Raymarine Satellite TV Systems User’s Guide Document Number: 81258_3 Date: October 2006...
Page 2
Trademarks and registered trademarks Autohelm, HSB, Raymarine, RayTech, Sail Pilot, SeaTalk and Sportpilot are registered trademarks of Raymarine Limited. Apelco is a registered trademark of Raymarine Holdings Limited (Registered in all major marketing territories). AST, Autoadapt, Auto GST, Autoseastate, Autotrim, Bidata, Marine Intelligence, Maxiview, On Board, Raychart, Raynav, Raypilot, Raystar, ST40, ST60, Seaclutter, Smart Route, Tridata and Waypoint Navigation are trademarks of Raymarine Limited.
Multiple IRDs ... 18 System with 4 RF connector baseplate ... 21 Multiple IRDs ... 22 Connecting your satellite TV system to an NMEA0183 GPS ... 23 System set up ... 25 Start up... 25 Changing the default satellite... 26 Monitoring the current status of the antenna...
Page 4
Middle East... 57 South America ... 59 Satellite coverage by geographic location ... 60 Europe ...60 Satellite tracking... 62 Satellite service providers ...62 European satellites... 62 Technical specification... 67 Raymarine 45 STV ...67 Raymarine 60 STV... 70 Raymarine Satellite TV Systems...
Safety notices WARNING Product installation This equipment must be installed in accordance with the instructions contained in this handbook. Failure to do so could result in poor product performance, personal injury and/or damage to your boat. CAUTION In-line fuse If you do not have a breaker in the power circuit, an in-line 5 A quick blow fuse should be fitted to the positive (white) lead of the power cable.
TV system provides uninterrupted television access to hundreds of TV chan- nels in all types of weather conditions. On the open sea or at the dock, the Raymarine Satellite TV system auto- matically identifies, acquires and tracks compatible signals from all digital video broadcast (DVB) satellites.
Television reception For full functionality of your Raymarine Satellite TV system, it is necessary to subscribe to the relevant service(s) from the appropriate service provider(s). Full details of service providers can be found in “Satellite service providers” on page 62.
Page 9
What does a typical system look like? Power Note: Satellite receivers, televisions and subscription services must be purchased separately. Raymarine Satellite TV Antenna Power/Data cable cable Satellite Receiver (IRD) Antenna Control Unit Television D7944_1...
Always use the ferrites supplied by Raymarine. Connections to other equipment If your Raymarine equipment is to be connected to other equipment using a cable not supplied by Raymarine, a suppression ferrite MUST always be attached to the cable near to the Raymarine unit.
• 4 x Spring washers. System cables Your Raymarine STV package also includes the following cables: • RO8134 - 15 m Power and Data cable - used for connecting the antenna and ACU. • RO8133 - 10 m Power cable - used for connecting the ACU to the DC power supply. (45STV models only).
What tools do I need to install my TV system?... Power drill 5 mm 10 mm (3/8 in) Allen key drill 80 mm (3 in) hole saw Pencil Adhesive tape 13 mm (1/2 in) 13 mm (1/2in) socket spanner Cross-head Suitable waterproof Socket wrench screwdriver...
Power requirements You need to consider the following power requirements: • Your Raymarine Satellite TV system has been designed to work on a boat’s power supply rated at 12 V DC. • If your boats power supply is rated at 24 V DC you will need to install a suitable DC power inverter to reduce the supply voltage to 12 V DC.
Power and data cable This cable is supplied at a length of 15 m. If a longer length is required you should replace this cable with Raymarine Part No.E96007 - 30 m Power/Data cable. Power cable This cable is supplied at a length of 10 m.
Raymarine Satellite TV Systems How do I install the ACU?... ACU dimensions The dimensions of the ACU are shown below: 160 mm (6.3 in) 195 mm (7.67 in) 224.6 mm (8.84 in) D9275_1...
Installing the ACU The ACU should be installed below decks, in a position that is: • dry. • well ventilated. • easily accessible. • near your main TV viewing area. The ACU should be installed using the two fixing brackets supplied. These brackets can be placed on the sides of the unit to provide a top or bottom fix.
