RCA RC59i User Manual

v1.0 (EN/F)
user manual
guide de l'utilisateur
EN/F
It is important to read this user manual prior to using your new product for the fi rst time.
Nous vous recommandons de lire ce manuel avant d'utiliser votre nouveau produit
pour la première fois.
For your records The descriptions and characteristics in
this owner's manual are for the purpose
In the event that service should be
of general reference only and not as a
required, you may need the model
guarantee. In order to provide you with
number and the serial number. In the
the highest quality product, we may
space below, record the date and place
make changes or modifi cations without
of purchase and the serial number:
prior notice.
Model No.:
Date of Purchase:
Place of Purchase:
Serial No.:
Technical information
Product: Clock Radio
Brand: RCA
Model: RC59i
Electrical consumption
Power Supply: 120V ~ 60Hz
Power Consumption: 9 Watts
iPod is a trademark of Apple Inc.,
registered in the U.S. and other
countries.
Apple is not responsible for the
operation of this device or its
compliance with safety and regulatory
standards.
"Made for iPod" means that an
electronic accessory has been designed
to connect specifi cally to iPod and has
been certifi ed by the developer to meet
Apple performance standards.
SET button Clock
Using SET button Setting clock time
Use the SET button to set clock and 1. Press SET three times. Refer to "SET
wake times. Each press of the button
button".
will change to adjust a different time
setting.
The unit will immediately
prompt to clock setting when
1. Press SET once to set the wake time
you plug the unit for power
of WAKE 1.
for the fi rst time (or after a period of
time without AC and battery power).
There is no need to press the SET
button.
The indicator lights against one
• The clock time fl ashes on the
of the WAKE 1 mode icons
display.
2. Press SET twice to set the wake
time of WAKE 2.
2. Press or to set the clock time.
• The time decrements or increments
follow by a faster rate when you
The indicator lights against one
press and hold the button.
of the WAKE 2 mode icons
• The clock is in 12 hour format.
The indicator lights against AM to
3. Press SET a third time to set the indicate a.m. time.
clock time.
3. To save and exit the clock setting,
wait for about 5 seconds or press
SET once. The clock time is set and
should stop fl ashing.
No indicators light here
4. Press SET a fourth time to exit the
setting mode.
Auxiliary source Wake function
Listening to auxiliary

