Raypak Digital and Millivolt Gas Heater Technical Data

Digital and Millivolt Gas Heaters
C
INDOOR
DRAFTHOOD
38"
13-1/4"
GAS
CONNECTION
BTUH
Heater Input Cabinet
Model (000)
R206A 199.5
R266A 266.0
R336A 332.5
R406A 399.0
Designation for a Digital heater using propane gas is "EP"; a Digital heater using natural gas is "EN".
Designation for a Millivolt heater using propane gas is "MP"; a Millivolt heater using natural gas is "MN".
Prefix "P" is for plastic (polymer) headers; "C" is for cast iron (ASME) headers.
Suffix "X" is for cupro-nickel tubing; "C" is for copper tubing
Example: P-R406A-EN-X = Plastic headers, 406 model size, digital, natural gas, cupro-nickel
Reduce input 4% for each 1000 feet above sea level when installed above 2000 feet elevation.
Manufactured under Patent No. 3,623,458.
Swimming Pool and Spa
Heating Products

Technical Data

B
26-5/8"
(28-5/8" ASME)
A
(A) (B) (C)
Flue Indoor
Width Diameter Drafthood
20" 6" 61-5/8"
23" 7" 62"
26" 8" 63"
29" 9" 64-1/2"
4-3/8"
J
(3-3/8" ASME)
32-11/16"
ELECTRICAL
CONNECTION
(J)
Minimum Gas
Conn.
11-7/8" 3/4"
11" 3/4"
10-5/8" 3/4"
12-5/16" 3/4"
8-7/8"
(6-5/8" ASME)
40"
STACKLESS
OUTDOOR TOP
28"
Digital
Shipping Weights (lbs)
w/ Polymer
Headers
Water
and Stackless
Conn.
Top
2" 187
2" 210
2" 230
2" 249
The Pool and Spa Heating Experts
Amp Draw
120 volt 240 volt
4 2
w/ cast iron
Headers
and Stackless Indoor
Top Drafthood
206 12
229 15
249 17
268 20