The bolts should be tightened to a torque of 30 Nm (22.1 ft.lb.) to ensure that the foam Foam sealing ring is compressed to restraint prevent water ingress. D7954_1 D7955_1 Raymarine Satellite TV Systems...
4 RF port connectors. Which type is fitted depends on your area of operation and the antenna model. The models are: Raymarine 45STV system All antennas are fitted with a 2 RF port connector baseplate. Raymarine 60STV system Regions with circular polarization North America, South America (DirecTV) - 2 RF port connectors.
3. Connect the DC power supply to the connector on the rear of the ACU. How do I configure the system?... Your Raymarine Satellite TV system can be connected with multiple IRDs at the same time to receive pictures in different cabins offering the maximum choice of channels.
Twin IRDs You can connect two IRDs to your antenna as shown in the following diagram.However, only one of the IRDs can be configured as a two satellite receiver. The other IRD needs to be configured as a one satellite receiver. The two satellite receiver determines which satellite is tracked, while the other receiver can watch any channel which is available from the tracked satellite.
North American systems and South America (DirecTV) In order to connect three or four IRDs to the antenna, you will need to purchase an active multi-switch with 2 satellite ‘in’ ports (Raymarine recommends the Channel Master 6314 IFD), and the necessary additional RF cables.
Page 23
North American systems - DirecTV This version of a multi-switch installation uses a DiSEqC supplier - Raymarine Part No. A96014 - and enables you to change the satellite being tracked as you change channels using the IRD master instead of the ACU.
Page 24
4. For each output required, connect an RF cable from an OUT connector of the signal splitter to the LNB or ANT connector of the individual IRD units. Raymarine Satellite TV Systems 5. Terminate any unused connections with a suitable 75 Ohm DC termi- nator block.
System with 4 RF connector baseplate Single IRD This is the basic method for connecting your Raymarine Satellite TV System. D7960_1 (not supplied) RF 1 RF 2 POWER RF 3 RF 4 Antenna baseplate The RF cable should be connected from RF1 to ‘LNB’, ‘ANT’ or ‘Satellite In’...
To connect more than 4 IRDs you will need to install a suitable active multi- switch between the antenna and the IRDs. RF 4 IRD 2 IRD 4 Connect the multiswitch in accordance with the manufacturer’s instructions. Raymarine Satellite TV Systems RF 1 RF 2 POWER RF 4 RF 3 Antenna...
Connecting your satellite TV system to an NMEA0183 GPS Note: This applies to Raymarine 60 STV systems only. Rear view Using the 9 pin connector supplied, you can connect your satellite TV system directly to you boat’s NMEA 0183 GPS system for improved tracking accuracy.
System set up Introduction This section of the handbook describes how to set up your Raymarine Satellite TV system after installation using the ACU or the Graphical User Interface (GUI) and includes the following functions: • System start up. •...
AZ:###.# EL:###.# SIGNAL:### 126.75E 37.20N SKEW : 28.3 Raymarine Satellite TV Systems SETUP 4. Antenna is again tracking satellite A. Press to display position detail. 5. Antenna position detail and signal SETUP strength is displayed. Press center soft key to display NMEA GPS page.
Set up mode To enter set up mode: TRACKING A: ASTRA 2 1. With the antenna tracking press B : HOTBIRD SETUP SETUP. SETUP MODE? 2. Press YES to enter setup mode. SET SAT PAIR? 3. Press YES to set the satellite pair. PREV NEXT Setting the satellite pair...
Press SELECT to set chosen satellite to SAT A. Press EXIT to return to main set up menu. Raymarine Satellite TV Systems 4. Set satellite A when DiSEqC is active SAT A* : DTV119 from IRD. NEXT SELECT...
Setting the GPS using the ACU SETUP MODE? 1. Press YES to enter set up mode. SET SAT PAIR? 2. Press NEXT to enter GPS set up PREV NEXT mode. SET GPS? 3. Press YES to set GPS. PREV NEXT 4.
SELECT EXIT SELECT - sets the displayed satellite for editing. EXIT - returns to the main set up menu. Raymarine Satellite TV Systems 5. Input satellite name. SATNAME : ASTRA 2 + increases a value. - decreases a INPUT value.
