USER MANUAL
RTD615i
It's important to read this instruction prior to using your new product for the first time.

Connections and Setup

Accessories provided
OK
+ -
+ -
RCR 192 AA8
Remote control and 2 Left and right Centre speaker Subwoofer Left and right Sur-
AAA batteries front speakers round speakers
One Pig-Tail Composite One external AM
antenna wire video cable loop antenna
Things to consider before you connect Connecting the antennas
• Ensure that the mains supply in your house
FM75 Ω
complies with that indicated on the identification
sticker located on the back of your unit.
White
• Install your unit horizontally, away from
Antenna
any source of heat (fireplace) or appliances
creating strong magnetic or electric fields. The
components of this unit are sensitive to heat.
GND
The maximum ambient temperature should not
exceed 35°C / 95°F. The AM and FM antennas connect to the AM and
• Leave enough space around the unit to allow FM terminals on the system's back panel. They
must be hooked up in order to receive clear recep-
adequate ventilation: 10 cm/4 inches on either side
and above the top, and 5 cm/2 inches at the rear. tion.
• The humidity of the room should not exceed
AM Loop Antenna
75%. If you have to use the unit outdoors, do not
expose it to rain or splashing water. The apparatus
1. Uncoil the AM antenna wire.
should not be exposed to dripping or splashing
2. Press down on the antennas tab to open the
and no objects filled with liquids, such as vases,
terminal.
should be placed on the apparatus.
3. Make sure the white wire on the AM loop antenna
• Moving the unit from a cold place to a warm one
is inserted into the AM loop terminal and the other
can cause condensation on some components
wire is inserted into the ground loop terminal.
inside the unit. Let the condensation disappear
on its own before turning the unit on again.
• Before moving the unit, make sure the disc tray
is empty.
• Where the mains plug or an appliance coupler
is used as a disconnect device, the disconnect
device shall remain readily operable.
• Other important use and cleaning information
at the end of the booklet.
-5-
Connections and Setup
Better surround placement
Location
No adjacent walls
If possible, place surround speakers to either side
Surround speakers can go on stands facing each
of the listening area, not behind it. other to approximate sidewall mounting (A), or to
the sides or rear of the viewing area, aimed upwards;
Height
they can go right on the floor, or preferably, a few
If space permits, install surround speakers 2-3 feet
feet off the floor such as on end tables (B).
above viewers. This helps to minimize localization
effects.
Aiming
Aim surround speakers straight across the room,
not down at viewers, to help create a more open,
spacious surround sound field.
Test tone/Channel balance
Channel balance
Your receiver is equipped with a test signal generator
to help balance the audio level for each channel.
See Audio Setup under The Setup Menu section for
more details on how to access this feature.
Level adjustment and surround channel level
expectation
Alternative Surround Placement
Even though you adjust the surround channel to
Rear wall
be as loud as the others on the test signal, you
If rear wall mounting is the only choice, aim the
may find that surround channels seems quieter
speakers at each other (A), towards the front (B) or
for actual TV and Movie content. This is because
towards the sidewalls (C, D).
producers use surround for subtle atmospherics
Experiment with placement until sounds seem to
and ambience, and only rarely for special effects.
surround you, rather than come from behind you.

Overview of Controls - Front Panel Controls

Open and close Adjust the Switch the unit
the disc tray. volume. on and off.
iPod docking AUDIO IN jack - Start/pause Stop disc Select the input sources. Press repeatedly
compartment to connect playing a disc playback. to select:
• DVD/ iPod – to access DVD/ iPod mode.
portable audio
• TUNER – to listen to the radio.
players.
• AUX (rear) / AUDIO IN (front) – to listen to
the audio input from the connected TV,
VCR or SAT/Cable Box.
• OPTICAL (rear) - to connect to digital audio
-10-
components
STS8615i IB Mar 7.indd 1

