RCA RP5415 User Manual

v5.0 (EN/E)
user manual
manual de usuario
RP5415PK
EN/E
It is important to read this user manual prior to using your new product for the fi rst time.
Es importante leer este manual antes de usar por vez primera su equipo.
• Do not place lighted candles, Important Battery Precautions
cigarettes, cigars, etc. on the • Any battery may present a risk
product. of fi re, explosion, or chemical
• Connect power cord only to burn if abused. Do not try to
AC power source as marked on charge a battery that is not
the product. intended to be recharged, do
• Care should be taken so that not incinerate, and do not
objects do not fall into the puncture.
product. • Non-rechargeable batteries,
• Do not attempt to disassemble such as alkaline batteries, may
the cabinet. This product leak if left in your product for
does not contain customer a long period of time. Remove
serviceable components. the batteries from the product
• The marking information if you are not going to use it
is located at the bottom of for a month or more.
apparatus. • If your product usaes more
• Caution marking is located at than one battery, do not mix
bottom of apparatus. types and make sure they are
inserted correctly. Mixing types
This is CLASS II apparatus or inserting incorrectly may
with double insulation, cause them to leak.
and no protective earth • Discard any leaky or deformed
provided. battery immediately. They
may cause skin burns or other
personal injury.
• Please help to protect the
environment by recycling
or disposing of batteries
according to federal, state, and
local regulations.
• Do not expose batteries to
excessive heat (for example,
by leaving them in sunlight or
close to fi re).

General controls

Front view
Left view
– turns on or off the radio; turns
off the wake function
TUNING – selects radio frequency
Top view
– Slide to activate
Wake 1 settings and change Wake
1 mode:
• (wake to alarm) – selects
alarm as the waking mode
• (wake to radio) – selects
radio as the waking mode
SLEEP – activates sleep function
• OFF – deactivates Wake 1
waking mode
SNOOZE – turns off the wake
function temporarily; cancels the
WAKE 1 CHECK TIME – checks

sleep function

the waking time for Wake 1
DISPLAY – switches between
AUX IN – jack for external audio
analog and digital clock displays
input
Auxiliary input
Connecting auxiliary
Adjust the auxiliary
device
device to mid-range
volume and adjust the
Connect your auxiliary audio
master volume by rotating
player (e.g. mp3 player) with an
VOLUME knob on the unit.
audio cable (not included) to the
Do not turn the volume of the
AUX IN jack on the left side of
auxiliary device too high as this
the unit.
may affect the sound quality.
For other playback operations,
Selecting AUX IN mode
control them on your auxiliary
• Press AUX ON/OFF on the
device.
back of the unit to select AUX
IN mode.
• Press AUX ON/OFF again to
exit from the AUX IN mode
and resume to standby mode.
To listen to the radio again,
press .

