Important Information WARNING To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Product Registration Please fill out the product registration card (packed separately) and return it immediately. Returning the card allows us to contact you if needed. Product Information Keep your sales receipt to obtain warranty parts and service and for proof of purchase.
Chapter 1: Connections & Setup Things to Consider Before You Connect ... 4 Protect Against Power Surges ... 4 Protect Components from Overheating ... 4 Position Cables Properly to Avoid Audio Interference ... 4 Important Stand and Base Safety Information ... 4 Use Indirect Light ...
Page 4
Table of Contents Chapter 4: Using the Menu System How to Use the Different Types of Menus and Control Panels ... 30 Menus ... 30 Control Panels ... 30 Audio Menu ... 32 Picture Quality Menu ... 33 Screen Menu ... 33 Using Closed Captioning ...
Connections & Setup Chapter Overview: • Things to Consider Before You Connect • Choose Your Connection • Connections • The Front of Your TV • Plug in the TV • Put Batteries in the Remote • How to Use the Remote Control to Complete the Interactive Setup •...
Connections & Setup Things to Consider Before You Connect Protect Against Power Surges • Connect all components before you plug any of their power cords into the wall outlet. • Turn off the TV and/or component before you connect or disconnect any cables. •...
Choose Your Connection There are several ways to connect your TV. Please use the following chart to determine which connection is best for you. Proceed to the appropriate page and connect your TV. Components Cables Needed to Connect Components to Your TV You will need coaxial cables for the connections represented in this book.
Connections & Setup TV (back panel) TV + VCR 1. Connect your TV to your VCR Connect a coaxial cable to the CABLE/ANTENNA jack on your TV and to the Output Jack on your VCR (sometimes labeled OUT TO TV). 2.
TV Only 1. Connect the TV to your cable or antenna Connect the coaxial cable from your cable or antenna to the CABLE/ANTENNA jack on the back of your TV. Chapter 1 TV (back panel) Connections & Setup CABLE/ ANTENNA Go to page 11...
Page 10
Connections & Setup SATELLITE RECEIVER VIDEO S-VIDEO VIDEO AUDIO TV (back panel) IN FROM ANT OUT TO TV SATELLITE IN FROM ANT OUT TO TV CABLE/ ANTENNA Satellite Signal Chapter 1...
TV + VCR + Satellite Receiver 1. Connect coaxial cables to the Satellite Receiver A. Connect the coaxial cable from your cable outlet, cable box, or antenna to the Input Jack on your satellite receiver (sometimes labeled IN FROM ANT). B.
Connections & Setup The Front of Your TV Front Panel If you cannot locate your remote you can use the buttons of your TV to operate many of the TV’s features. MENU Brings up the Main menu. When in the menu system, it selects highlighted items. Also returns you to the previous menu.
Use the CHAN ^/v and VOL +/– buttons to move through the menu system. Use the MENU button to select items. Chapter 1 Plug in the TV Plug the end of the power cord into the wall outlet. Match the wide blade of the plug with the wide slot in the outlet.
Connections & Setup To access the setup menus manually, press MENU and choose Setup. ñol 3 Français Complete the Interactive Setup The menu system in your TV allows the TV’s features to work properly. In this book, we call it the “interactive setup” because the TV asks you questions, you answer, and the TV makes the appropriate adjustments.
Using the Remote Control Chapter Overview: • The Buttons on the Remote Control • Programming the Remote to Operate Other Components • How To Use the Remote After You’ve Programmed It • Code List Changing Entertainment. Again. Graphics contained within this publication are for representation only. Chapter 2...
CLEAR Removes any menu or display from the screen and returns you to TV viewing. DVD Puts the remote in DVD mode to operate RCA, GE and Proscan DVD players. It cannot be programmed. FORWARD If you’re operating a VCR or DVD player with the remote control, press FORWARD to advance a disc or videotape.
Page 17
To turn off all the RCA, GE, and PROSCAN components that are connected to the TV, press ON•OFF twice within two seconds. This feature only works with most RCA, GE and PROSCAN products. Chapter 2 Using the Remote Control PLAY If you’re operating a VCR or DVD player, plays the disc or videotape.
The universal remote control can be programmed to operate most brands of remote controllable VCRs, satellite receivers and cable boxes. The remote is already programmed to operate most RCA, GE and Proscan TVs, VCRs, DVD players, laserdisc players and satellite receivers.
Using Direct Entry 1. Turn on the component you want the remote to operate. 2. Look up the brand and code number(s) for the component on the code list on page 7. 3. Press and hold the component button that corresponds to the component you want the remote to operate (VCR1, VCR2, SAT•CABLE, or AUX) 4.
Page 21
Using the TV’s Features Chapter Overview: • The Channel Banner • Parental Controls and V-Chip Changing Entertainment. Again. Graphics contained within this publication are for representation only. Chapter 3...
Using the TV’s Features Sample displays on a Channel Banner. Channel Banner There are several indicators that might appear when you press the DISPLAY button on the remote. This display is called the Channel Banner. The following list describes the items on the Channel Banner screen (left to right and top to bottom).
