Service
Information
© 2011 Reg. Office: Peterborough PE2 9JB Registered in London: 106725
Indesit Company UK Ltd
5407366 Issue 3
C00196081
FREESTANDING
LARDER
FRIDGES
Model
Covered
Energy Band 'A' Models
SD1511
SD1513
SD1711
SD1711V
SD1712V
Energy Band 'A+' Models
SD1521
SD1522
SD1522HA
SD1721
SD1721VHA
SD1722J
SD1722JHA
SD1722VHA
SD1723
SD1746
April 2011
Comm.
Code
44302
44303
44308
47201
47203
44301
47204
53532
44306
53528
44307
53531
53530
44305
44304
Advertisement
Table of Contents
Related Manuals for Hotpoint Ariston SD1511
Summary of Contents for Hotpoint Ariston SD1511
- Page 1 5407366 Issue 3 April 2011 C00196081 FREESTANDING LARDER FRIDGES Model Comm. Covered Code Energy Band 'A' Models SD1511 44302 SD1513 44303 SD1711 44308 SD1711V 47201 SD1712V 47203 Energy Band 'A+' Models SD1521 44301 SD1522 47204 SD1522HA 53532 SD1721 44306 SD1721VHA...
-
Page 2: Health & Safety
Indesit Company HEALTH AND SAFETY For the servicing of refrigeration products, containing Isobutane R600a refrigerant. These instructions are in addition to any other Company procedures already published. Published primarily for Indesit Company engineers working in the UK or Southern Ireland, for which these instructions are MANDATORY. - Page 3 Indesit Company HEALTH AND SAFETY 19. Working with a naked flame i.e. soldering or brazing is forbidden. Unless otherwise stated, pipework connections must only be made using the Lokring coupling system. 20. Electronic leak detectors with high voltage tips must NOT be used with any Isobutane (R600a). 21.
-
Page 4: Table Of Contents
Indesit Company CONTENTS Health & Safety ........... . .2 - 3 Index &... -
Page 5: Introduction
Indesit Company MODEL INTRODUCTION The models included in this publication are 1500 and 1700 mm high larder fridges, introduced in March 2007. All models are similar with regard to the furniture design, but there are variations for energy-banding (A and A+), exterior colour and 'V' models that have an air circulation fan in the fridge compartment. -
Page 6: Specifications
Indesit Company SPECIFICATIONS Colours Introduction Date - March 2007 Polar White SD1721 SD1511 SD1521 SD1711 SD1711V SD1721VHA SD1746 Argento Vivo SD1513 SD1723 Inox SD1522 SD1522HA SD1712V SD1722J SD1722JHA SD1722VHA 'V' = Ventilation Fan 'J' = Joining models – SD & UP1722J 'HA’... - Page 7 Indesit Company TECHNICAL DATA: Power Supply Voltage: 220/240 V Power Supply Frequency: 50 Hz Absorption Current: Normal Operation 0.8 Amps COMPRESSOR WINDING Manufacturer: ACC/ZEM TECUMSEH Type I/D: HTK55AA-2 THG1340MKS Winding Resistance Start: 30.3 28.4 Run: 31.9 25.9 Refrigerant/ Grams: R600a - Refer to the appliance rating plate ENERGY: Model: SD15**...
-
Page 8: Product Description With Image
Indesit Company DESCRIPTION OF APPLIANCE: Temperature Control Removable Lidded Shelf with Egg Tray Removable Multipurpose Shelves Shelves Bottle Shelf Fruit and Vegetable Bin Levelling Feet Service Manual UK English 8 of 17... - Page 9 Indesit Company NOTES Service Manual UK English 9 of 17...
-
Page 10: Door Reversal Instructions
Indesit Company DOOR REVERSAL (All models except SD1722J and SD1722JHA) OLD AESTHETIC DOOR (ORIGINAL) & NEW AESTHETIC DOOR (STANDARD) All the images below refer to the door with new aesthetics unless otherwise stated. Important Notes for Guidance: Before commencing any work refer to the Safety Notes at the beginning of this manual. Read the instructions on the next page fully and refer to the diagrams below before carrying out the door reversal. -
Page 11: Sd1722Jha
Indesit Company DOOR REVERSAL (All models except SD1722J and SD1722JHA) OLD AESTHETIC DOOR (ORIGINAL) & NEW AESTHETIC DOOR (STANDARD) All the instructions below refer to the door with new aesthetics unless otherwise stated. Fig 1: Removing the Door and Top Hinge fittings Open the door and ease the hinge cover strip out from above the door seal;... -
Page 12: J' Models ~ Joining Kit Instructions
Indesit Company JOINING KIT - 'J' MODELS ONLY Freezer Supplied ~ LH door hinging – Fridge Supplied ~ RH door hinging Before attempting to join the two appliances together, it is important to level each appliance separately in the position it will stand. If this is not done properly it will be more difficult to join the appliances together and undue stresses may be introduced into the cabinets over time. - Page 13 Indesit Company JOINING KIT - 'J' MODELS ONLY Remove the base moulding from the fridge and insert the multiple hole 'hinge fixing plate' in the slot behind the lower left hand hinge position. Affix the tapping plate using the screws provided. See image below.
-
Page 14: Wiring Connection Information
Indesit Company WIRING CONNECTION CHART CONTROL HARNESS PLUG CONTROL HARNESS SOCKET Front View Rear View Foamed in Place PLUG & SOCKET Used in “V models only: For other models, see thermostat connections 1 ~ Not used 1 ~ Rear Link to Light only 2 ~ Black ~ Thermostat 3 2 ~ Black ~ Compressor Black ~ Ventilator... -
Page 15: Terminal Thermostat
Indesit Company 3 TERMINAL THERMOSTAT Thermostats may have 3 terminals and incorporate an OFF switch position in addition to the thermostat switch. This type of thermostat is a direct replacement for existing 3 terminal types. It is also a suitable replacement for 2 Terminal type thermostats fitted to these models which do not have the OFF position. -
Page 16: Theoretical Wiring Diagram
Indesit Company THEORETICAL WIRING DIAGRAM 2 TERMINAL THERMOSTAT COMPRESSOR CAPACITOR THERMOSTAT (if fitted) VENTILATOR - ‘V’ MODELS ONLY LIGHT LIGHT SWITCH 5407607wd1.pdf SD1722VHA 3 TERMINAL THERMOSTAT COMPRESSOR CAPACITOR (if fitted) THERMOSTAT VENTILATOR - ‘V’ MODELS ONLY LIGHT LIGHT SWITCH 5407607wd2.pdf SD1722VHA Service Manual UK English... - Page 17 Indesit Company Service Manual UK English 17 of 17...