Warranty information

12 Month Limited Warranty interruptions of broadcast
Applies to RCA Audio/Video or internet service, to costs
Products incurred for installation,
• AUDIOVOX ELECTRONICS removal or reinstallation of
CORP. (the Company) warrants product, to corruptions caused
to the original retail purchaser by computer viruses, spyware
of this product that should or other malware, to loss of
this product or any part media, fi les, data or content,
thereof, under normal use and or to damage to tapes, discs,
conditions, be proven defective removable memory devices or
in material or workmanship cards, speakers, accessories,
within 12 months from the computers, computer
date of original purchase, such peripherals, other media
defect(s) will be repaired or players, home networks or
replaced with reconditioned vehicle electrical systems.
product (at the Company's • This Warranty does not
option) without charge for apply to any product or
parts and repair labor. part thereof which, in the
• To obtain repair or opinion of the Company, has
replacement within the terms suffered or been damaged
of this Warranty, the product through alteration, improper
is to be delivered with proof installation, mishandling,
of warranty coverage (e.g. misuse, neglect, accident, or by
dated bill of sale), specifi cation removal or defacement of the
of defect(s), transportation factory serial number/bar code
prepaid, to the Company at label(s). THE EXTENT OF THE
the address shown below. COMPANY'S LIABILITY UNDER
• This Warranty does not THIS WARRANTY IS LIMITED TO
extend to the elimination THE REPAIR OR REPLACEMENT
of externally generated PROVIDED ABOVE AND,
static or noise, to correction IN NO EVENT, SHALL THE
of antenna problems, loss/ COMPANY'S LIABILITY EXCEED
FCC information equipment off and on, the user is
encouraged to try to correct the
This equipment has been tested
interference by one or more of
and found to comply with the
the following measures:
limits for a Class B digital device,
pursuant to Part 15 of FCC Rules.
• Reorient or relocate the
These limits are designed to
receiving antenna.
provide reasonable protection
• Increase the separation
against harmful interference in
between the equipment and
a residential installation. This
RP5415 receiver.
equipment generates, uses, and
• Connect the equipment into
can radiate radio frequency
an outlet on a circuit different
energy and, if not installed
from that to which the
and used in accordance with
receiver is connected.
the instructions, may cause
• Consult the dealer or
harmful interference to radio
an experienced radio/TV
communications.
technician for help.
However, there is no guarantee
Modifi cations not expressly
that interference will not occur
approved by the party responsible
in a particular installation. If
for compliance could void the
this equipment does cause
user's authority to operate the
harmful interference to radio or
equipment.
television reception, which can
be determined by turning the
SEE MARKING ON BOTTOM OF PRODUCT
For your records The descriptions and
characteristics in this owner's
In the event that service should
manual are for the purpose of
be required, you may need the
general reference only and not as
model number and the serial
a guarantee. In order to provide
number. In the space below,
you with the highest quality
record the date and place of
product, we may make changes
purchase and the serial number:
or modifi cations without prior
Model No.:
notice.
Date of Purchase:
Place of Purchase:
Serial No.:
Technical information
Product: Clock Radio
Brand: RCA
Model: RP5415/RP5415PK
Power Supply: 120V ~ 60Hz
Power Consumption: 4 Watts
Right view
Back view
BAND AM/FM – selects radio
band
AUX ON/OFF – selects auxiliary
input mode
+ VOLUME – – adjusts volume
– adjusts Wake 2 time
– Slide to activate
Wake 2 settings and change Wake
– adjusts clock time
2 mode:
• (wake to alarm) – selects
– adjusts Wake 1 time
alarm as the waking mode
• (wake to radio) – selects
– BRIGHTNESS + – adjusts display
radio as the waking mode
brightness
• OFF – deactivates Wake 2
waking mode
WAKE 2 CHECK TIME – checks
the waking time for Wake 2
Wake function
Checking wake time
Setting wake time
This unit allows two wake times • Press WAKE 1 CHECK TIME
or WAKE 2 CHECK TIME on
to be set.
• Turn the wake time setting the sides of the unit to check
respective wake time. Wake
knob or on the back
of the unit to adjust wake time shows briefl y on the
display.
time 1 and 2 respectively.
• The time decrements or • "OFF" shows on the display
if no wake source is selected
increments will follow by a
faster rate when you turn and while you are checking the
wake time.
hold the knob.
• "WAKE 1" or "WAKE 2" icon
fl ashes on the display while Turning off the wake
you are adjusting respective
alarm or radio
wake time.
• Press SNOOZE on the top of
the unit. The wake alarm or
Selecting wake source
radio will be switched off
You may be woken up by radio
temporarily. The alarm or
or alarm.
radio will be on again when
1. Select an AM or FM station
the snooze period is over. (see
(see directions on "Radio").
"SmartSnooze
2. Set a wake time (see above
• To turn off the wake alarm
direction).
or radio completely, press
3. Slide the switches on the sides
The wake alarm or radio will
of the unit to / (wake
activate again the next day
by alarm) or / (wake
unless you switch off the wake
by radio). Corresponding icon
function (see "Switching off
lights on the front of the unit.
wake function").
– Wake 1 by alarm
– Wake 1 by radio
– Wake 2 by alarm
– Wake 2 by radio
THE PURCHASE PRICE PAID implied warranty lasts or the
BY PURCHASER FOR THE exclusion or limitation of
PRODUCT. incidental or consequential
• This Warranty is in lieu of damage so the above
all other express warranties limitations or exclusions
or liabilities. ANY IMPLIED may not apply to you. This
WARRANTIES, INCLUDING Warranty gives you specifi c
ANY IMPLIED WARRANTY legal rights and you may also
OF MERCHANTABILITY, have other rights which vary
SHALL BE LIMITED TO THE from state to state.
DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR How to make a warranty
BREACH OF ANY WARRANTY claim:
HEREUNDER INCLUDING ANY • If your product is capable
IMPLIED WARRANTY OF of storing content (such
MERCHANTABILITY MUST BE as an mp3 player, digital
BROUGHT WITHIN A PERIOD voice recorder, etc), it is
OF 24 MONTHS FROM DATE recommended to make
OF ORIGINAL PURCHASE. periodic backup copies of
IN NO CASE SHALL THE content stored on the product.
COMPANY BE LIABLE FOR If applicable, before shipping a
ANY CONSEQUENTIAL OR product, make a back up copy
INCIDENTAL DAMAGES FOR of content or data stored on
BREACH OF THIS OR ANY the device. Also, it is advisable
OTHER WARRANTY. No person to remove any personal
or representative is authorized content which you would not
to assume for the Company want exposed to others. IT IS
any liability other than LIKELY THAT CONTENTS AND
expressed herein in connection DATA ON THE DEVICE WILL BE
with the sale of this product. LOST DURING SERVICE AND
• Some states do not allow REFORMATTING. AUDIOVOX
limitations on how long an ACCEPTS NO LIABILITY FOR
This Class B digital apparatus
complies with Canadian ICES-003.
Cet appareil numérique de la
classe B est conforme à la norme
NMB-003 du Canada.
Manufacturer/Responsible
Party
Audiovox Electronics Corp.,
150 Marcus Blvd., Hauppauge, NY
11788
WARNING:
TO PREVENT FIRE
OR ELECTRICAL
SHOCK HAZARD,
DO NOT EXPOSE
THIS PRODUCT TO
RAIN OR MOISTURE.

