Page 1 2000 Applications 10 - 19 Deepfat Fryer Applications Guide Programming & Operating Steps TOTAL CUSTOMER SATISFACTION Watlow Controls ISO 9001 1241 Bundy Blvd. P.O. Box 5580 Winona, Minnesota U.S.A. 55987-5580 Registered Company (507) 454-5300, Fax (507) 452-4507 Winona, Minnesota USA WMC2-XAGN-0003-Rev A $5.00...
Page 3: Application 10
Application 10 Automatic Deepfat Fryer with Autolift Control Single Heat Channel, Four Menus Introduction to Application 10 ....1 Configuration Mode Quick Reference ..3 Program Mode Quick Reference .
Page 4 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 5 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 10 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 6 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 10 to access them. For menu programming direc- tions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 7 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 8 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Menu 1 Menu 2 Basket up Menu 3 Menu 4 Basket down Startup Apply power to the fryer and add cooking oil if necessary. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt].
Page 9 Start/Stop key indicator light will flash slowly. The temperature of Channel 1 will be displayed until the operating temperature is reached. The heat output indicator light - G, just below the display- will light up whenever the controller is calling for heat. When the fryer is at operating temperature (above relative set point minus the ready band) [ready] will appear on the display and the Start/Stop key indicator light will flash rapidly.
Page 10 the display. (The message, which varies based on programming at [M`__] / [ALArn] will appear for ten seconds.) An audible tone will sound for five seconds. Time will continue to count down on the display. 4. When the cooking cycle is finished the basket will rise automatically. One of the fol- lowing will happen, depending on the way the controller was programmed at [EtypE] / {Sound]: With Sound set to 0: The controller automatically switches to idle, where the con-...
Page 11 lowing will happen, depending on the way the controller was programmed at [EtypE] / {Sound]: With Sound set to 0: The controller automatically switches to idle, where the con- troller maintains the temperatures at set point and does not run time. [`idle] or time of day will appear on the display.
Page 12 Temperature Alarms The controller will alert you to temperature alarm conditions if they occur. If an alarm occurs, take action as determined by your supervisor. See the Appendix in the Hardware & Software Setup Guide for a Troubleshooting Chart and a summary of temperature alarms.
Page 13: Application 11
Application 11 Automatic Deepfat Fryer with Autolift Control Single Heat Channel, 40 Menus Introduction to Application 11 ... . . 11 Configuration Mode Quick Reference ..13 Program Mode Quick Reference.
Page 14 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 15 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 11 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 16 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 11 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 17 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 18 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Operation Function Idle Temperature Number One Idle Temperature Number Two Increment and Basket Up Menu Select Start/Stop Decrement and Basket Down Start-up Apply power to the fryer and add cooking oil if necessary. Select a Menu 1.
Page 19 Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt]. The display will show [Pre-`] [`HEat] followed by oil tem- perature as the oil heats. 2000 2000 2000 [`50`f] [ready] [`idle] Edit Accept...
Page 20 1. Select the menu you want to run as shown earlier in “Select a Menu”. 2. With [`idle] or time of day on the display, press the Start/Stop key. RAPID SLOW FLASH FLASH 2000 2000 2000 [`idle] [pre-`] [`Heat] [100f`] [ready] Edit Accept...
Page 21 With Sound set to 0: The controller automatically switches to idle. [`idle] or cur- rent time will appear on the display. The Start/Stop key indicator light will flash slowly. The controller will maintain temperature at the programmed set point. With Sound set to 1, 2, or 3: [``End] will appear on the display and an audible tone will be emitted.
Page 22 rent time will appear on the display. The Start/Stop key indicator light will flash slowly. The controller will maintain temperature at the programmed set point. With Sound set to 1, 2, or 3: [``End] will appear on the display and an audible tone will be emitted.
Page 23 Manual Basket Lift At any time you can raise or lower the basket manually by using the Down-arrow key (to lower) or the Up-arrow key (to raise). If you raise the basket manually while cooking, the timer will pause. Countdown time will resume when you manually lower the basket or when you press the active menu key.
Page 24 Errors The controller will alert you to errors if they occur. Errors are critical problems that shut down the unit. If an error occurs, an error message will appear on the display. You should switch off the power and call for service. See the Appendix in the Hardware &...