This screen appears when you try to tune to a channel or program that’s blocked by Parental Controls. Press DISPLAY on your remote to enter your password. Chapter 3 Parental Controls and V-Chip The Parental Controls menu allows you to program your TV so that children cannot see certain programs, channels, or use the front panel controls.
Using the TV’s Features How V-Chip Works When turned “on,” the V-Chip software reads a code that most broadcasters send with programs. That code tells the software the program’s age-based rating (TV-MA, TV-14, etc.) and content themes [(Violence (V), Adult Language (L), etc.)]. If you have blocked the rating and/or content themes that the program contains, you will receive the message, “This channel is not approved for viewing,”...
The V-Chip Rating Limit Screen The following is an example of where items are located within the Rating Limit screen. Rating Status Field Lets you select whether the status of the age-based rating limit to the left is View or Block. Rating Field Lets you select from a list of age-based ratings...
Page 26
Using the TV’s Features Rating Rating Content field status field status fields When you change the status of a rating to Block, the system will automatically block higher ratings and all corresponding content themes. Hierarchy of Age-Based Ratings TV-MA Mature Audience Only TV-14 Parents Strongly Cautioned TV-PG...
Content Themes Sexually explicit dialogue Adult language Sexual situations Violence Fantasy Violence Rating Rating Content status field field themes Content status fields Content Rating Rating themes field status field Content status fields Chapter 3 Blocking Specific Content Themes You can block programs based on their content. (Content is represented by the D, L, S, V and FV on your screen.
Using the TV’s Features Rating Rating field status field V-Chip Movie Rating Limit You set movie rating limits by blocking movies rated above a specified level. How to block movie ratings and view movie ratings is explained in the next two sections.
Rating Rating field status field Chapter 3 Viewing Movie Ratings After you block movie ratings, you have the option of changing some of the rating status buttons back to View: 1. Highlight the Rating field and press the CHAN and CHAN^ buttons to find the rating you want to view.
Using the TV’s Features Front Panel Block Selecting this option lets you block (disable) or unblock (enable) the TV’s front panel. The remote still tunes to any channel. Front Panel Block can: • Keep children from watching TV when the parent is not present. •...
Using the TV’s Menu System Chapter Overview: • How to Use the Different Types of Menus and Control Panels • Audio Menu • Picture Quality Menu • Screen Menu • Channel Menu • Time Menu Changing Entertainment. Again. Graphics contained within this publication are for representation only. Chapter 4...
Using the TV’s Menu System How to Use the Different Types of Menus and Control Panels The TV’s menu system has three types of screens: menus, control panels, and choice lists. You use the buttons on the remote or the front panel to access the menu system and make changes to the settings.
Page 33
If the control panel is not set to the current time, use the VOL + and VOL – buttons to go back over the columns and the digits to make changes. You can also enter numbers by using the CHAN ^ and CHAN v buttons on the remote.
Using the TV’s Menu System Audio Menu Mute Press MENU to reduce the TV’s volume to its minimum level. Press MENU again to restore the volume. Tone Controls Displays the slider controls for adjusting the TV’s treble, bass and balance. Audio Processor Displays a choice list of available audio modes, which control the way the sound comes through your speakers.
Chapter 4 Using the TV’s Menu System Picture Quality Menu Basic Picture Controls Displays the five slider controls for adjusting the way the picture looks. Contrast Adjusts the difference between the light and dark areas of the picture. Color Adjusts the richness of the color. Tint Adjusts the balance between the red and green levels.
Using the TV’s Menu System Using Closed Captioning Many programs are encoded with closed-captioning information, which lets you display the audio portion of a program as text on the TV screen. Closed captioning is not available on all channels at all times. Only specific programs encoded with closed-captioning information are applicable.
To enter a number greater than 99, press and hold “1” to enter the hundreds digit, then press the two remaining numbers. Chapter 4 Using the TV’s Menu System Channel Menu Signal Type Displays a choice list that lets you select the current antenna type. UHF/VHF Antenna Choose this if you are currently using an off-air antenna for TV signals.
Other Information Chapter Overview: • Troubleshooting • Care and Cleaning • Warranty • Index Changing Entertainment. Again. Graphics contained within this publication are for representation only. Chapter 5...
Other Information Troubleshooting Most problems you encounter with your TV you can correct by consulting the Troubleshooting list that follows. TV Problems TV won’t turn on • Press the POWER button. • Make sure the TV is plugged in. • Check the wall receptacle (or extension cord) to make sure it is “live”...
The Remote Control Doesn’t Work • Something might be between the remote and the remote sensor on the component. Make sure there is a clear path. • Maybe the remote isn’t aimed directly at the TV. • Maybe batteries in remote are weak, dead or installed incorrectly. Put new batteries in the remote. •...
How you get service: • For 20" screen size: Take your RCA television to any Authorized RCA Television Service Center and pick up when repairs are complete. • For screen sizes larger than 20": Request home or pick up, repair, and return service from any Authorized RCA Television Service Center, provided that your television is located within the geographic territory covered by an Authorized RCA Television Service Center.
Page 43
Limitation of Warranty: • THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