Setting wake time

This unit allows 2 wake times to be set.
source
1. Press SET once (for setting WAKE 1
1. Connect your auxiliary source (e.g.
time) or twice (for setting WAKE 2
mp3 player) to the AUX input jack
time). Refer to "SET button".
on the left of the unit with an
• The wake time fl ashes on the
audio cable (not supplied).
display.
2. Press RADIO/AUX twice to turn
on the unit and to switch to listen
to AUX mode. If you are in radio
mode, press RADIO/AUX once.
• The indicator lights against AUX
mode icon ( AUX ) on the display.
2. Press or to set the wake time.
• The time decrements or increments
3. Adjust the auxiliary player to mid-
follow by a faster rate when you
range volume and adjust the master
press and hold the button.
volume on the unit. Do not turn the
volume of the auxiliary player too • The clock is in 12 hour format.
The indicator lights against AM to
high as this may affect the sound
indicate a.m. time.
quality.
• For other playback operations,
3. To save and exit the wake setting,
control them on your auxiliary
wait for about 5 seconds or press
player.
SET repeatedly until the time
display stops fl ashing.
Warranty information
12 Month Limited Warranty accessories, computers, computer
Applies to RCA Audio/Video peripherals, other media players,
Products home networks or vehicle electrical
• AUDIOVOX ELECTRONICS CORP. (the systems.
Company) warrants to the original • This Warranty does not apply to
retail purchaser of this product any product or part thereof which,
that should this product or any in the opinion of the Company,
part thereof, under normal use and has suffered or been damaged
conditions, be proven defective in through alteration, improper
material or workmanship within installation, mishandling, misuse,
12 months from the date of neglect, accident, or by removal
original purchase, such defect(s) or defacement of the factory
will be repaired or replaced with serial number/bar code label(s).
reconditioned product (at the THE EXTENT OF THE COMPANY'S
Company's option) without charge LIABILITY UNDER THIS WARRANTY
for parts and repair labor. IS LIMITED TO THE REPAIR OR
• To obtain repair or replacement REPLACEMENT PROVIDED ABOVE
within the terms of this Warranty, AND, IN NO EVENT, SHALL THE
the product is to be delivered with COMPANY'S LIABILITY EXCEED
proof of warranty coverage (e.g. THE PURCHASE PRICE PAID BY
dated bill of sale), specifi cation of PURCHASER FOR THE PRODUCT.
defect(s), transportation prepaid, to • This Warranty is in lieu of all other
the Company at the address shown express warranties or liabilities. ANY
below. IMPLIED WARRANTIES, INCLUDING
• This Warranty does not extend ANY IMPLIED WARRANTY OF
to the elimination of externally MERCHANTABILITY, SHALL BE
generated static or noise, to LIMITED TO THE DURATION OF
correction of antenna problems, THIS WRITTEN WARRANTY. ANY
loss/interruptions of broadcast or ACTION FOR BREACH OF ANY
internet service, to costs incurred for WARRANTY HEREUNDER INCLUDING
installation, removal or reinstallation ANY IMPLIED WARRANTY OF
of product, to corruptions caused MERCHANTABILITY MUST BE
by computer viruses, spyware or BROUGHT WITHIN A PERIOD OF 24
other malware, to loss of media, MONTHS FROM DATE OF ORIGINAL
fi les, data or content, or to PURCHASE. IN NO CASE SHALL THE
damage to tapes, discs, removable COMPANY BE LIABLE FOR ANY
memory devices or cards, speakers, CONSEQUENTIAL OR INCIDENTAL
FCC information • Connect the equipment into an outlet
on a circuit different from that to
This equipment has been tested and
which the receiver is connected.
found to comply with the limits for a Class
• Consult the dealer or an experienced
B digital device, pursuant to Part 15 of FCC
radio/TV technician for help.
Rules. These limits are designed to provide
reasonable protection against harmful
Modifications not expressly approved
interference in a residential installation.
by the party responsible for compliance
This equipment generates, uses, and can
could void the user's authority to operate
radiate radio frequency energy and, if
the equipment.
not installed and used in accordance
RC59i
with the instructions, may cause harmful
This Class B digital apparatus complies
interference to radio communications.
with Canadian ICES-003.
Cet appareil numérique de la classe B
However, there is no guarantee that
est conforme à la norme NMB-003 du
interference will not occur in a particular
Canada.
installation. If this equipment does cause
harmful interference to radio or television
Manufacturer/Responsible Party
reception, which can be determined
Audiovox Electronics Corp.,
by turning the equipment off and on,
150 Marcus Blvd., Hauppauge, NY 11788
the user is encouraged to try to correct
the interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
SEE MARKING ON BOTTOM OF PRODUCT
Before you begin
Battery back-up operation
Plugging in for power
The power failure protection circuit will
• AC OUTLET POWER SUPPLY:
not operate unless battery is installed.
120V~60Hz
• The AC power plug is
No worry battery backup
polarized (one blade is
wider than the other) • When the battery backup functions,
the digital display will not light,
and only fi ts into AC
power outlets one way. however, the wake function
still occurs during the power
If the plug will not go
interruption if remaining battery
into the outlet completely, turn the
power is adequate.
plug over and try to insert it the
• Normal operation will resume after
other way. If it still does not fi t,
contact a qualifi ed electrician to AC power is restored so you will not
have to reset the time or wake.
change the outlet, or use a different
one. Do not attempt to bypass this
Install battery as follow:
safety feature.
• Power is fed to the unit even when 1. Remove battery compartment door
(located at the bottom of the radio)
it is not functioning. To cut the
by applying thumb pressure to the
power supply off, the power cable
must be unplugged. tab on battery door and then lift
the door out and off the cabinet.
2. Connect a 9-volt battery (not
supplied) to the connector plug.
3. Replace the compartment door.
Power failure indicator
• When AC power is interrupted
(disconnected) for a short period
of time, both time and alarm
settings will change (unless battery
is installed). After AC power is
restored (reconnected), the Digital
Display will blink to indicate that
power was interrupted and you
should readjust the time and alarm
settings.
Radio

Listening to radio

Antenna
To turn on or off radio: Built-in AFC
1. Press RADIO/AUX to turn on the • The Built-in Automatic Frequency
radio.
Control (AFC) works only on FM. It
helps reduce drift on FM reception
2. Press OFF to turn off the radio, or and keep the radio locked in on the
press RADIO/AUX or iPod to select FM station to which it is tuned.
another sound mode. • When tuning in FM stations, you
may notice that the station you are
To select radio band: tuning can be well-tuned on two
• Slide the AM FM switch to select or three nearby points on the dial.
FM or AM band. Always tune carefully at the loudest
and clearest point.
To tune frequency:
• Rotate – TUNING + to tune AM Antenna
frequency. • A built-in ferrite rod antenna
eliminates the need for an outside
antenna for AM reception. Rotating
the unit slightly may improve
reception of distant AM stations.