FCC Information

This device complies with part 15 of the FCC Ventilation
Rules. Operation is subject to the following two You must adequately ventilate the product. Make
conditions: (1) This device may not cause harmful
sure there is adequate space around the unit to
interference, and (2) this device must accept any
provide proper air flow for ventilation. See dia-
interference received, including interference that
gram.
may cause undesired operation.
7 cm
This equipment has been tested and found to
comply with the limits for a Class B digital device,
10 cm 10 cm
pursuant to part 15 of the FCC Rules. These limits
A U D I O I N
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses 7 cm
and can radiate radio frequency energy and, if
10 cm
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
This product complies with DHHS Rules 21 CFR
However, there is no guarantee that interference
Subchapter J. Applicable at the date of manufac-
will not occur in a particular installation. If this ture.
equipment does cause harmful interference
to radio or television reception, which can be For your safety
determined by turning the equipment off and
The AC power plug is polar-
on, the user is encouraged to try to correct the
ized (one blade is wider than
interference by one or more of the following
the other) and only fits into
measures:
AC power outlets one way.
•
Reorient or relocate the receiving antenna.
If the plug won't go into the
• I n c r e a s e t h e s e p a r a t i o n b e t w e e n t h e
outlet completely, turn the
equipment and receiver.
plug over and try to insert it the other way.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
If it still won't fit, contact a qualified electrician to
is connected.
change the outlet, or use a different one. Do not
• Consult the dealer or an experienced radio /
attempt to bypass this safety feature.
TV technician for help.
Removing the power plug is the only way to com-
WARNING: Changes or modifications to this unit
pletely remove power from your product. Make
not expressly approved by the party responsible
sure the power plug remains easily accessible.
for compliance could void the user's authority to
operate the equipment.
Note:
This DVD player is designed and manufactured to
respond to the Region Management Information.
This Home Theater has earned
If the Region number of a DVD disc does not cor-
the ENERGY STAR.
respond to the Region number of this DVD player,
this player cannot play the disc. The Region num-
ber for this DVD player is Region 1.
-1-
Connections and Setup
Connecting to your TV (VIDEO)
Method 2 Method 1 • If your television is a high definition
TV
VIDEO IN television, use the unit's HDMI output
Y to get the highest possible video resolution.
P If unable to use a HDMI connection, use the
B
P VIDEO IN unit's component video output and set the
R
Progressive Scan option in the Video menu
Component
Video
Video Cable to ON, to get the next highest possible video
Cable
resolution.
• If one of the devices is not working, check
Y
Green
that all the cables have been inserted
P
Blue B
properly into the jacks.
R
P
Red R
• If your component has only one input for
L
COMPOENT VIDE audio (mono), connect it to the left (white
(REGULAR AND PROG SCAN)
L/Mono) audio jack on the TV and don't
connect the right audio part of the cable.
Method 1
Composite video jack (yellow)
• The basic video jack is color-coded yellow. Connecting to your TV (via HDMI input)
• Video cable (yellow) is supplied for the connection
HDMI stands for High Definition Multimedia
for good picture quality.
• Connect the video OUT jack on the receiver to Interface. HDMI transfers digital audio and
the Video IN jack on your TV so the video content uncompressed digital video on a single cable.
Press the HDMI button on the remote control to
goes from the receiver to the screen.
change output signals as follows: 480p, 720p,1080i
Method 2 and 1080p.
Component video jacks (Pr, Pb, Y)
• The component video jacks are color-coded green,
blue and red.
TV
• Additional component video cables (not supplied)
are required to provide best picture quality. They HD MI
are usually color-coded green, blue and red.
To HDMI
• Connect the component video OUT jacks on the input
HDMI cable
receiver to the component video IN jacks on your
(not s upplied)
TV so the video content goes from the receiver to
the screen.
To HDMI Y
output
P
B
R
P
R
L
COMPOENT VIDEO
HDMI (REGULAR AND PROG SCAN)
Note:
• Refer to the owner's manual of the connected
TV as well.
-6-
Overview of Controls
ON•OFF: Turn on/off the unit.
Switch between DVD and iPod mode.
DVD/iPod:
TUNER : Select the TUNER and selects between FM/
AM.
AUDIO/AUX: Select and toggle between the Front AUDIO
IN mode and the Rear Auxiliary input (for
listening to audio input from connected TV,
