- Page 1 Double Built in Oven Users Guide & Installation & Servicing...
-
Page 2: Table Of Contents
Contents Safety Instructions Before first use The Facia Panel Oven accessories Oven operation Main oven Top oven Oven temperature Oven cooking chart Grilling in the oven Grilling cooking chart Installation Technical Data... -
Page 3: Safety Instructions
• Do not use the oven to heat kitchen, not only does this waste fuel but the control knobs may become overheated. • Do not let children near the oven during use to avoid the danger of burns or injury. -
Page 4: The Facia Panel
See fig. USERS GUIDE The shelf supports are numbered from 1- 5 in the main oven and 1-3 in the top oven, position 1 being the lowest. The oven pan can be used for roasting or grilling in the oven. When grilling, fit the handle to the oven pan to slide it in or out of the oven. -
Page 5: Main Oven
The oven should be pre-heated for 5-10 minutes before use. The oven pan should be used on one of the upper shelf positions. Fit the handle when sliding the oven pan in or out of the oven. -
Page 6: Oven Temperature
5-10 minutes before use. This function is ideal for grilling small quantities of food. Fit the handle when sliding the oven pan in or out of the oven. Grilling must always take place with the oven door closed in order to ensure correct performance of this function. -
Page 7: Oven Cooking Chart
Roast turkey Vegetable bake Beef casserole 500g is approximately 1lb (1lb 2oz) Temperature Conversion Chart In order to convert existing recipes for use in your oven, use this chart as a guide. COOKING GUIDE Shelf Cooking Temp ºC Position time/mins 20-25... -
Page 8: Grilling In The Oven
Food should be arranged on a wire shelf on one of the upper shelf positions. The oven pan should be placed into the oven with the trivet in place to collect any juices. Fit the handle to the oven pan when sliding it in or out of the oven. -
Page 9: Setting The Time Of Day
(see diagram) Setting the time of day When the oven is first connected to the mains electricity supply or following a power failure, three zeros will flash in the time display. To set the time of day... -
Page 10: Cleaning And Care
( until the time display reads zero. Press ) button and at the ( ) button to reset the main oven to manual operation. The flashing ( indicator will disappear. The main oven can now be used manually. -
Page 11: Removing The Shelf Supports
This will lock the hinges in the open position. Stand in front of the oven and grasp the open door with one hand on each side. Lift the door as if closing it until it is at an angle of about 30º, then continue lifting the door towards you, out of the hinge slots. -
Page 12: Solving Problems
Please contact your Rangemaster dealer for details. With catalytic liners fitted to the main, only the roof, floor and door of the oven require conventional cleaning (see page 11). -
Page 13: Installation
A.C. single phase 230 V, 50 Hz electricity supply. The total rated load is 3.9kW. The oven must be connected to a 30 amp power supply via a suitable isolator with an on-off switch, and protected by a 30 amp fuse. The isolator should be easily accessible in case of maintenance or emergency. - Page 14 INSTALLATION Built-in installation This appliance is designed for building- in to a standard 600mm wide oven housing. The housing, adjacent furniture and all materials used in installation must be able to withstand a minimum temperature of 80ºC plus ambient...
- Page 15 INSTALLATION When placing the oven in the housing, do not use the oven door as a lever for lifting the oven as damage may result. Once the oven has been positioned in the housing it should be secured in place at the four corners of the oven door frame using suitable screws (see diagram).
-
Page 16: Technical Data
Technical Data Electrical ratings Total rated load Main oven fan element Main oven grill element Top oven upper element 0.9kW Top oven lower element 1.3kW Top oven grill element Oven interior volumes Main oven volume Top oven volume Overall appliance dimensions...