Selecting wake source

If Waking to RADIO (
selected:
You may be woken up by the alarm,
radio, or music from iPod. 3. Select a desired wake up radio
channel (refer to "Listening to the
1. Set a wake time (refer to the above
instructions). radio"). If no wake up channel is
set, your last listening radio station
2. Press WAKE 1 MODE or WAKE will be selected.
2 MODE to select a wake mode.
4. Adjust the volume to your desired
The indicator lights against the
corresponding wake mode icon on level.
the display.
– Wake time 1 by alarm 5. Press OFF to turn off the unit.
– Wake time 1 by radio
– Wake time 1 by iPod If Waking to iPod (
selected:
– Wake time 2 by alarm
– Wake time 2 by radio 3. Adjust the volume to your desired
level. The last played fi le on the
– Wake time 2 by iPod
iPod will be played when the wake
function activates.
If Waking to Alarm ( , ) is
selected:
4. Press OFF to turn off the unit.
• If you set the wake function with
low volume level before going to
Note: If there is no iPod connected, the
bed, we advise using Waking to
alarm tone will sound instead even if
Alarm mode to wake you up.
Waking to iPod mode is selected.
DAMAGES FOR BREACH OF THIS OR PERSONAL CONTENT OR DATA ON
ANY OTHER WARRANTY. No person THE RETURNED DEVICE. Product
or representative is authorized
will be returned with factory
to assume for the Company any default settings, and without any
liability other than expressed herein
pre-loaded content which may have
in connection with the sale of this been installed in the originally
product. purchased products. Consumer will
• Some states do not allow limitations be responsible for reloading data
on how long an implied warranty and content. Consumer will be
lasts or the exclusion or limitation
responsible to restore any personal
of incidental or consequential preference settings.
damage so the above limitations or
• Properly pack your unit. Include
exclusions may not apply to you. any remotes, memory cards, cables,
This Warranty gives you specifi c etc. which were originally provided
legal rights and you may also have with the product. However DO NOT
other rights which vary from state return any removable batteries,
to state. even if batteries were included
with the original purchase. We
How to make a warranty claim:
recommend using the original
• If your product is capable of storing carton and packing materials.
content (such as an mp3 player,
• Include evidence of purchase date
digital voice recorder, etc), it is such as the bill of sale. Also print
recommended to make periodic your name and address and a
backup copies of content stored description of the defect. Send via
on the product. If applicable, standard UPS or its equivalent to:
before shipping a product, make
a back up copy of content or data Audiovox Electronics Corp.
stored on the device. Also, it is
Attn: Service Department.
advisable to remove any personal 150 Marcus Blvd.
content which you would not want Hauppauge N.Y. 11788
exposed to others. IT IS LIKELY 1-877-833-3491
THAT CONTENTS AND DATA ON
THE DEVICE WILL BE LOST DURING • Insure your shipment for loss or
SERVICE AND REFORMATTING. damage. Audiovox accepts no
AUDIOVOX ACCEPTS NO LIABILITY
liability in case of damage or loss en
FOR LOST CONTENT OR DATA, route to Audiovox.
OR FOR THE SECURITY OF ANY

IMPORTANT SAFETY INSTRUCTIONS

Some of the following information may
not apply to your particular product;
however, as with any electronic product,
precautions should be observed during
handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near
water.
• Clean only with dry cloth.
• Do not block any ventilation
openings. Install in accordance with
the manufacturer's instructions.
• Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifi ers) that produce heat.
• Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the
other. A grounding type plug has
two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. If
WARNING:
the provided plug does not fi t into
TO PREVENT FIRE
your outlet, consult an electrician
OR ELECTRICAL for replacement of the obsolete
outlet.
SHOCK HAZARD,
• Protect the power cord from being
DO NOT EXPOSE
walked on or pinched particularly at
THIS PRODUCT TO
plugs, convenience receptacles, and
RAIN OR MOISTURE.
the point where they exit from the
apparatus.
• Only use attachments/accessories
specifi ed by the manufacturer.
Alkaline (NEDA 1604A/
IEC 6LR61) battery is
recommended. Carbon-zinc
battery may be used but memory
holding time will be substantially
reduced. Memory holding time
for a fresh alkaline battery is
approximately 8 hours (if radio
or alarm are not operated) which
should take care of short, nuisance-
type AC power failures. To preserve
battery life, the unit should remain
plugged into an AC outlet. As the
battery gets older, its voltage drops
and memory may be lost. Be sure
to replace the battery periodically.
Battery should be removed if the
unit will be stored for more than
one month. Leaky battery can badly
damage the clock radio.
iPod