Page 25: Application 12
Application 12 Manual Deepfat Fryer with Autolift Control Single Heat Channel, One Menu Introduction to Application 12 ... . . 23 Configuration Mode Quick Reference ..25 Step 7 Design a Faceplate Overlay .
Page 26 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 27 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 12 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 28 Auto-tuning Note: Before auto-tuning Application 12, [teNp1] in the operations menu must first be set to a value that is typical of your application. (See the Hardware & Software Setup Guide for information on programming menus.) Then set [tHerl] / [tunE1] to [```on]. After you accept [```on], by pressing “Enter,”...
Page 29 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 30 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Temp Time Increment & Basket Up Not Used Start/Stop Decrement & Basket Down Startup Apply power to the fryer and add cooking oil if necessary. Set the Menu Set the cooking temperature.
Page 31 Five Second Timeout When using the up or down keys to change a value, if you do not press any key for 5 seconds, the controller will automatically be set to the last value on the display and return to [`idle]. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt].
Page 32 The Melt Cycle To avoid burning congealed oil (shortening), a slow heating action may be necessary. If this is desired, be sure that in the Configuration Mode [etype] / [melt] has been set to [```on]. Then, when the oil temperature is below 212 ºF the heat output will be lim- ited to 10% of full power.
Page 33 With Sound set to 1, 2, or 3, [``End] will appear on the display and an audible tone will be emitted. The Start/Stop indicator light will flash rapidly. You can acknowl- edge and silence the tone by pressing the Start/Stop key or it will time out in 1 to 20 seconds and go into idle.
Page 34 5. To repeat cooking, repeat steps 1 through 5. Adjust a Menu While Cooking You can adjust the temperature and time settings during the cooking and hold sequences by performing the actions shown under “Set the Menu” earlier in this section. Changes can be made to temperature and time only during the portion of the cooking sequence in which they are active.
Page 35 & Software Setup Guide for a Troubleshooting Chart and a summary of temperature alarms. Errors The controller will alert you to errors if they occur. Errors are critical problems that shut down the unit. If an error occurs, an error message will appear on the display. You should switch off the power and call for service.
Page 36 Notes Watl o w M 2 0 0 0 Ap pl i cati o n 1 2 I N I H E F...
Page 37: Application 13
Application 13 Pressurized Automatic Deepfat Fryer Single Heat Channel, Six Menus Introduction to Application 13 ... . . 35 Configuration Mode Quick Reference ..37 Program Mode Quick Reference .
Page 38 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 39 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 13 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 40 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 13 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 41 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 42 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Menu 1 Menu 2 Menu 3 Menu 4 Menu 5 Menu 6 Startup 1. Apply power to the fryer and add cooking oil if necessary. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt].
Page 43 The heat output indicator light - G, just below the display- will light up whenever the controller is calling for heat. When the fryer is at operating temperature (above relative set point minus the ready band) [ready] will appear on the display and the Start/Stop key indicator light will flash rapidly.
Page 44 the way the controller was programmed at [etype] / [sound]: With Sound set to 0: The controller automatically switches to [`idle], where the controller maintains the temperatures at set point and does not run time. [`idle] or current time of day will appear on the display. The menu key indicator light flashes slowly.
Page 45 flashes slowly. With Sound set to 1, 2, or 3: [``end] will appear on the display and an audible tone will be emitted. The menu key indicator light will flash rapidly. You can acknowl- edge and silence the tone by pressing the active menu key or it will time out in 1 to 20 seconds and go into [`idle].
Page 46 Notes Watl o w M 2 0 0 0 Ap pl i cati o n 1 3 I N I H E F...
Page 47: Application 14
Application 14 Pressurized Automatic Deepfat Fryer One Heat Channel, 40 Menus Introduction to Application 14 ... . . 45 Configuration Mode Quick Reference ..47 Program Mode Quick Reference .
Page 48 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 49 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 14 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 50 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 14 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 51 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 52 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Idle one temperature Idle two temperature Increment Menu select Start/Stop Decrement Start-up Apply power to the fryer and add cooking oil if necessary. Select a Menu 1. Press the Menu Select key. The controller will display the currently selected menu.