Before you begin

Plugging in for power
AC OUTLET POWER SUPPLY:
120V~60Hz
The AC power plug is
polarized (one blade is
wider than the other)
and only fi ts into AC
power outlets one way.
If the plug will not go into the
outlet completely, turn the plug
over and try to insert it the other
way. If it still does not fi t, contact
a qualifi ed electrician to change
the outlet, or use a different one.
Do not attempt to bypass this
safety feature.
Power is fed to the unit even
when it is not functioning. To cut
the power supply off, the power
cable must be unplugged.
Clock
Setting clock
Turn the clock setting knob on
the back of the unit to adjust
clock time. The time decrements
or increments will follow by a
faster rate when you turn and
hold the knob. The digital clock
shows and a clock icon fl ashes
on the display while you are
adjusting the time.

Display brightness

Clock time and radio frequency
are displayed on the display area
at the front of the unit. You
can adjust the brightness of the
display by rotating BRIGHTNESS
on the back of the unit.
SmartSnooze TM operation
This operation allows extra sleep
time after the wake function
is on. The alarm will be off by
pressing SNOOZE, SLEEP or
DISPLAY until the snooze period
is over. Snooze period can be
set between 1 and 30 minutes
(default: 9 min).
Set the "quiet" period as follow:
1. Press and hold SNOOZE.
2. Turn the clock setting knob
on the back of the unit to
adjust the snooze "quiet"
period (default: 9 min). The
time decrements or increments
will follow by a faster rate
when you turn and hold the
knob.
TM Operation")
.
LOST CONTENT OR DATA, OR
FOR THE SECURITY OF ANY
PERSONAL CONTENT OR DATA
ON THE RETURNED DEVICE.
Product will be returned
with factory default settings,
and without any pre-loaded
content which may have been
installed in the originally
purchased products. Consumer
will be responsible for
reloading data and content.
Consumer will be responsible
to restore any personal
preference settings.
• Properly pack your unit.
Include any remotes, memory
cards, cables, etc. which were
originally provided with the
product. However DO NOT
return any removable batteries,
even if batteries were included
with the original purchase. We
recommend using the original
carton and packing materials.
• Include evidence of purchase
date such as the bill of sale.
Also print your name and
address and a description of
the defect. Send via standard
UPS or its equivalent to:
PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE

