2010 20:19:09

Advertisement

Table of Contents
loading

Related Manuals for RCA RTB1100

Summary of Contents for RCA RTB1100

  • Page 1 It's important to read this instruction prior to using your new product for the fi rst time. English IB(A5).indd 1 English IB(A5).indd 1 USER MANUAL RTB1100 4/15/2010 20:19:09 4/15/2010 20:19:09...

  • Page 2: Fcc Information

    FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Important Information SEE MARKING ON BACK OF PRODUCT WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
  • Page 4 Important Information Important Battery Information • Do not mix diff erent types of batteries or new and old batteries. Do not use rechargeable batteries. • In order to avoid any risk of explosion, observe the polarities indicated inside the battery compartment.

  • Page 5: Important Safety Instructions

    Important Safety Instructions Please Read and Save for Future Reference. Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. • Read these instructions. •...

  • Page 6: Connections And Setup

    • Easy and simple HDTV connection using a single HDMI cable (cable not included). • Multiple outputs for connecting your home theater system or amplifi er. • PIP functionality that lets you display primary and secondary video at the same time (if available on the Blu-ray Disc).

  • Page 7: Things To Consider Before You Connect

    Connections and Setup Things to Consider before You Connect • Ensure that the mains supply in your house complies with that indicated on the identifi cation sticker located on the back of your unit. • Install your unit horizontally, away from any source of heat (fi replace) or appliances creating strong magnetic or electric fi elds.
  • Page 8 Connections and Setup • If your television is a high definition television, use the unit’s HDMI output to get the highest possible video resolution. • If one of the devices is not working, check that all the cables have been inserted properly into the jacks.
  • Page 9 Connections and Setup Connecting AUDIO IN from External Sources such as TV Using AUDIO IN Jacks Connect the AUDIO IN jacks from the unit to the AUDIO OUT jacks on VCR, TV, SAT/Cable Box or other component. Press either SOURCE button on the main unit or AUX button on the remote control to select AUX mode.

  • Page 10: Connecting The Speakers

    Connections and Setup Connecting the Speakers Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the ter- minal and insert the wire.

  • Page 11: Positioning Speakers

    Connections and Setup Positioning Speakers Courtesy Dolby Laboratories 1. Left, Right (Front Speakers) Front speakers carry primarily music and sound eff ects. 2. Center In surround mode, the center speaker carries most of the dialog as well as music and eff ects. It should be set between the left and right speakers.
  • Page 12 Connections and Setup Better Surround Placement Location If possible, place surround speakers to either side of the listening area, not behind it. Height If space permits, install surround speakers 2-3 feet above viewers. This helps to minimize localization eff ects. Aiming Aim surround speakers straight across the room, not down at viewers, to help create a more open,...

  • Page 13: Overview Of Controls

    Overview of Controls English IB(A5).indd 14 English IB(A5).indd 14 OPEN/CLOSE Press to open or close the disc tray. ON/STANDBY Press to turn on your unit, or put your unit in standby mode. When your unit is in standby mode, power is still entering your unit.
  • Page 14 Overview of Controls English IB(A5).indd 15 English IB(A5).indd 15 BD/USB Press to select the BD/USB mode. LEVEL Toggle channels for diff erent level settings. Adjusts the value using REPEAT Press to repeat the current title, chapter, track, or repeat all. This button is only used for DVD/CD discs.

  • Page 15: Basic Playback Operations

    Basic Playback Operations Compatible Discs • Blu-ray Disc • DVD-video (DVD-ROM) • DVD+RW, DVD-RW • DVD+/-R • Audio CDs (CDDA) • JPEG Regional Coding This unit has been designed to play back BD-video with region “A” and DVD-video with region “1”. You cannot play back BD-video or DVD-video that are labeled for other regions.

  • Page 16: Viewing Photographs

    Basic Playback Operations 3. Press button to select Play All (plays all fi les), then press OK button to start playback. • If you want to see information about the fi le that is playing, press INFO button on the re- mote control.

  • Page 17: Displaying Blu-Ray Disc Information

    Basic Playback Operations 3. Press , , buttons to select a fi le or folder, then press OK button. If you selected a folder, the fi les in the folder are displayed. Press buttons to select a fi le, then press OK button.

