Raypak 80 and 115 Gallons Specifications

HOT WATER STORAGE TANKS
APPLICATION
The tank can be installed whenever the demand utilizes stored water from 80 to 115 gallons or more. Whether installed
individually or as several tanks in parallel, this tank can provide 80% draw without an appreciable temperature
decrease in single temperature application.
FEATURES
• Available in 80 and 115 gallon sizes
• 150 PSI maximum working pressure
• Two magnesium anodes
• Meets ASHRAE 90.1
• Los Angeles City approval application no. M-880057
• Insulated and jacketed
• R-16 value insulation
• Foam insulation
• Five-year limited warranty
• Labels for each opening
• Large drain valve
CONSTRUCTION CODE
• Storage Tank - The tanks are lined with a double
coating of a high-temperature glass formula. It is
built for long life under any water conditions. Two
magnesium anode rods are factory installed.
• R-Foam Insulation - Rigid polyurethane foam insu-
lation for improved economy and fuel savings. The
insulation is R-16 value and complies to ASHRAE
90.1.
SAMPLE SPECIFICATION
The hot water storage tank shall be a Raypak __________ gallon factory insulated and jacketed tank.
The tank shall have a double coating of a high temperature glass lining and be equipped with two (2) magnesium anode
rods. The tank shall be constructed and designed for 150 PSI working pressure.
The tanks shall be insulated with rigid polyurethane foam that completely surrounds the tank and shall be enclosed
in a baked enamel steel jacket. The tank insulation must be R-16 value and must meet or exceed ASHRAE standard
90.1. The tank shall be covered by a five (5) year limited warranty against corrosion.
Catalog No.: 4000.20-I
• Steel Jacket - Complete unit is enclosed in baked
enamel steel jacket. With minimum care, the jacket
will remain attractive and colorful for years.
• Tank Openings - Circulating tank connections and
hot water outlets are 2" NPT. Other openings are for
T and P valve, tankstat, thermometer and drain port.
(3/4" NPT Drain valve standard)
• Labels - Openings are individually labeled
for easy identification.
Effective: 03-15-08
NON-CODE
80 AND 115 GALLONS
80 gallon tank illustrated
Replaces: 12-28-07