Connecting iPod

To connect iPod:
• Place the adapter (provided with
your iPod) and then your iPod on
the universal dock for iPod.
To select iPod mode:
• Press iPod on the front of the unit
to select the iPod mode.
• The indicator lights against iPod
mode icon ( ) on the display.
• Playback from the iPod starts
automatically.
• If no iPod is connected in the iPod
mode, the unit will exit the iPod
mode and turn off automatically.
, ) is
• When the wake
function activates, the
corresponding wake mode
indicator will fl ash until the
wake function is turned off. The
indicator will then stop fl ashing
and keep lighting up.
• When the AC power is
disconnected, all wake mode will
be reverted to alarm tone.
Checking wake time
, ) is
• To check the wake time after setting,
press SET until the indicator lights
against a WAKE 1 icon ( , or )
or WAKE 2 icon ( , or ). The
respective assigned wake time also
shows on the display.
• Pay any charges billed to you by
the Exchange Center for service not
covered by the warranty.
• A new or refurbished unit will be
shipped to you freight prepaid.
What we will do:
Provide you with a new, or at our
option, a refurbished unit. The
exchange unit is under warranty for
the remainder of the original product's
warranty period.
For Canada Customers, please ship
to:
Audiovox Return Centre
c/o Genco
6685 Kennedy Road,
Unit#3, Door 16,
Mississuaga, Ontario
L5T 3A5
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE
• Use only with the cart, stand, • Always leave suffi cient space around
tripod, bracket, or table specifi ed the product for ventilation. Do
by the manufacturer, or not place product in or on a bed,
sold with the apparatus. rug, in a bookcase or cabinet that
]
When a cart is used, use may prevent air fl ow through vent
caution when moving openings.
the cart/apparatus • Do not place lighted candles,
combination to avoid cigarettes, cigars, etc. on the
injury from tip-over. product.
• Unplug this apparatus during • Connect power cord only to AC
lightning storms or when unused power source as marked on the
for long periods of time. product.
• Refer all servicing to qualifi ed • Care should be taken so that objects
service personnel. Servicing is do not fall into the product.
required when the apparatus has • Do not attempt to disassemble
been damaged in any way, such the cabinet. This product does
as power-supply cord or plug is not contain customer serviceable
damaged, liquid has been spilled components.
or objects have fallen into the • The marking information is located
apparatus, the apparatus has been at the bottom of apparatus.
exposed to rain or moisture, does • Caution marking is located at
not operate normally, or has been bottom of apparatus.
dropped.
This is CLASS II apparatus with
ADDITIONAL SAFETY INFORMATION double insulation, and no
• Main plug is used as disconnect
protective earth provided.
device and it should remain readily
operable during intended use. In
order to disconnect the apparatus
from the mains completely, the
mains plug should be disconnected
form the mains socket outlet
completely.
• Apparatus shall not be exposed to
dripping or splashing and no objects
fi lled with liquids, such as vases,
shall be placed on the apparatus.
General controls
Top view
OFF – Turn off the unit
SET – Refer to "SET button"
Universal dock for iPod
WAKE 1 MODE / WAKE 2 MODE – Activate or change Wake 1 or
2 settings
RADIO/AUX – Turn on the unit; select Radio or Auxiliary Input
mode
iPod – Turn on the unit; select iPod mode
or
wake time
REPEAT – Select repeat playback mode for iPod
SHUFFLE – Select random playback mode for iPod
SLEEP – Refer to "Sleep function"
SNOOZE – Turn off the wake function momentarily; turn off the

sleep function

Side views
– TUNING + – Adjust radio frequency
AM / FM – Select radio band
– VOLUME + – Adjust volume
AUX IN – Auxiliary input jack

