RCA DRC246N User Manual

The Dolby Digital* Setup Menu
Dynamic
Dolby
This feature monitors the audio track and
controls the different sound levels via dynamic
-- Dolby Digital Setup -- compression. It minimizes sudden volume
increases such as when a commercial starts.
Dynamic Full
3/4
Select a range using the  andbuttons and
1/2
press OK.
1/4
OFF
The Preferences Setup Menu
The menu gives you options to change some aspects of your DVD player to fit your
personal preferences.
Audio: Selects the dialogue language: English,
Preferences
French or Spanish.
Subtitle: Selects the subtitle language: English
-- Preferences Setup Page --
French or Spanish.
Audio Eng English
Disc Menu: Selects the disc's menu language:
Subtitle Eng English
English, French or Spanish.
Disc Menu Eng English
Ratings 1 Kid Safe Notes: Discs are created differently.The DVD player can't
Password Change override some language preferences. If a disc's software
was created to play the movie (title) in a perferred
language, the preference you set might be ignored.
Also, if the language isn't available on the disc you're playng the disc's default language will be chosen.
If the disc wasn't created with subtitles, you won't be able to use the Subtitle feature.
Ratings: Lets you determine what types of discs can be played in the player, and what
types of discs will require a password to override the rating limit that you've set. The
system ranks the ratings from 1 to 8 in order to accommodate the rating systems
used in other countries. (Level 1 is considered material that is least offensive and
appropriate for young audiences. Level 8 is considered the most offensive.)
Note: In order for the Rating Limits to be enforced, the disc you're playing must contain a movie (or a title)
that is rated.
Password: Password is not defined until you set it. Should you select a password and
then forget it, go to the Troubleshooting section for instructions on resetting.
Note:There is a lock feature on your DVD player if you want to prevent your child from watching
DVDs (don't forget to remove the remote control). Follow the directions for locking and unlocking in the
Troubleshooting section.
Troubleshooting
You can correct most problems you have with your product by consulting the
Troubleshooting list that follows.
Note: If you prefer, we can provide you with the name of an Authorized Service Representative who will
visit your home for a fee to install your electronic entertainment system and to instruct you in its operation.
For details about this service, call 1-888-206-3359. For additional assistance while using your RCA product,
please visit www.rca.com/customersupport.
Player won't work or no power
• Try unplugging the AC power cord, wait two minutes, and plug it back in.
The remote control does not work
• Remember to point the remote control at the front of your player (towards the
infrared remote sensor). Make sure there are no objects between the remote and
the player.
• Maybe the batteries in the remote are weak, dead, or installed incorrectly. Replace
the batteries and make sure the polarity of the terminals (+ and -) is correct.
• Operate the remote control at a distance of no more than 20 feet.
Disc won't play
• Insert a disc with the label side facing up.
• Check the type of disc you put into the disc tray. Refer to Compatible Disc
section.
• Make sure the regional code of the disc is Region No. 1.
Forgot password
• Open the tray and press CLEAR, 0,0,0,0,1.Turn off DVD player and then turn it on
by pressing the ON/OFF key, or you can unplug the unit, wait a few seconds and
plug it in again.
Lock/Unlock DVD player
• To lock player, open tray and press SETUP, 0, 0, 0, 8, 3 (an on-screen message, "Key
Lock On" is displayed).
• To unlock, press SETUP, 0, 0, 0, 8, 3.
Play starts, but then stops immediately
• The disc is dirty. Clean it.
• Condensation has formed. Allow player to dry out.
Picture format does not match the screen format.
• The picture format is adjustable, refer to SETUP menu section. Some discs dictate
the format, in which case no adjustment is possible.
Picture is distorted
• The disc might be damaged.Try another disc.
• When using FORWARD or REVERSE buttons, it is normal for some distortion
while scanning.
Sound problems
• Adjust the volume control.
• If a TV is used, check whether the sound is muted or turned down low.
• You may need to readjust the settings in the AUDIO menu.
• Sound is muted during still, frame advance, or slow-motion play.
Menu problems
• With a DVD: the disc menus are not displayed in your language. Read the disc
jacket to see what languages are available on that disc. Choose one that suits you, if
possible.
• With a DVD: there are no subtitles. Read the disc jacket to see if subtitles are
available on that disc. Choose subtitles in a language that suits you if possible.
• If the player's setup menus are not displayed in the language you want, check that
your language is among those listed in the MENU LANG menu. If necessary,
choose another language.
• To clear a menu from the screen, pressbutton or repeatedly press SETUP.