VCR or SAT/Cable Box).
0-9: Number entry.
CLEAR: Quit the current setting manually from the
TV screen without saving change.
Access the Info menu.
INFO:
OPTICAL: Select digital audio input.
TITLE: Access the title menu of DVD discs.
DISC MENU: Access the disc menu during playback.
OK: Confirm your selection.
:
Navigate through the menus. The left and
right arrows also tune the radio frequency in
OK
the tuner mode.
MUTE: Mute and restore the sound.
SETUP: Enter Setup menu.
RETURN:
In DVD mode, return to the previous menu.
VOL +/- : Adjust the sound volume.
CH+/ , CH–/ : Directly access the next or previous chapter
(DVD) or track (CD). Select programmed
stations in TUNER mode.
REV:
Start reverse accelerated play.
PLAY: Start playing a disc.
FWD: Start forward accelerated play.
SLOW: Select SLOW motion function.
STOP: Stop playback.
PAUSE: Freeze frame, access frame advance.
AUDIO: Access the audio function.
ANGLE: Access the camera angle function for DVD disc.
ZOOM: Access the Zoom function.
SUBTITLE:
Select the subtitle languages or turns
subtitle off ( if available).
HDMI: Change video output signals (480p, 720p,
1080i or1080p).
SUBWOOFER: Select among subwoofer output levels (soft/
balance/strong/powerful).
RANDOM: Turn on/off random playback on CDDA/
jpeg discs.
REPEAT: Access the repeat function.
LEVEL: Toggle channels for different level settings.
RCR 192 AA8
Adjust the value using VOL +/-.
-11-
FCC Information
THE LIGHTNING FLASH AND ARROWHEAD
WITHIN THE TRIANGLE IS A WARNING SIGN
ALERTING YOU OF "DANGEROUS VOLTAGE"
INSIDE THE PRODUCT.
THE EXCLAMATION POINT WITHIN THE TRI-
ANGLE IS A WARNING SIGN ALERTING YOU OF
SEE MARKING ON BACK OF PRODUCT
IMPORTANT INSTRUCTIONS ACCOMPANYING
THE PRODUCT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSON-
NEL.
WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE.
WARNING: TO BE COMPLETELY DISCONNECT THE POWER INPUT , THE MAINS PLUG OF APPARA-
TUS SHALL BE DISCONNECTED FROM THE MAINS. THE MAINS PLUG OF APPARATUS SHOULD NOT
BE OBSTRUCTED OR SHOULD BE EASILY ACCESSED DURING INTENDED USE.
Service information DVD copy protection
This product should be serviced only by those In accordance with the DVD standard, your DVD
specially trained in appropriate servicing player is equipped with a Copy Protection system,
techniques. which can be switched on and off by the DVD
disc itself, in order to make any recording of the
Main plug is used as the disconnect device,
relevant DVD disc onto a videotape of very poor
it shall remain operable and should not be
picture quality, or even impossible. This product
obstructed during intended use. To be completely
disconnected the apparatus from supply mains, the incorporates copyright protection technology
that is protected by method claims of certain U.S.
main plug of the apparatus shall be disconnected
patents and other intellectual property rights
from the mains socket outlet completely.
owned by Macrovision Corporation and other
Caution
rights owners. Use of this copyright protection
Invisible laser radiation when open and interlocks
technology must be authorized by Macrovision
defeated. Avoid exposure to beam. Class 1 laser
Corporation, and is intended for home use only
product.
unless otherwise authorized by Macrovision
This system must be opened only by qualified
Corporation Reverse engineering or disassembly
technicians to prevent accidents caused by the
is prohibited.
laser beam.
-2-
Connections and Setup
Digital Optical Input
Connecting AUDIO from external
sources such as TV
Connect components capable of outputting Dol-
by digital (e.g. TV or SAT/Cable Box) or standard
Using AUX jack
PCM (CD) format digital signals. Use a fiber optical
Connect the AUX jacks from the unit to the AUDIO
cable for this digital audio connection. (cable not
OUT jacks on VCR, TV, SAT/Cable Box or other
included).
component.
Press OPTICAL key on remote control or SOURCE
key on main unit to select OPTICAL IN for digital
TV
SAT/ audio output components.
VCR Cable Box
AUDIO OUT
OR
OR
TV SAT/
Cable Box
OR
OPTICAL
Audio OU T
Y
cable
Red
P B
R
P White
R
L
OPTICAL
COMPOENT VIDEO IN
(REGULAR AND PROG SCAN)
Using AUDIO IN jacks
Connect the Ø3.5mm AUDIO IN jacks on the front
panel of the unit to the headphone output on mp3
players.
Notes:
• Ø3.5mm to Ø3.5mm audio cables (not
included).
• Press either SOURCE on the main unit or AUDIO/
AUX on the remote control to select AUDIO IN
mode.
• To listen to the audio input from the connected
component, press SOURCE on the main unit or
AUDIO/AUX on the remote control to select the
AUDIO IN mode.
Suggest using Ø3.5mm AUDIO IN jack for
MP3 player and AUX IN jacks for auxiliary
equipment such as DVD, VCR or PC.
-7-
Overview of Controls Playing Discs - Basic Functions
SURROUND: Changes the Surround sound setting.

