  • Page 1 LCD TV RLC1909...

  • Page 2: Table Of Contents

    Table of Contents Caution Important Safety Precautions INSTALLATION Top/Side panel diagram Remote Controller Battery Installation Using the Remote Control Install TV Set your TV Connect Antenna and power Turn On TV PICTURE MENU SOUND MENU TUNE MENU FUNCTION MENU PARENT CONTROL CHANGE PASSWORD TV RATOMG OSD MENU...

  • Page 3: Caution

    Caution The lightening flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated "dangerous voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 4 Caution: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.2 19) Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted candles). 20) Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

  • Page 5: Installation

    STANDARD INSTALLATION The TV can be installed in various ways such as on a wall, or on a desktop etc. The TV is designed to be mounted horizontally. Ensure that you connect the earth ground wire to prevent possible electric shock. if grounding methods are not possible, have a qualified electrician install a separate circuit breaker.
  • Page 6 STANDARD INSTALLATION b. Wall Mount: Horizontal installation (1) Secure the wall brackets with the bolts(not provided as parts of the product, must purchase separately) on the wall.Match the height of the bracket that is mounted on the wall. The wall bracket is of nomal dimension. Please see the position of the wall brackets bolts as follow picture.
  • Page 7 NOTES OF WALL INSTALLATION (1) Keep the TV stand for may be future use. (2) Don’t set the TV set on shelves, carpets, beds, or closets. (3) Don’t cover the TV with curtain or paper. (4) Leave ventilation space to avoid the following: No good for ventilation No good for ventilation...
  • Page 8 Top panel diagram...

  • Page 9: Top/Side Panel Diagram

    INPUT VIDEO OUTPUT VIDEO YPbPr:Color difference components input and relevant video input S-VIDEO: Color and brightness difference components input. AV Output VGA/AUDIO: VGA audio input. Side panel diagram S-VIDEO VIDEO ANT 75 ohm: Connect the antenna to the antenna input. HDMI Input: Digital signal input from HDMI video connector 14/15.

  • Page 10: Remote Controller

    POWER : Sets your TV to power on or standby mode. MUTE : Press to mute the sound. Press again or press VOL+ to unmute. 3 0--9 Press 0~9 to select a TV channel directly while watching TV. The channel will change after 2 seconds.Applicable for entering page number in teletext mode and so on.
  • Page 11 side DC 12V AV Input/Output S-Video Input AV2 Input/Y Pb Pr Input VGA Input HDMI Input indicator...
  • Page 13 Press Menu to exit sub-menu.
  • Page 14 memory 2. In Advance item, Press button to enter sub menu, as below figure. 2.1. 2.2.
  • Page 15 PG13 NC17 NONE Empty Empty 8 ANS + 13 ANS + 18 ANS + 16 ANS +...
  • Page 16 CHANNEL...
  • Page 18 1366...

  • Page 19: Resolution

    Ripping line in Please use good quality connecting cable. RCA connecting Unplug the power cable and wait for 30 seconds, then connect.If there is Problem still some problem with our TV, do not repair it by yourself, please contact with exist the customer service center.

  • Page 20: Specifications

    SPECIFICATIONS Screen Size NTSC M PAL M/N TV system Video system NTSC/PAL AIR：2-69 Preset Channels VGA, A/VX2, S-VIDEO, HDMI, Y PBPR, Input/Output ANT 75 Audio output power 3Wx2 DC 12V Power requirement <48W Max. power consumption User's manual Accessories AC adaptor CATV ：1-125 Ω...