Page 35
HOR LOW 10773 22000 9. Input the tracking frequency (MHz) INPUT and symbol rate (kHz) for Horizontal Low Band. HOR LOW 0X0020 10. Input the NID for Horizontal Low INPUT Band. VER HIGH 11895 27500 11. Input the tracking frequency (MHz) INPUT and symbol rate (kHz) for Vertical High Band.
LNB. DSS LOCK - use only DSS lock signal for tracking. Note: (1) Raymarine does not recommend changing the satellite information unless advised to do so by the satellite provider. (2) Vertical and horizontal polarization applies to regions with linear polarization only.
6. Press YES to accept the data. Press NO to cancel and return to main set up menu. Note: Raymarine does not recommend changing the LNB type unless instructed to do so. LNB systems in regions with linear polarization SETUP MODE? 1.
PREV SELECT NEXT SELECT - sets the displayed method. EXIT - returns to main set up menu. Raymarine Satellite TV Systems SAVE? 5. Press YES to accept the selection. Press NO to cancel and return to main set up menu.
Setting the LNB skew angle Note: This menu is only applicable to Raymarine 60STV Premium models SETUP MODE? 1. Press YES to enter set up mode. SET SAT PAIR? 2. Press NEXT 5 times to enter the PREV NEXT Local frequency menu.
E93006 4. Product name is displayed. EXIT Press EXIT to return to main set up menu. Raymarine Satellite TV Systems 5. Antenna software version is ANT S/W VER : 1.00 displayed. EXIT Press EXIT to return to main set up menu.
ANTENNA GO POSITION? 3. Press YES to enter Go position. PREV NEXT 4. Input position value for azimuth AZ : ###.##DEG (AZ) axis. INPUT + increases a value. - decreases a value. Change the underscored digit using the +/- buttons. Press INPUT to accept a value.
UP - move in up direction. EXIT DOWN EXIT - go to Ant move step menu. DOWN - move in down direction. Raymarine Satellite TV Systems Setting defaults SETUP MODE? 1. Press YES to enter set up mode. SET SAT PAIR? 2.
Set up using the Graphical User Interface You can also set up your Raymarine Satellite TV system using the Graphical User Interface (GUI) which can be found on the CD-ROM. The CD-ROM contains folders for the different areas of operation. Open the correct folder for your area of operation.
The GUI control soft keys The following is an explanation of the operation of the different GUI soft keys: Connection status Baudrate setting Serial port setting D8016_1 Raymarine Satellite TV Systems D8359_1...
Restart Click this soft key to restart the antenna tracking the chosen satellite. Setup Click this soft key to enter the GUI set up mode prior to making any changes. Get Antenna Information Click this soft key to display the current system settings. Advanced Control This is a password protected area for dealer use only.
Editing the satellite information This section of the GUI enables you to edit satellite information Raymarine Satellite TV Systems To edit a satellite’s information: 1. Click ‘Set Satellite Information’ in the menu options. The set satellite information screen is displayed.
Setting antenna angle, move step and diagnosis. You can move the antenna to a new target position or carry out diagnosis using the Move antenna - Execute diagnosis function of the GUI. Moving the antenna to a new position There are two methods for moving (stepping) the antenna to a new position: •...
5. Tighten the LNB securing screws. 6. Refit the antenna unit cover. 7. Power the system ON and function test. Note: Certain Raymarine 60STV Satellite TV systems have automated skew control. These systems will automatically rotate the LNB to maximize reception in your location.
Ensure that the system is isolated from your boat’s power supply before carrying out any maintenance. Your Raymarine Satellite TV system has been designed to require minimal maintenance. The following routine maintenance checks will ensure that your system maintains peak performance: •...
Page 50
5. Incorrect or loose RF or power/data connectors As part of the regular maintenance recommended by Raymarine, all connections should be checked to ensure that they have not become loose. A loose RF or power/data connector can reduce signal quality or cause the antenna not to work.
Antenna diagnosis 1. Press YES to enter set up mode. SETUP MODE? 2. Press NEXT 8 times to go to Antenna SET SAT PAIR? Diagnosis menu. PREV NEXT 3. Press YES to enter diagnosis mode. ANT DIAGNOSIS? PREV NEXT CODE101 TESTING 4.