Page 53 When the unit reaches initial preheat temperature, [ready] will flash once on the dis- play and an audible tone will sound for 2 seconds. Then [`idle] will appear on the dis- play. (If the Real-time Clock option is installed and [SEtUp] / [Cloc`] is set to [``yes], the time of day will appear on the display.) If the preheat condition is met before power-up, the controller goes directly to idle, and does not display [rEAdy] or sound an audible tone.
Page 54 RAPID SLOW FLASH FLASH 2000 2000 2000 [`idle] [pre-`] [`Heat] [100f`] [ready] Edit Accept Edit Accept Edit Accept Exit Back-Up Exit Back-Up Exit Back-Up AT OPERATING TEMPERATURE (PREHEAT CONDITION MET) If the preheat condition has not been met, the fryer will preheat until appears [ready] on the display.
Page 55 Run A Menu (without preheat feature) This procedure describes how to run a menu when the preheat function is inactive — in other words, when the [Ready] parameter in the [SetUp] function of the Configuration Mode is set to [```no] — and initial preheat power-up has been com- pleted.
Page 56 Event outputs Event output 1 assists in controlling pressure. Event output 1 will switch on when a menu starts and switch off when the time remain- ing is equal to the value programmed in the Configuration Mode under [Etype] / [PtinE].
Page 57: Application 15
Application 15 Pressurized Manual Deepfat Fryer One Heat Channel Introduction to Application 15 ... . . 55 Configuration Mode Quick Reference ..57 Step 7 Design a Faceplate Overlay .
Page 58 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 59 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 15 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 60 Auto-tuning Note: Before auto-tuning Application 15, [teNp1] in the operations menu must first be set to a value that is typical of your application. (See Hardware & Software Setup Guide for information on programming menus.) Then set [tHerl] / [tunE1] to [```on]. After you accept [```on], by pressing “Enter,”...
Page 61 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 62 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Temp Time Increment Not Used Start/Stop Decrement Startup Apply power to the fryer and add cooking oil if necessary. Set the Menu Set the cooking temperature. 1. Press the Temp key [teNp1] and then the cooking temperature value will appear on the display.
Page 63 Five Second Timeout When using the up or down keys to change a value, if you do not press any key for 5 seconds, the controller will automatically be set to the last value on the display and return to [`idle]. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [seTUp] / [Ready].
Page 64 The Melt Cycle To avoid burning congealed oil (shortening), a slow heating action may be necessary. If this is desired, be sure that in the Configuration Mode [etype] / [melt] has been set to [```on. Then, when the oil temperature is below 212ºF the heat output will be lim- ited to 10% of full power.
Page 65 Run A Menu (without preheat feature) This procedure describes how to run a menu when the preheat function is inactive — in other words, when the [Ready] parameter in the [SetUp] function of the Configuration Mode is set to [```no] — and initial preheat power-up has been com- pleted.
Page 66 Cancel a menu Canceling the menu stops controller operation completely. The controller does not main- tain set point temperatures or run time. Users may cancel the menu in order to run another one, to stop menu operation for any reason, or when preparing to shut off the fryer.
Page 67: Application 16
Application 16 Automatic Deepfat Fryer One Heat Channel, Six Menus Introduction to Application 16 ... . . 65 Configuration Mode Quick Reference ..67 Program Mode Quick Reference .
Page 68 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 69 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 16 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 70 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 16 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 71 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 72 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Menu 1 Menu 2 Menu 3 Menu 4 Menu 5 Menu 6 Startup Apply power to the fryer and add cooking oil if necessary. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt].
Page 73 The word [Pre-`] [`Heat] will appear on the display for a few moments. The menu key indicator light will flash slowly. The temperature of Channel 1 will then be displayed until the operating temperature is reached. The heat output indicator light - G, just below the display- will light up whenever the controller is calling for heat.
Page 74 the display. (The message, which varies based on programming at [M```] / [ALArn] will appear for ten seconds.) An audible tone will sound for five seconds. Time will continue to count down on the display. 4. When the cooking cycle is finished one of the following will happen, depending on the way the controller was programmed at [EtypE] / {Sound].
