CHANGING YOUR LANDSCAPE SINCE 1945
swisherinc.com
OWNER'S MANUAL
2645R
Starting Serial #: L212-261001
Plow Blade, 50"
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
Before Operating this
Equipment.
ade I The
SWISHER ACQUISITION INC.
USA
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE 660-747-8183 FAX 660-747-8650
of US and Global Parts
11529 REV 12-261

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2645R and is the answer not in the manual?

Questions and answers

Related Manuals for Swisher 2645R

Summary of Contents for Swisher 2645R

  • Page 1 Plow Blade, 50" IMPORTANT Read and follow all Safety Precautions and Instructions Before Operating this Equipment. ade I The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 PHONE 660-747-8183 FAX 660-747-8650 of US and Global Parts 11529 REV 12-261...
  • Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the product will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. • Read the manual. Learn to operate this machine safely. •...
  • Page 4 PLOW PARTS DETAIL Cut Edge 2317 (9) is preinstalled to Blade 2150 (29) using 5/16-18 X 3/4 Carriage Bolt 10216 (8) and 5/16-18 Serrated Flange Nut NB170 (11). Item # Part # Description Item # Part # Description AS125 Cap - Round Vinyl, Black NB121 Nut - Jam Lock, 1/2-13 2-Way NB182 Nut - Nyloc 3/8-16...
  • Page 5 TO ENSURE PROPER ASSEMBLY, CAREFULLY FOLLOW ALL INSTRUCTIONS LISTED BELOW Pivot Latch Assembly These steps need to be done in sequence: Lay parts down in the order they are shown below. Slide Plow Mount 2588 (24) into Pivot Weldment 2323 (18) and secure with ½-13 X 3½ Bolt NB577 (25) and ½-13 Nyloc Nut NB281 (15).
  • Page 6 TO ENSURE PROPER ASSEMBLY, CAREFULLY FOLLOW ALL INSTRUCTIONS LISTED BELOW Pivot Mount Assembly Connect Skid Weldment 10068 (12) through the channel on the outer right edge of the Blade using Clevis Pin NB300 (7) and Hair Pin NB127 (10) in the order shown below. Repeat for the left side.
  • Page 7 TO ENSURE PROPER ASSEMBLY, CAREFULLY FOLLOW ALL INSTRUCTIONS LISTED BELOW Tilt Spring Assembly Assemble one 3/8-16 Nut NB212 (4) to each Eyebolt NB635 (5). Attach one end of Tilt Spring 2335 (6) to the Plow Mount assembly tab and the other end to Eyebolt NB635 (5).
  • Page 8 * MODEL NUMBER - _______________ TYPE - _______________ * PART NUMBER WITH PAINT CODE * PART DESCRIPTION TELEPHONE - 1-800-222-8183 FAX - 1-660-747-8650 ade I The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 PHONE 660-747-8183 FAX 660-747-8650 of US and Global Parts...
