Peak PKC0BU7 Owner's Manual And Warranty

7.0-inch digital back-up camera
Hide thumbs Also See for PKC0BU7:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Enlarged version
7.0-inch Digital
Back-Up Camera
Model No.: PKC0BU7
Owner's Manual
and Warranty Information
Read these instructions completely before using this product.
Retain this Owner's Manual for future reference.
1
© 2016
9/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PKC0BU7 and is the answer not in the manual?

Questions and answers

Related Manuals for Peak PKC0BU7

Summary of Contents for Peak PKC0BU7

  • Page 1 7.0-inch Digital Back-Up Camera Model No.: PKC0BU7 Owner’s Manual and Warranty Information Read these instructions completely before using this product. Retain this Owner’s Manual for future reference. © 2016 9/16...

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ........................ 2 Back-Up Camera Safety ......................2 INTRODUCTION ..........................3 FEATURES ............................3 INSTALLATION ..........................4 OPERATION ............................ 6 Testing the System ........................6 Monitor Controls ........................6 CARE AND MAINTENANCE ......................8 Storage ........................... 8 Cleaning ..........................8 Fuse Replacement ........................

  • Page 3: Introduction

    INTRODUCTION The Back-Up Camera displays images behind the vehicle, and is used when backing up a vehicle. When the vehicle is driven in reverse, the camera is activated, which sends a signal to the transmitter. The transmitter sends a video signal to the monitor, which then displays the view captured by the camera. FEATURES Color monitor displays view from the rear of the vehicle Wireless monitor can be mounted to a windshield or a dashboard with the supplied adhesive pad for...

  • Page 4: Installation

    INSTALLATION Some states or local governments may have regulations or laws that restrict the use of anything that might impair the clear view of a license plate. Check local laws for compliance. For the Back-Up Camera to be properly installed, it must be wired into the vehicle’s taillight harness.
  • Page 5 Legend Positive (+) Wire from Reverse Light Wire Connector Reverse Light Negative (-) Wire from Reverse Light Negative (-) Camera Power Wire (Black) Positive (+) Camera Power Wire (Red) Camera 11. The red positive (+) wire from the camera splices into the positive (+) wire from the reverse lights and the black negative (-) wire from the camera splices into the negative (-) wire from the reverse lights.

  • Page 6: Operation

    18. Remove the lm from the foam adhesive pad and press stand rmly onto mounting surface. NOTE: After mounting, protect the mounting surface from direct sunlight for 24 hours. 19. Slide the monitor onto the monitor arm. The monitor angle can be adjusted by loosening the monitor angle adjustment knobs, tilting the monitor, then tightening the knobs.
  • Page 7 Adjusting Monitor Settings To adjust the following monitor settings, make sure the park brake is applied, turn the ignition switch to the ON position and shift the vehicle to reverse. In extremely bright conditions, the screen image may take a few seconds to stabilize.

  • Page 8: Care And Maintenance

    To view rmware: Select set up Select version CARE AND MAINTENANCE Storage Store this Back-Up Camera in a cool, dry area and keep it away from direct sunlight, heat, excessive humidity and dampness. Cleaning Do not clean or wipe the Back-Up Camera with solvents or chemical materials. If necessary, remove dirt or stains using a soft cloth dampened with a mild detergent solution.

  • Page 9: Notice To Drivers In California And Minnesota

    State law prohibits drivers in California and Minnesota from using suction mounts on their windshields while operating motor vehicles. Other dashboard or friction mounting options should be used. Peak® does not take any responsibility for any nes, penalties, or damages that may be incurred as a result of disregarding this notice.

  • Page 10: Limited Warranty

    LIMITED WARRANTY Manufacturer warrants to the original consumer, or purchaser, that the PEAK® PKC0BU7 7.0-inch Digital Back-Up Camera will be free from defects in material and workmanship for 1 year from the date of sale to the original purchaser. Manufacturer hereby excludes and disclaims any and all other warranties, expressed or implied, beyond those warranties speci ed above.