Page 75 the way the controller was programmed at [EtypE] / {Sound]: With Sound set to 0: The controller automatically switches to idle, where the con- troller maintains the temperatures at set point and does not run time. [`idle] or time of day will appear on the display. The menu key indicator light will flash slow- With Sound set to 1, 2, or 3: [``End] will appear on the display and an audible tone will be emitted.
Page 76 Notes Wa tl o w M i ni Ch e f 2 0 0 0 Ap p l i cati o n 1 6...
Page 77: Application 17
Application 17 Automatic Deepfat Fryer One Heat Channel, Four Menus Introduction to Application 17 ... . . 75 Configuration Mode Quick Reference ..77 Program Mode Quick Reference .
Page 78 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 79 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 17 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 80 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 17 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values unction Parameter...
Page 81 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 82 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Menu 1 Not Used Menu 2 Menu 3 Not Used Menu 4 Startup Apply power to the fryer and add cooking oil if necessary. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [setpt] The display will show [prE-`] [`Heat] followed by oil temperature as the oil heats up.
Page 83 If the fryer is not at operating temperature, it will preheat. Meanwhile: The word [Pre-`] [`Heat] will appear on the display for a few moments. The menu key indicator light will flash slowly. The temperature of Channel 1 will be dis- played until the operating temperature is reached.
Page 84 With Sound set to 4 or 5, [``End] will appear on the display and the menu key indicator light will flash rapidly. You must acknowledge the audible tone by pressing the active menu key. Once acknowledged, the tone is silenced and the controller goes into idle.
Page 85: Application 18
Application 18 Automatic Deepfat Fryer One Heat Channel, 40 Menus Introduction to Application 18 ... . . 83 Configuration Mode Quick Reference ..85 Program Mode Quick Reference .
Page 86 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 87 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 18 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 88 Program Mode Quick Reference These are the functions, parameters and values included in the Program Mode for this application. You must select Application 18 to access them. For menu programming directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes a detailed explanation of all parameters and values.
Page 89 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 90 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Operation Function Idle One Temp Idle Two Temp Increment Menu Select Start/Stop Decrement Start-up Apply power to the fryer and add cooking oil if necessary. Select a Menu 1.
Page 91 play and an audible tone will sound for 2 seconds. Then [`idle] will appear on the display. If Real Time Clock option is installed and [setUp] / [Cloc`] is set to [``yes], the time of day will appear on the display. Preheat If in the Configuration Mode [SEtUP] / [ready]] has been set to yes, the controller will detect temperatures and preheat to operating temperature (above relative set point...
Page 92 RAPID SLOW FLASH FLASH 2000 2000 2000 [`idle] [pre-`] [`Heat] [100f`] [ready] Edit Accept Edit Accept Edit Accept Exit Back-Up Exit Back-Up Exit Back-Up AT OPERATING TEMPERATURE (PREHEAT CONDITION MET) If the preheat condition has not been met, the fryer will preheat until [ready] appears on the display.
Page 93 acknowledge and silence the tone by pressing the Start/Stop key or it will automati- cally time out within 2 seconds for setting 1 or 20 seconds for settings 2 or 3 and then go into idle. The Start/Stop key indicator light will flash slowly. The controller will maintain temperature at the programmed set point.
Page 94 will maintain temperature at the programmed set point. With sound set to 4 or 5: [``End] will appear on the display and the Start/Stop key indicator light will flash rapidly. You must acknowledge the audible tone by pressing the Start/Stop key. Once acknowledged the audible tone is silenced and the con- troller goes into idle.
Page 95 Based on its programming, the unit will run the menu in one of the ways described earlier. Change Menus 1. With the controller in idle, select the menu you want to run by performing the pro- cedure under “Select a Menu” earlier in this section. 2.
Page 96 Notes Watl o w M i ni Ch e f 2 0 0 0 Ap pl i cati o n 18...
Page 97: Application 19
Application 19 Manual Deepfat Fryer One Heat Channel Introduction to Application 19 ... . . 95 Configuration Mode Quick Reference ..97 Step 7 Design a Faceplate Overlay ..99 Step 8 Operate the Controller .