Listening to iPod

Made for:
To control the playback:
• iPod touch 2nd
1. Press iPod to start or pause the
generation 8GB, 16GB,
playback.
32GB
• During playback, press and hold
• iPod touch 1st generation 8GB,
or to search backward or
16GB, 32GB
forward within a music fi le.
• iPod nano 4th generation
(video) 8GB, 16GB
2. Press or to skip to the
• iPod nano 3rd generation
previous or next fi le.
(video) 4GB, 8GB
• iPod classic 80GB, 160GB
3. Press SHUFFLE to play the fi les in
• iPod nano 2nd generation
random order in the iPod. Press
(aluminum) 2GB, 4GB, 8GB
again to cancel the function (shows
• iPod 5th generation (video)
on the iPod display).
30GB, 60GB, 80GB
• iPod mini 4GB, 6GB
4. Press REPEAT to select a repeat
• iPod 4th generation 40GB
playback mode (repeat 1 or repeat
• iPod 4th generation (color
all). Press REPEAT until no repeat
display) 20GB, 30GB, 40GB, 60GB
mode is selected (shows on the
iPod display) to cancel the repeat
playback.
Sleep function

Turning off wake function

In the sleep mode, the radio, iPod or
AUX mode turns off automatically.
To silence the wake function
momentarily:
To set the sleep time:
• Press SNOOZE. The alarm will sound
1. Press SLEEP repeatedly to cycle
again when the snooze period (9
among the sleep time available
minutes) is over.
(90min, 60min, 30min, 15min and
• Snooze function can be used
OFF. 90min is the default setting).
repeatedly up to 1 hour. After this,
the wake function will turn off until
2. When the desired sleep time is
the next day.
selected, release SLEEP and wait for
about 5 seconds, the sleep time is
OR
now set.
To stop the wake function:

To listen to the radio:

• Press OFF. The alarm will be on
• The radio turns on by default. If
again the following day at the same
not, press RADIO/AUX and select a
time.
radio station as usual.
OR

To listen to the iPod:

• Press iPod and then press
To disable the wake function
to select a fi le on the iPod.
completely:
• If iPod mode is selected in your last
• Press WAKE 1 MODE or WAKE 2
sleep mode setting, the iPod will
MODE repeatedly until no indicator
start to play, instead of the radio.
lights against a wake mode icon ( ,
• The radio will be played whenever
, or , , ) on the display.
the iPod mode is selected but
without an iPod connected.

To listen to the auxiliary player:

• If an auxiliary player (e.g. mp3
player) is connected, press RADIO/
AUX to select AUX mode and start
playback on your auxiliary player.
Important Battery Precautions
• Any battery may present a risk of
fi re, explosion, or chemical burn
if abused. Do not try to charge a
battery that is not intended to be
recharged, do not incinerate, and
do not puncture.
• Non-rechargeable batteries, such as
alkaline batteries, may leak if left in
your product for a long period of
time. Remove the batteries from the
product if you are not going to use
it for a month or more.
• If your product uses more than one
battery, do not mix types and make
sure they are inserted correctly.
Mixing types or inserting incorrectly
may cause them to leak.
• Discard any leaky or deformed
battery immediately. They may
cause skin burns or other personal
injury.
• Please help to protect the
environment by recycling or
disposing of batteries according to
federal, state, and local regulations.
• Do not expose batteries to excessive
heat (for example, by leaving them
in sunlight or close to fi re).
– Skip or search music fi le in iPod; adjust clock time and
To charge the iPod:
• You may charge the battery of your
iPod through the universal dock for
iPod while the unit is turned off
(standby mode) or in the iPod or
AUX mode. Charging control should
be operated on the iPod.
All playback operations can
also be performed on your
iPod when it is connected
with this unit.
To change or check the remaining
time in sleep mode:
• Press SLEEP once to check the
remaining sleep time. Press SLEEP
repeatedly to select another sleep
time.
To cancel the sleep mode:
• If you decide to turn off the unit
sooner, press SNOOZE, OFF or press
SLEEP repeatedly to select "OFF".
When the sleep mode is
activated again, the sleep
setting will be the same as the
one you have set before.
or
Audiovox Electronics Corp.
150 Marcus Blvd., Hauppauge, NY 11788
©2009 Audiovox Electronics Corp.
Trademark(s) ® Registered
Marque(s) ® Deposée(s)
Marca(s) ® Registrada(s)
www.rcaaudiovideo.com
Printed in China