Technical support You can obtain Technical Support for your Raymarine Satellite TV System from the following: www.raymarine.com United States Raymarine Technical Support 1-800-539-5539 extension 2444, or (603) -881-5200 Product Repair and Service Raymarine Product Repair Center 21 Manchester Street, Merrimack, NH 03054 - 4801...
Satellite information Introduction This section contains information on satellites in your region and includes: • Satellite coverage areas. • Satellite coverage by geographic location. • Satellite tracking information Satellite coverage areas The following satellite coverage maps do not guarantee coverage. This can be affected by climatic conditions that may cause variation in the satellite signal.
Page 54
Astra 2A South Hotbird 60STV 45STV D9227_1 Raymarine Satellite TV Systems 60STV 45STV D9228_1...
Satellite tracking Your Raymarine Satellite TV System can track a variety of DVB compatible and DSS (DIRECTV) satellites. Your system contains a pre-programmed library of either European or North American satellites, whichever are applicable to your system. There are also two open slots which can be programmed with user defined satellites.
Page 68
0X1004 20000 0X1009 20000 0X1009 20000 0XFFF7 20000 0XFFF7 20000 0XFFF0 20000 0XFFF0 20000 0X1004 20000 0X1004 Raymarine Satellite TV Systems LNB band Decoding polarization type (vertical or hori- zontal) RHCP LHCP RHCP LHCP RHCP LHCP RHCP LHCP RHCP LHCP...
Page 69
Australia and New Zealand Satellite Frequency Transponder name symbol rate Optus B1 12608 12456 Optus C1 12447 12358 Far East Satellite Frequency Transponder name symbol rate Agila2 12301 Telstar 10 12528 12551 Telstar 18 12538 FEC code Satellite network ID 22500 0x00B6 22500...
Appendix 7: Technical specification Raymarine 45 STV General Approvals CE - conforms to EU Directive 89/336/EEC FCC- verified to CFR47: Part 15 Dimensions Satellite antenna unit 500 mm x 538 mm (19.7 x 21.2 ins.) Antenna dish diameter 450 mm (18 ins.) Antenna control unit 195 mm x 225 mm x 65 mm (7.6 x 8.8...
Page 72
Local oscillator jump @ 13/18 V switching Local oscillator phase noise Conversion gain Gain flatness Raymarine Satellite TV Systems 160 mA (max) 0 Hz - Low band 22 KHz + 4 KHz - High band C ~ +60 C ~ +80 Linear vertical and horizontal 12.1 ~ 12.7 GHZ...
Page 73
Dual LNBF Gain variation 5 dB (max) across 500 MHz Cross polarization isolation 25 dB (min.) Image rejection 40 dBm (min.) Output VWSR 2.1(max) in a 75 W system Noise figure 1.1 dB (max) Po 1 dB 0 dBm (min.) -50 dBc (max), two tones of -15 dBm order intermodulation output spaced 27 MHz...
C (-4 F to 158 Universal Twin LNBF RF input frequency range IF output frequency range Local oscillator frequency Raymarine Satellite TV Systems Ku-band (10.7 to 12.75 GHz) 36 dBi 47 dBW to 90 Roll - + 25 Pitch - + 15...
Page 75
Universal Twin LNBF Local oscillator frequency stability + 1.0 MHz @ 25 + 2.0 MHz @ -40 Local oscillator phase noise -50 dBc/Hz @ 1 kHz -75 dBc/Hz @ 10 kHz -95 dBc/Hz @ 100 kHz Conversion gain 50 dB (min), 60 dB (max) Gain flatness + 0.5 dB/26 MHz Cross polarization isolation...
Page 76
Output in band spurious Output VWSR Noise figure Output connector type Raymarine Satellite TV Systems 10.7 ~ 11.7 GHz - Low band 11.7 ~ 12.75 GHz - High band 950 ~ 1950 MHz - Low band 1100 ~ 2150 MHz - High band 9.75 GHz - Low band...
Page 77
QuadLNBF (EU Premium models) Polarization switching voltage 10.5 V ~ 14.0 V @ VP 16.0 V ~ 19.0 V @ HP DC current consumption 160 mA (max) Band switching signal (DiSEqC 1.0 0 kHz - Low band interface) 22 kHz + 4 kHz - High band Operating temperature range C ~ +60 Storage temperature range...