IMPORTANT SAFETY INSTRUCTIONS

Some of the following the provided plug does not
information may not apply to fi t into your outlet, consult an
your particular product; however, electrician for replacement of
as with any electronic product, the obsolete outlet.
precautions should be observed • Protect the power cord
during handling and use. from being walked on or
• Read these instructions. pinched particularly at plugs,
• Keep these instructions. convenience receptacles, and
• Heed all warnings. the point where they exit from
• Follow all instructions. the apparatus.
• Do not use this apparatus near • Only use attachments/
water. accessories specifi ed by the
• Clean only with dry cloth. manufacturer.
• Do not block any ventilation • Use only with the
openings. Install in accordance cart, stand, tripod,
with the manufacturer's bracket, or table
instructions. specifi ed by the
• Do not install near any heat manufacturer,
sources such as radiators, heat or sold with the apparatus.
registers, stoves, or other When a cart is used, use
apparatus (including amplifi ers) caution when moving the cart/
that produce heat. apparatus combination to
• Do not defeat the safety avoid injury from tip-over.
purpose of the polarized • Unplug this apparatus during
or grounding-type plug. A lightning storms or when
polarized plug has two blades unused for long periods of
with one wider than the time.
other. A grounding type plug • Refer all servicing to qualifi ed
has two blades and a third service personnel. Servicing is
grounding prong. The wide required when the apparatus
blade or the third prong is has been damaged in any way,
provided for your safety. If such as power-supply cord or
Battery back-up operation
Power failure indicator
The power failure protection
When AC power is interrupted
circuit will not operate unless
(disconnected) for a short period
battery is installed.
of time, both time and alarm
settings will change (unless
When the battery backup
battery is installed). After AC
functions, the digital display will
power is restored (reconnected),
not light, however, the wake
the Digital Display will blink
function still occurs during the
to indicate that power was
power interruption if remaining
interrupted and you should
battery power is adequate.
readjust the time and alarm
settings.
Normal operation will resume
after AC power is restored so you
will not have to reset the time or
wake.
Install battery as follow:
1. Remove battery compartment
door (located at the bottom of
the radio) by applying thumb
pressure to the tab on battery
door and then lift the door
out and off the cabinet.
2. Connect a 9-volt battery (not
supplied) to the connector
plug.
3. Replace the compartment door.
Radio
Selecting between Switching on/off
analogue and digital clock
Press to turn on or off the radio.
Press DISPLAY to select between
analogue and digital clock display. Switching band
Slide the BAND AM/FM switch on
the back of the unit to select FM
or AM band.
Tuning radio
Turn the TUNING knob on the
left of the unit to adjust radio
frequency.
Antennas
AM Antenna – A built-in ferrite
rod antenna eliminates the need
for an outside antenna for AM
reception. Rotating the unit
slightly may improve reception of
distant AM stations.
FM Antenna – The power cord
acts as your FM antenna. The
power cord picks up moderate
to strong stations and eliminates
the need for an external antenna
in most strong signal areas. Be
sure the power cord is stretched
out to its full length. Do not
coil or bunch the cord together.
Sleep function
Switching off wake
In sleep mode, you can set the
duration (up to 2 hours) before
function
the radio turn off automatically.
Slide the switches on the sides
of the unit to OFF to switch off
1. Press and hold SLEEP and turn
respective wake function. The set
the clock setting knob
wake time will not be erased and
the back of the unit to adjust
can be used the next day when
the duration up to 2 hours.
you switch on wake function
The time decrements or
again.
increments will follow by a
faster rate when you turn and
hold the knob.
• Note: The radio will be
switched on.
2. To check the remaining
duration before the radio turns
off, press and hold SLEEP.
3. To cancel the sleep function,
press SNOOZE or
Audiovox Electronics Corp.
Attn: Service Department.
150 Marcus Blvd.
Hauppauge N.Y. 11788
1-877-833-3491
• Insure your shipment for loss or
damage. Audiovox accepts no
liability in case of damage or
loss en route to Audiovox.
• Pay any charges billed to you by
the Exchange Center for service
not covered by the warranty.
• A new or refurbished unit
will be shipped to you freight
prepaid.
What we will do:
Provide you with a new, or at our
option, a refurbished unit. The
exchange unit is under warranty
for the remainder of the original
product's warranty period.
For Canada Customers, please
ship to:
Audiovox Return Centre
c/o Genco
6685 Kennedy Road,
Unit#3, Door 16,
Mississuaga, Ontario
L5T 3A5
plug is damaged, liquid has
been spilled or objects have
fallen into the apparatus, the
apparatus has been exposed
to rain or moisture, does not
operate normally, or has been
dropped.
ADDITIONAL SAFETY
INFORMATION
• Main plug is used as
disconnect device and it
should remain readily operable
during intended use. In order
]
to disconnect the apparatus
from the mains completely,
the mains plug should be
disconnected form the mains
socket outlet completely.
• Apparatus shall not be exposed
to dripping or splashing and
no objects fi lled with liquids,
such as vases, shall be placed
on the apparatus.
• Always leave suffi cient space
around the product for
ventilation. Do not place
product in or on a bed, rug,
in a bookcase or cabinet that
may prevent air fl ow through
vent openings.
Alkaline (NEDA 1604A/
IEC 6LR61) battery is
recommended. Carbon-
zinc battery may be used but
memory holding time will
be substantially reduced.
Memory holding time for
a fresh alkaline battery is
approximately 8 hours (if radio
or alarm are not operated)
which should take care of
short, nuisance-type AC power
failures. To preserve battery
life, the unit should remain
plugged into an AC outlet.
As the battery gets older, its
voltage drops and memory may
be lost. Be sure to replace the
battery periodically. Battery
should be removed if the unit
will be stored for more than
one month. Leaky battery can
badly damage the clock radio.
Changing position of the power
cord may improve reception.
Built-In AFC – The Built In
Automatic Frequency Control
(AFC) works only on FM. It helps
reducing drift on FM reception
and keeping the radio locked in
on the FM station to which it is
tuned.
When tuning in FM stations, you
may notice that the station you
are tuning can be well-tuned on
two or three nearby points on the
dial. Always tune carefully at the
loudest and clearest point.
If you set Sleep function
with low volume level
before going to bed, we
advise using Wake to alarm
mode.
on
.
Audiovox Electronics Corp.
150 Marcus Blvd,
Hauppauge, NY 11788
©2009 Audiovox Electronics Corp.
Trademark(s) ® Registered
Marque(s) ® Deposée(s)
Marca(s) ® Registrada(s)
www.rcaaudiovideo.com
Printed in China