Page 98 Key Functions in Configuration Mode 2000 Display five-digit, seven- segment numeric LED display. Indicator lights (1 for each key, 2 for heat channels). Edit key (A) Access the next level of parameters or values. Up key (C) Move up the Edit Enter lists.
Page 99 Configuration Mode Quick Reference These are the functions, parameters and values included in the Configuration Mode for this application. You must select Application 19 to access them. For directions, see the Hardware & Software Setup Guide. The Appendix of that guide includes an explanation of all parameters and values.
Page 100 Auto-tuning Note: Before auto-tuning Application 19, [teNp1] in the operations menu must first be set to a value that is typical of your application. (See Hardware & Software Setup Guide for information on programming menus.) Then set [tHerl] / [tunE1] to [```on]. After you accept [```on], by pressing “Enter,”...
Page 101 Step 7 Design a Faceplate Overlay To complete the installation, you must apply a graphic membrane to the front panel of the controller. The following artwork will help you design and create a membrane for this application. For more dimensions and guidelines, see the Hardware & Software Setup Guide.
Page 102 Step 8 Operate the Controller Summary of Key Functions in Operation Mode Function Temp Time Increment Not Used Start/Stop Decrement Startup Apply power to the fryer and add cooking oil if necessary. Set the Menu Set the cooking temperature. 1. Press the Temp key [teNp1] and then the cooking temperature value will appear on the display.
Page 103 Five Second Timeout When using the up or down keys to change a value, if you do not press any key for 5 seconds, the controller will automatically be set to the last value on the display and return to [`idle]. Initial Preheat At power-up, the unit will preheat to the temperature value set in the Configuration Mode [Etype] / [preHt].
Page 104 The Melt Cycle To avoid burning congealed oil (shortening), a slow heating action may be necessary. If this is desired, be sure that in the Configuration Mode [etype] / [melt] has been set to [```on]. Then, when the oil temperature is below 212 °F the heat output will be lim- ited to 10% of full power.
Page 105 that is, when the [Ready] parameter in the [SetUp] function of the Configuration Mode is set to [```no] — and initial preheat power-up has been completed. 1. Set the menu as shown earlier. 2. With [`idle] or time of day on the display, press the Start/Stop key 2000 2000 2000...
Page 106 Timer Output If [Etype]] / [T`OUt]] in the Configuration Mode is set to [``yes], when time is count- ing down Event Output 2 is on. It is off during [Pause], [`Idle] or [Hold]. Temperature Alarms The controller will alert you to temperature alarm conditions if they occur. If an alarm occurs, take action as determined by your supervisor.
Page 107 Specifications Audible Output Options (1032) • Switched dc signal, 4.5V to 5.25V, 30mA maximum Control Mode output, minimum load resistance > 150Ω, non-isolated. • Single and dual heat channels, PID or on/off. • Internal audible alarm, 75dB at 10 cm. •...
Page 108: Ordering Information
Software AA = Standard Food Equipment Application Software Set XX = Custom Set-up parameters or Made-To-Order custom software. Consult your local Watlow Sales Engineer. Code number assigned by factory. 10 6 Wa tl o w M 2 0 0 0...
Page 109 Ordering Information: Part Numbers & Accessories 2000 Accessories 2000 Documentation 0836-0442-0000 Sensor Input Mating Connector, WMC2-XUGN-0000 The Complete M (RIACON #31007106), 6-position, 2000 User Guide quick-connect terminal, screw WMC2-XADN-0000 The Complete M connection for 28-14 AWG wires, 2000 User Guide on CD tighten to 7 in/lb WMC2-XTDN-0000 2000 Tutorial...
Page 110 Watlow Controls Watlow Controls is a division of Watlow Electric Mfg. Co., St. Louis, Missouri, a manu- facturer of industrial electric heating products since 1922. Watlow begins with a full set of specifications and completes an industrial product that is manufactured totally in- house, in the U.S.A.
Page 111 Watlow M ™ 2000 Deepfat Fryer Applications Guide Watlow Controls, 1241 Bundy Blvd., P.O. Box 5580, Winona, MN U.S.A. 55987-5580 Phone: (507) 454-5300, Fax: (507) 452-4507...
