USER'S GUIDE
Mark 5 Nuvo
Lite
OXYGEN CONCENTRATOR
[Original language is English]
Federal Law (US) restricts this device to sale
or use by, or on the order of, a licensed phy-
sician. This oxygen concentrator should be
used only under the supervision of a licensed
physician.
GLOSSARY OF SYMBOLS..........................................1
GENERAL SAFETY GUIDELINES ............................2
1
Unpacking and Packaging....................................... 3
1.1 Method for disposing of waste..................................3
1.2 Method for disposing of device.................................3
2
DESCRIPTION.......................................................3
2.1
Front panel (Fig. 2.1)......................................... 4
2.2
Rear panel (Fig. 2.2) ..............................................4
3
STARTING-UP / INSTALLATION .......................4
3.1 Use in direct oxygen therapy ...................................4
3.2 Turning off device.....................................................5
4 CLEANING-MAINTENANCE ...............................5
4.1 Cleaning ...................................................................5
I
: ON (power switched on)
O
: OFF (power switched off)
: Type B device
: Class II protection
: Do not expose to open fl ames
2010-8403CE Rev C
(OCSI)
Contents
4.2 Daily disinfection..........................................................5
4.3 Maintenance............................................................ 6
5 USEFUL INFORMATION........................................6
5.1 Accessories and spare parts....................................... 6
5.3 Operating principles.................................................. 7
5.4 Alarms-Safety devices-Indications ........................... 7
5.5 OCSI function .......................................................... 8
5.6 Technical characteristics ........................................... 8
5.7 Standards................................................................... 9
5.8 Troubleshooting.......................................................10
Notes.................................................................................11

GLOSSARY OF SYMBOLS

0413
Complies with the 93/42/EEC directive
certifi ed by the approved organization no 0413.
Danger: Do not smoke when using oxygen or when
near this device.
: Do not use oil or grease
: Technical information
: Consult the accompanying documents
: Keep in the vertical position
: Fragile - handle with care
: Oxygen concentration warning light
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mark 5 Nuvo OCSI Lite 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nidek Medical Mark 5 Nuvo OCSI Lite 3

  • Page 1: Table Of Contents

    USER'S GUIDE Mark 5 Nuvo (OCSI) Lite OXYGEN CONCENTRATOR [Original language is English] Federal Law (US) restricts this device to sale 0413 Complies with the 93/42/EEC directive or use by, or on the order of, a licensed phy- certifi ed by the approved organization no 0413. sician.
  • Page 2: General Safety Guidelines

    GENERAL SAFETY GUIDELINES Only persons who have read and understood this entire manual should be allowed to operate the MARK 5 Nuvo Lite The CAUTIONS below indicate a potentially The WARNINGS below indicate a potential hazardous situation. If conditions are not hazardous situation.
  • Page 3: Unpacking And Packaging

    Mark 5 Nuvo Lite with the accesso- provider. Operating environmental condi- ries recommended by Nidek Medical Products, tion guidelines are discussed later in another Inc. Refer to section 5. section of this User's Guide.
  • Page 4: Front Panel (Fig. 2.1)

    3. STARTING UP / INSTALLATION 3.1. Use in direct oxygen therapy a. Ensure that the switch (Item1 in Fig.2.1) is in the O (OFF) position. b. For use without Humidifi er Bottle connect the cannula directly to the concentrator oxygen product outlet (Item 3 in Fig 2.1).
  • Page 5: Turning Off Device

    3.2 Turning off device e. Plug the power cable into a power outlet (Fig. 3.3) of the correct voltage and frequency as At the end of the treatment, press the I/O Switch defi ned on the manufacturer's technical label to place it in the O (OFF) position to stop the (Fig 2.2).
  • Page 6: Maintenance

    • Empty the water from the humidifi er. must be designed for oxygen therapy usage. • Rinse the humidifi er fl ask under running The accessories with a Nidek Medical part water • Fill humidifi er up to the mark with water...
  • Page 7: Material In Direct Or Indirect Contact With Patient

    5.2. Materials in direct or indirect contact Process fault • with the patient In the case of a process fault, a visible and au- dible alarm is activated (continuous red light or Concentrator casing ........ABS lighted alarm and audible alarm). Power Cord ...........
  • Page 8: Ocsi Function

    5.4.3 Indicators (continued) 5.5.4 Maintenance of the Device Alarms • The red indicator warns of a process No special maintenance is required. The alarm fault. One event that can cause the red set-point is factory set and the setting cannot be indicator to be illuminated is low oxy- adjusted.
  • Page 9: Standards

    Mark 5 Nuvo Lite Serial No. _______ Electrical power supply: _________________________________ Rating: 230V 50Hz Date fi rst used : __________________ Average Power: 180 W(avg) Protection Class: Class II Maintained by: __________________ Mains Protection: ________________________________ Filters: Your distributor: ________________ At the rear of the device: a cabinet air fi lter. At the compressor input: an inlet air fi...
  • Page 10: Troubleshooting

    5.8. Troubleshooting. Observations Possible Causes Solutions The I/O (ON/OFF) button is in the "I" Power cord is not correctly (ON) position but the device does not Check the cable connection. plugged into the wall outlet. operate. Check the circuit breaker (5) on the The audible alarm sounds intermit- Power failure.
  • Page 11: Notes

    NOTES ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ 2010-8403CE Rev C September 2013...
  • Page 12: September

    EU Representative mdi Europa GmbH Langenhagener Str. 71 30855 Hannover-Langenhagen Germany Nidek Medical Products, Inc. 3949 Valley East Industrial Drive Tel: +49-511-39-08 95 30 Birmingham, Alabama 35217 U.S.A. Fax: +49-511-39-08 95 39 Tel: 205-856-7200 Fax: 205-856-0533 info@mdi-europa.com info@nidekmedical.com www.mdi-europa.com www.nidekmedical.com...
