RadioLAN DockLINK User Manual

Wireless local area network
Hide thumbs

Advertisement

Wireless Local Area Network
DockLINK User Guide
890-010 12/04/98
© 1998 RadioLAN. All rights Reserved

Advertisement

Table of Contents
loading

  Related Manuals for RadioLAN DockLINK

  Summary of Contents for RadioLAN DockLINK

  • Page 1 Wireless Local Area Network DockLINK User Guide 890-010 12/04/98 © 1998 RadioLAN. All rights Reserved...
  • Page 2 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 890-010 12/04/98 Page ii © 1998 RadioLAN.
  • Page 3 Maximum Output Power: 50 mW Notes: This device has shown compliance with new rules adopted under Docket 87-389 and is not affected by Section 15.37, transition rule. Each radio is marked with its operating frequency. 890-010 12/04/98 Page iii © 1998 RadioLAN.
  • Page 4: Disclaimer

    RadioLAN and its writers assume no responsibility for inaccuracies and reserve the right to modify and revise this document without notice. It is always our goal at RadioLAN to supply accurate and reliable documentation. If you discover a discrepancy in this document, please e-mail your comments or suggested corrections to marketing@radiolan.com.
  • Page 5: Trademark Disclosures

    Manual Conventions The following text formats are used throughout this manual: References to other locations in the manual or to other manuals provided by RadioLAN are italicized. Narrow Bold Letters describe buttons and fields on the screen. describe Screen Names or Screen Tab Names.
  • Page 6: Table Of Contents

    Installing the DockLINK... 9 Locating the Radio Unit... 10 Connecting the DockLINK ... 11 Initial IP Address Setup... 13 Using the DockLINK Manager ...16 The DockLINK Manager... 16 Accessing the DockLINK with the Browser ... 17 890-010 12/04/98 Page vi © 1998 RadioLAN.
  • Page 7 Viewing the System Log... 62 Managing the DockLINK Locally...63 DockLINK Local Management ... 65 Configuring the DockLINK for use in the Dock Mode ... 66 Logging onto the DockLINK Configuration Screen... 67 Using the Main Menu ... 69 Working with the System Configuration Menu... 71 Configuration Manager Menu Items ...
  • Page 8 Appendix B: Technical Specifications ...95 Network Protocol ... 95 Standards Support... 95 Electrical Specifications... 95 Physical Specifications... 96 Environmental Specifications... 96 Electromagnetic Emissions ... 97 Safety Agency Approvals ... 97 Getting Technical Support...98 Index ...99 890-010 12/04/98 Page viii © 1998 RadioLAN.
  • Page 9: Introduction

    Network device, such as a PC, workstation, or printer, allowing interaction with RadioLAN wireless network resources. The DockLINK includes a Radio Unit, a RJ-45 jack for connection to an Ethernet Hub, a power jack, and a special RJ11 serial port for connecting the DockLINK to a VT-100 terminal or modem.
  • Page 10 DockLINK. If you set an IP Address in the DockLINK, you will receive an IP Address response only when you Ping the DockLINK from the device to which it is connected.
  • Page 11 Designed for Simplicity The DockLINK is designed to be installed and set up quickly. If you require no more than basic management of packet flow, you can simply install the DockLINK and begin using its powerful network access capabilities. In circumstances like these, there is no need for custom configuration.
  • Page 12 The DockLINK includes a built-in serial port for connecting a VT-100 terminal or a modem. Using a terminal allows you serial access configuration and system performance pages. Connecting a modem to the Serial port allows you to dial into the DockLINK from a remote location to log in and configure or view system performance. System Requirements To successfully place a DockLINK into operation, you must meet the following requirements: The DockLINK must connect directly to a 10BaseT Network Interface Card.
  • Page 13: Quick Installation Steps

    10BaseT equipment and puts it onto the wireless network. Like other RadioLAN products, the DockLINK is easy to install in just a few steps. 1. Locate the DockLINK near to the 10BaseT device, like the printer in Figure 3.
  • Page 14: To Test The Antenna Placement

    Installation of the DockLINK does not require the use of tools, and no configuration is needed in the DockLINK for operation. If your site uses RadioLAN SubNet ID codes, or encryption, then the DockLINK will need to be configured before operation.
  • Page 15: Designing Your System

    Designing Your System This section describes the best ways to locate one or more DockLINKs, and to orient the DockLINK’s Radio Unit. For best performance, orient the DockLINK’s Radio Unit perpendicular to the horizon. Because signal strength and quality diminish when the Radio Unit is enclosed, it is best to locate the Radio Unit outside of cabinets. The most suitable locations are above obstacles such as cubical walls or shelves.
  • Page 16 To test for best signal quality, locate a temporary wireless station in the location at which you intend to locate the DockLINK. Use the N station on the network to verify signal quality. Also test locations where fixed wireless stations are not normally located, such as conference rooms.
  • Page 17: Installing The Docklink