The invalid icon ( ) appears on screen
• The action cannot be completed at this time for one of the following reasons: the
disc's software restricts it; the disc's software doesn't support that feature (e.g.,
angles); the feature is not available at the moment; you've requested a title or
chapter number that is out of range.
Ratings problems
• If you forget your password, go to "Forget Password" information in this section.
• The default language for dialogues and subtitles may be preset by the DVD.
Limited Warranty
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• 90 days from date of purchase - Unit exchange, which includes parts and labor.
• 91 days to 1 year from date of purchase - Unit exchange, which includes parts only; you pay the
labor.
• The warranty for rental units begins with the first rental or 45 days from date of shipment to
the rental firm, whichever comes first.
What we will do:
During the initial 90 days:
• Provide you with a new, or at our option, a refurbished unit. The exchange unit is under
warranty for the remainder of the original product's warranty period.
After the 90 days and within one year:
Provide you with a new, or at our option, a refurbished unit. The exchange unit is under warranty
for the remainder of the original product's warranty period. We will bill you a flat exchange
charge to replace a defective unit. This charge covers the labor cost for its repair.
How to make a warranty claim:
• Properly pack your unit. Include any cables, etc., which were originally provided with the
product. We recommend using the original carton and packing materials.
• Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the
product is within the warranty period must be presented to obtain warranty service. For rental
firms, proof of first rental is also required.
• Also print your name and address and a description of the defect. Send via standard UPS or its
equivalent to:
Thomson Inc., 11721 B Alameda Avenue, Socorro,Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
• Insure your shipment for loss or damage. Thomson accepts no liability in case of damage or loss
en route to Thomson.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty does not cover:
• Acts of nature, such as but not limited to lightning damage.
• Adjustment of customer controls.
• Damage from misuse or neglect.
• A unit that has been modified or incorporated into other products or is used for institutional
or other commercial purposes.
• Batteries.
• Units purchased or serviced outside the U.S.A.
• Shipping damage if the unit was not packed and shipped in the manner prescribed by Thomson.
Product Registration:
Please complete the online Product Registration on www.rca.com/productregistration or complete
and mail the Product Registration Card packed with your unit. It will make it easier to contact you
should it ever be necessary. The return of the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS
PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE
HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON
INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY
INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT
OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE
GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW,ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to warranty:
• Some states do not allow the exclusion nor limitation of incidental or consequential damages,
or limitations on how long an implied warranty lasts, so the above limitations or exclusions may
not apply to you.
• This warranty gives you specific legal rights; you also may have other rights that vary from state
to state.
©2004 Thomson, Inc
Trademark(s) ®Registered, Marca(s) Registrada(s)
4

DVD Player

User's Guide
DRC246N
Changing Entertainment.Again.
WARNING
To reduce risk of electrical shock, do not remove
cover or back (no user serviceable parts inside).
RISK OF ELECTRIC SHOCK.
Refer servicing to qualified personnel.
DO NOT OPEN.
This symbol indicates "dangerous voltage"
inside the product that presents a risk of
electric shock or personal injury.
WARNING:
Handling the cord on this product or cords associated with accessories
sold with this proudct, will expose you to lead, a chemical known to the State of California to
cause birth defects or other reproductive harm. Wash hands afer handling.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect this equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This class B digital apparatus meets all requirements of the Canadian Interference--Causing
Equipment Regulations.
The Shock Hazard Marking and Associated Graphical Symbol is provided on the bottom panel of unit.
Refer to the identification/rating label located on the back panel of your product for its proper
operating voltage.
Caution: To prevent electric shock, match wide blade
of plug towide slot, fully insert.
Attention: Pour éviter les chocs électriques,
introduire la lame la plus large de la fiche dans la borne
correspondante de la prise et pousser jusqú au fond.
Product Registration: Please fill out the product registration card (packed separately) and
return it immediately. For U.S. customers:Your RCA Consumer Electronics product may also be
registered at www.rca.com/productregistration. Registering this product allows us to contact you
if necessary.
Keep your sales receipt to obtain warranty parts and service and for proof of purchase.Attach
it here and record the serial and model numbers in case you need them.The numbers are
located on the back of the player.
Model number: Serial Number:
Purchase date:
Dealer address and phone:
WARNING:To reduce the risk of fire or CAUTION:THIS PRODUCT UTILIZES
shock hazard, do not expose this DVD player A LASER. USE OF CONTROLS OR
to rain or moisture. No objects filled with ADJUST-MENTS OR PERFORMANCE OF
liquids, such as vases, shall be placed on the PROCEDURES OTHER THAN THOSE
apparatus. SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO
CAUTION: FCC Regulations state that
NOT OPEN COVERS AND DO NOT REPAIR
unauthorized changes or modifications to this
YOURSELF. REFER SERVICING TO QUALIFIED
equipment may void the user's authority to
PERSONNEL.
operate it.