Compatible discs

In DVD mode, press the button to
• DVD
select between 5.1 ch and STEREO
• CD, CD-R, CD-RW
modes. In the AUDIO/ AUX mode
Compatible formats
(analog input), press the button to
• DVD, JPEG
select between 5.1 CHANNEL and
• CD
STEREO modes. (Refer to details
on "Sound Enhancement Systems"

Regional coding

under "additional information"
Your unit has been designed to process regional
section below.)
management information stored on DVD discs.
The regional code for your unit is 1. Discs that
Remote control functions in tuner mode
have a different regional code will not play.
TUNER: Select the TUNER and switch be-
tween FM/AM.

Operating the DVD receiver

VOL+/–: Adjust the sound volume.
1. Turn on your television set.
MUTE: Mute and restore the sound.
2. Press ON•OFF on the remote control or ON/
TUNER +/–: Tune down and up the radio fre-
STANDBY located on the unit's front panel.
quencies.
Press DVD on the remote control.
MEMORY: Store a station.
Loading disc
CH+/ /CH–/ : Select programmed stations.
AUDIO: Select between Stereo and Mono 1. Press on the front panel to open the disc
mode for Tuner (FM).
tray.
2. Place a disc onto the disc tray with the label
Using remote control to navigate through side up.
the on-screen menus
3. Press again to close the disc tray.
Use , , , buttons and OK on the remote Playback
control to navigate through the on-screen displays
Switch the unit and the TV set on.
(the DVD player's menu, the Info Display that ap-
1. After loading a disc, playback starts automatically,
pears during playback, or a disc's menu).
or the disc menu appears. If the disc menu
appears, select the Play option to begin
Use , , , buttons on the remote control
playback.
to move through on-screen menus in the direc-
2. Press STOP to stop playback.
tion of the button (e.g., to move right, press ).
The buttons are used to highlight an option. Once
Accelerated play
highlighted, press OK to select the option that is
While the disc is playing, press REV or FWD one or
highlighted.
more times to vary the speed and direction of the
accelerated play. Press PLAY to resume normal
playback.
Note: Pause
Insert 2 "AAA" batter ies into the re- While the disc is playing, press PAUSE once for
mote control prior to use.
freeze frame. Press PLAY to resume normal play-
back.
Frame advance
1. Press PAUSE twice. "Step" is displayed.
2. Each time you press PAUSE button, the picture
advances one frame.
3. Press PLAY to resume normal playback.
-12-
Important Information
Important battery information
CAUTION:
• Do not mix different types of batteries or new and This product utilizes a laser. Use of controls or
old batteries. Do not use rechargeable batteries. adjustments or performance of procedures other
• In order to avoid any risk of explosion, observe than those specified may result in hazardous
the polarities indicated inside the battery radiation exposure. Do not open covers and do
compartment. Replace only with the type of not repair yourself. Refer servicing to qualified
batteries specified. Do not dispose of them in a personnel.
fire or recharge them.
• If you are not using the remote control for a long