  • Page 18: The Setup Menu

    Basic Playback Operations Using a disc popup menu 1. During Blu-ray or DVD playback, press POP UP button. The Blu-ray popup menu or the title menu of DVD disc opens. 2. Press , or buttons to select an option, then press OK button. Selecting a play source •...

  • Page 19: Display Setting

    The Setup Menu Display Setting 1. In the main menu of Settings, press then use button to select Display. System Display Network HDMI Status HDMI Preferred Format TV Type Settings Display Resolution TV Aspect Audio Film Mode Language 2. Press button and press select an option, then press OK button.

  • Page 20: Audio Setting

    The Setup Menu Audio Setting 1. In the main menu of Settings, press then use button to select Audio. Network Display PCM Downsamoling Digital Output Settings Audio Language System 2. Press button and press select an option, then press OK button. 3.

  • Page 21: System Setting

    The Setup Menu System Setting 1. In the main menu of Settings, press then use button to select System. System Audio Optical Disc AutoPlay Language BD-Live Internet Access BD-Live Storage Erase Blu-ray Storage Settings System Update Via Network Restore factory defaults Network Display 2.

  • Page 22: Connecting Auxiliary Components

    The Setup Menu 6. Press or EXIT button to go to the previous menu. Network Test You can test the connectivity of the network confi guration by “pinging” an IP address. Pinging means sending a signal to an IP address and waiting for a retuning signal.
  • Page 23 Radio The unit has a built-in tuner that allows for FM radio function. The AM loop antenna allows for AM radio function. Manual tuning 1. Connect the FM antenna and the AM loop antenna at the back of the unit. 2.

  • Page 24: Troubleshooting

    Troubleshooting The unit does not switch on. • Make sure it is plugged in. • Press STANDBY/ON button on the remote con- trol or ON/STANDBY button on the front of the unit. The device switches off spontaneously. • The devices switches off automatically when it is in STOP mode for more than 30 minutes with- out any user intervention.

  • Page 25: Additional Information

    Troubleshooting I can’t fi nd my fi le in the JPEG listing. • Make sure the fi le name is valid. The remote control does not work or works only intermittently. • Check that batteries are inserted or change them. •...
  • Page 26 Additional Information Handling and Caring for Discs • Handle your discs with care. Hold the disc with your fi ngers at the edges or through the hole. • Insert the disc with the label facing up (for a single-sided disc). •...
  • Page 27 Additional Information If the disc is not recognized after a period of 120 seconds, remove the disc, and insert it again. • Do not use its full capacity. • CD-Rs should be preferably used instead of CD-RWs (rewritable CDs) as, in certain cases, CD-RW playback may be faulty.

  • Page 28: Specifications

    Additional Information Specifi cations: Amplifi er Section: RMS Output Power: Dolby Digital Mode with 10% Total Harmonic Distortion Front, Rear and Center Channel: 167 Watts per channel (1kHz, 8Ω) Subwoofer Channel: 167 Watts (100Hz, 8Ω) Total RMS Output Power, Dolby Digital mode: 1000 W Muting Attenuation: 65 dB Frequency Response: 200Hz /3dB, 1KHz ref.

  • Page 29: Limited Warranty

    Limited Warranty AVC MULTIMEDIA (“AVC”) makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to non-commercial use of the product. One Year Parts & Labor Warranty AVC products purchased in the United States or Canada are warranted to be free from defects in materials or workmanship for a period of one year from the date of their original retail purchase.
  • Page 30 Limited Warranty Out of Warranty I n t h e e ve n t yo u r p ro d u c t re q u i re s re p a i r a f te r t h e l i m i te d w a r r a n t y p e r i o d h a s expired, please contact our Customer Support Center at www.RCAav.com Hours: Monday–Thursday: 9am–7pm, Friday: 9am–5pm, Saturday: 9am–NOON Eastern...
  • Page 31 English IB(A5).indd 32 English IB(A5).indd 32 Printed in China 811-110091W010 4/15/2010 20:19:13 4/15/2010 20:19:13...