This DVD player is designed and manufactured
Note:This device is protected by U.S. patent
to respond to the Region Management
numbers 4,631,603 and 4,577,216 and
Information. If the Region number of a DVD
4,819,098 and other intellectual property
disc does not correspond to the Region
rights.The use of Macrovision's copy
number of this DVD player, this DVD player
protection technology in the device must be
cannot play the disc.The Region number for
authorized by Macrovision and is intended
this DVD player is Region No 1.
for home and other limited pay-per-view uses
only, unless otherwise authorized in writing
Apparatus shall not be exposed to dripping or
Printed in China
by Macrovision. Reverse engineering or
splashing and that no objects filled with liquids,
TOCOM 16500260
disassembly is prohibited.
such as vases, shall be placed on the apparatus.
Setup and Connections
Install Batteries in the Remote
Insert two AA batteries, matching the polarities
indicated inside the battery compartment.
Notes: Do not mix different types of batteries or new and
old batteries.
Do not use rechargeable batteries.
Dispose of batteries in the proper manner, according to
federal, state, and local regulations.
Connection: DVD +TV
L
R
Red
White
INPUT
L
This symbol indicates
important instructions
Note: Whenever you are connecting your system cables, turn off the power and make certain that the
accompanying the product.
power cord has been removed from the wall outlet.
1. Connect the audio cables to the AUDIO OUT L and R jacks on the back of your
DVD player and to the corresponding AUDIO INPUT jacks on your TV.
2.
Connect the video Cable.
2a. Basic connection – Connect the video cable to the VIDEO OUT jack on the
back of the your DVD player, and to the VIDEO INPUT jack on your TV.
2b. S-Video (not shown) – If your TV has an S-Video jack, connect the S-Video
cable (not provided) to the S-VIDEO on the DVD to the S-VIDEO of your TV.
Note: If your TV doesn't have Audio and Video Input Jacks and only has an RF jack, you need to connect an
RF modulator (not provided).
Other Connection Options
COMPONENT VIDEO OUT (Y, Pb, Pr) Jacks
COMPONENT
The Y, Pb, Pr, jacks provide optimum picture quality
VIDEO OUT
because the video signal is separated into three
Y
parts.
To ensure maximum picture quality, use three
P
P
B R
video-grade cables (yellow) for the connection.You
can also buy bundled component video cables that
are color-coded to match the Y, Pb, Pr jacks (red,
green, and blue)
Note: Remember to connect the audio cables because the
component cable carries only the picture signal, not the sound.
Component Video Cables
CLASS 1
LASER
PROGRESSIVE SCAN ON/OFF Switch
PRODUCT
OFF
ON
If you connect the DVD Player to a TV that is
capable of using progressive scan technology, you
need to use the Y, Pb, Pr jacks and video cables. It is
PROGRESSIVE
essential to turn the PROGRESSIVE SCAN switch
SCAN
to the ON position. If you use S-VIDEO OUT or
VIDEO OUT jacks for your connection, leave the
switch in the OFF position.
Note: If your TV or monitor has progressive scanning capability,
you need to turn the switch on the back of the DVD player to
the PROGRESSIVE SCAN ON position.
DIGITAL OUT COAXIAL/OPTICAL
DIGITAL OUT
(Audio)
Use one of these jacks to connect your DVD player
to a Dolby Digital* receiver or decoder. Some
receivers have either the COAXIAL or OPTICAL
type of Digital Audio Input jack and some have
COAXIAL OPTICAL
both. Under most conditions, optical and coaxial
connections work equally well––the only difference
is the type of cable you connect to the jack.
Digital Out Digital Out
Note: If the DVD player is connected to a DTS** receiver
Optical Cable Coaxial Cable through DIGITAL OUT and DTS track is selected, there will be
no sound.
*Manufactured under license from Dolby Laboratories."Dolby" and the double-D symbol are trademarks
of Dolby Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories, Inc.All rights
reserved.
**DTS is a registered trademark of Digital Home Theater Systems, Inc.
1
DVD Player
AUDIO
OUT
DIGITAL OUT
VIDEO
S-VIDEO
OUT
COAXIAL OPTICAL
Yellow
TV
AUDIO
VIDEO
R
-OR-