This class B digital apparatus complies
period of time, remove the batteries.
with Canadian ICES-003.
Cet appareil numérique de la classe B
Please respect the environment and
est conforme à la norme NMB-003 du
prevailing regulations. Before you
Canada.
dispose of batteries or accumula-
tors, ask your dealer whether they
are subject to special recycling and if WARNING
they will accept them for disposal. To reduce the risk of fire or electric shock,
do not expose this product to rain or
Illustrations contained in this document are for rep-
moisture. No objects filled with liquids,
resentation only.
such as vases, should be placed on the
apparatus.
-3-
Connections and Setup
Connecting the speakers
Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each
speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the termi-
nal and insert the wire. Release the tab to lock wire in the terminal.
Front Speakers
Centre
Speaker
Right
Left
Green and
Purple and Black
Black
Red and White and
Black Black
Insert
Subwoofer
Press
Gray and
Blue and
Black
Black
Release
Rear Speakers
(Surround Sound)
Right Left
Note:
When connecting the speakers, make sure the polarities ("+" speaker wire to "+" on the re-
ceiver) of speaker wires and terminals match. For example, red wire to red terminal on the
receiver. If the cords are reversed, the sound will be distorted. Do not let the speaker wires
touch each other, it will damage the speaker.
-8-
Basic Playback Operations
Variable slow motion Types of menus
1. Press SLOW button on the remote control in play • Disc menu — The appearance and contents of
mode. this menu varies according to the type of disc
2. Each time the SLOW button is pressed the speed
you have inserted. It is separate from the Setup
of slow-motion playback changes in the follow- menu.
ing sequence: • Info menu — The unit's Info menu appears at
the top of the screen while the disc is playing.
X1/ 2 SF 1/ 3 X SF X 1/4 SF 1/ 5 X
Press INFO on the remote control to switch the
Info menu on or off.
PLAY SF 1/ 7 X SF 1/ 6 X
TT CH
3. Press PLAY to resume normal playback.
• Setup menu — Press SETUP to access this
Changing chapter/track
menu.
While the disc is playing, press the CH+/ , CH–/
button to go immediately to the next or previous
chapter, or to the next or previous track.
Zoom
General Setup
1. While a disc is playing, press ZOOM until you
reach the zoom size you want. The ZOOM button Video
HDMI Setup
toggles through X2, X3, X4 and then zooms out
TV Type
to X1/2, X1/3 and X1/4, then returns to normal
playback.
2. Move from one area to another (pan) using the
Default
buttons.
3. To turn ZOOM off, press ZOOM until you get to
the ZOOM OFF option.
Note:
When you press STOP, the unit stores the
point where playback was interrupted. If
you press PLAY again, playback resumes
from this point.
To stop playback completely or to start
again from the beginning, press STOP
twice. If the unit is left in STOP mode for
more than 5 minutes without any user
interaction, a screen saver is activated.
At the end of 30 minutes without any
user interaction, the unit switches off
automatically.
-13-

Important Safety Instructions

Please read and save for future reference. Additional safety information
Some of the following information may not apply • The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
to your particular product; however, as with
any electronic product, precautions should be such as vases, shall be placed on the apparatus.
• Always leave sufficient space around the product
observed during handling and use.
for ventilation. Do not place product in or on a bed,
• Read these instructions.
rug, in a bookcase or cabinet that may prevent
• Keep these instructions.
air flow through vent openings.
•
Heed all warnings.
• Do not place lighted candles, cigarettes, cigars,
• Follow all instructions.
etc. on the product.
• Do not use this apparatus near water.
• Connect power cord only to AC power source as
• Clean only with a dry cloth.
marked on the product.
• D o not block any ventilation openings.
• Care should be taken so that objects do not fall
Install in accordance with the manufacturer's
into the product.
instructions. • Do not attempt to disassemble the cabinet. This
• Do not install near any heat sources such product does not contain customer serviceable
components.
as radiators, heat registers, stoves, or other
apparatus (Including amplifiers) that produce
If your product operates on batteries, adhere to
heat.
the following precautions:
• Only use attachments / accessories specified by
the manufacturer.
A. Any battery may leak electrolyte if mixed with a
• Do not defeat the safety purpose of the
different battery type, if inserted incorrectly, or if
polarized or grounding-type plug. A polarized all batteries are not replaced at the same time.
plug has two blades with one wider than the B. Any battery may leak electrolyte or explode if
other. A grounding type plug has two blades disposed of in fire or an attempt is made to charge
a battery not intended to be recharged.
and a third grounding prong. The wide blade or
C. Discard leaky batteries immediately. Leaking
the third prong is provided for your safety. If the
batteries can cause skin burns or other personal
provided plug does not fit into your wall outlet,
injury. When discarding batteries, be sure to
consult an electrician for replacement of the
dispose of them in the proper manner, according
obsolete outlet.
to your state/provincial and local regulations.
• Protect the power cord from being walked on
D. Battery shall not be exposed to excessive heat
or pinched particularly at plugs, convenience
such as sunshine, fire or the like.
receptacles, and the point where they exit from
the apparatus.
• Unplug this apparatus during lightning storms
or when unused for long periods of time.
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as the power
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been
dropped.
-4-
Connections and Setup
Front speaker placement
Positioning speakers
For best results, follow the speaker placement
3
below.
1
Alignment
Align the centre speaker evenly with (A) or slightly
behind (B) (the left and right speakers), but not
2
ahead of them.
1
3 4
Courtesy Dolby Laboratories
1. Left, Right (Front Speakers)
Front speakers carry primarily music and sound
effects.
2. Centre
In surround mode, the centre speaker carries most
of the dialog as well as music and effects.
It should be set between the left and right
speakers. Angle
Place the left and right speakers to form a 45-de-
3. Surround (Rear Speakers)
gree angle with your favorite viewing position to
The surround speakers' overall sound balance
duplicate the soundtrack mixer's perspective.
should be as close as possible to the front speakers.
Proper placement is vital to establish an evenly
Height
distributed sound field.
The three front speakers should be as close as
possible to the same height. This often requires
4. Subwoofer
placing the centre speaker directly on top (A) or
A subwoofer is designed to reproduce powerful
beneath (B) the TV set.
low bass effects (explosions, the rumble of
spaceships, etc.).
A
Note:
Front, Centre speakers provided with this
unit are magnetically shielded to protect
your TV set. It is not recommended to
place the surround speakers or subwoofer
B
near the TV set.
-9-
The Info Menu
The Info Menu Title/chapter (DVD)/track (audio CD)
1. Press INFO on the remote control while a disc is To directly access a title, chapter (DVD) or a track
playing to display the info menu. The first banner (audio CD), press INFO, press OK.
Select the Title (TT), Track (TRK) or Chapter (CH)
shows title, chapter, and time display information.
icon and enter a number directly with the numeric
2. Press INFO again for audio language, subtitles,
and camera angle. buttons. Press OK again to confirm.
3. Press INFO a third time for play mode, bookmark
and sleep timer.
Note: Many discs only have one title.
4. Use the right/left buttons on the remote control
to select an icon.
5. Use the up/down buttons to scroll through the
Time display
options.
To access the Time Display, press INFO on the remote
control. Press the up/down buttons repeatedly to
display:
Note:
DVD: Chapter Time Elapsed, Chapter Time
INVALID KEY will be displayed if the
Remain, Title Time Elapsed and Title
function you select is not available.
Time Remain.
Audio CD: Track Time Elapsed, Track time Remain,
Disc Time Elapsed and Disc Time
DVD Info Display
Remain.
Chapter Time display
Title
To directly access a location on the disc which does
not correspond to the start of a title or
TT CH
chapter, press INFO once and press OK,
Audio language Subtitles Camera angle highlight the Time Display icon using
the buttons, then enter a time with the
5.1C H O F F number buttons (hh:mm:ss) and press
OK.
Play mode Bookmark Sleep timer
Note: Time display function may not
be available on all discs.
CD Info Display
Track Time display Audio (DVD)
Some discs have several audio tracks used for
TRK
different languages or different audio formats.
To change the language or audio format during
Play mode Bookmark Sleep timer
playback:
1. Press the INFO button twice.
2. Use the left/right buttons to select the Audio
icon, or press the AUDIO button on the remote
control.
3. Choose a language or an audio format with the
up/down buttons.
-14-
3/9/2009 5:46:14 PM