    Installing the DockLINK Before installing the DockLINK, note the DockLINK’s Media Access Control (MAC) Address. Each DockLINK’s MAC Address is noted on the bottom of the DockLINK’s housing. There are three basic inputs required by the DockLINK (see Figure 5):...
  • Page 18: Locating The Radio Unit

    DockLINK and all wireless stations that communicate with it. You can locate the DockLINK assembly on the desk next to your PC, or when using a longer Category 5 cable, you can mount the assembly on a wall, or ceiling.
  • Page 19: Connecting The Docklink

    Connecting the DockLINK You must connect the DockLINK to the station’s 10BaseT Network Interface Card and to the power adapter. Optionally, you can also connect a modem or VT-100 terminal to the DockLINK for local configuration. Follow these steps to connect external cabling to the DockLINK: 1.
  • Page 20 Network Interface Card and the 10BaseT jack on the DockLINK. Connect the cable to the DockLINK first, and then connect the other end of the cable to the port on the station’s Network Interface Card. 5. Set the MDI/MDI-X push-button switch to the correct setting for the RJ-45 Dual- modular cable.
  • Page 21: Initial Ip Address Setup

    DockLINK an IP Address. Connect the DockLINK To use the IP ASSIGN Utility, you must first connect DockLINK to the station’s 10BaseT Network Interface Card. The station must not be running a DHCP server while performing this procedure. 1. Determine the method that you are using to assign the IP Address:...
  • Page 22 The DockLINK’s Power LED illuminates. If you are using the local station, see Using the IP ASSIGN Utility to Optionally assign the DockLINK’s IP Address on page 15. If you are using the DockLINK Local Port, see Managing the DockLINK Locally on page 65.
  • Page 23 The utility returns a page listing of the MAC Addresses for all non-configured DockLINKs on the LAN segment. 3. Highlight the MAC Address for the DockLINK that you want to configure. 4. Enter the desired temporary IP Address for the DockLINK. Later, you can permanently set it using the IP screen. ARAMETERS The utility checks the IP Address to verify its validity.
  • Page 24: Using The Docklink Manager

    Web browser. Your browser must support Java script and frames. After launching your browser, enter the IP Address for the DockLINK. If you just setup the DockLINK for the first time, you should have already assigned the DockLINK’s IP Address using the IP ASSIGN Utility, or with the VT-100 terminal.
  • Page 25: Accessing The Docklink With The Browser

    Accessing the DockLINK with the Browser To access the DockLINK with your browser, follow these steps: 1. Open your Web browser. 2. In the browser’s address field, type the IP Address for the DockLINK, and then press Enter. The DockLINK’s L page appears.
  • Page 26 Product ID The Product ID field is a read-only field that reports the Product ID for the DockLINK. Enter User Name The Enter User Name field is an entry field where you enter your user name to gain access to the configuration and diagnostic pages.
  • Page 27: Docklink Manager Layout

    DockLINK Manager Layout The DockLINK Manger uses frames that allow you to size and view the pages according to your needs. The menu is made up of seven major topics: Node Discovery – Find connected stations here. System Features – Enable enhanced DockLINK features here.
  • Page 28 You can size the frames by clicking on the divider line and dragging the line to the size that meets your needs. Figure 12: The Main Page 890-010 12/04/98 Page 20 © 1998 RadioLAN.
  • Page 29: Discovering Wireless Nodes Within The Docklink's Data Range

    ISCOVERY currently within data range of the DockLINK. Nodes found on this screen are connected to the local station using the DockLINK as a bridge. The page displays a table with two main tabs: Station List Connectivity...
  • Page 30 Station List The Station List tab shows a list of stations that are currently connected to the DockLINK. The list is a table with a number of columns. Clicking on column headings sorts the list alphabetically. Clicking the table heading again reverses the sort.
  • Page 31 890-010 12/04/98 Score Color Transceiver Orientation Light Best location Green Dark Good location Green Yellow Improve if possible Yellow Need to improve Out of data range Out of carrier range Table 1 : Link Quality Ratings Page 23 © 1998 RadioLAN.
  • Page 32 Link This column shows the connectivity quality for the station. Table 1 on page 23 shows the meaning of the quality designation. 890-010 12/04/98 Figure 14: Node Discovery Network Information Page: Connectivity Tab Page 24 © 1998 RadioLAN.
  • Page 33: Setting Up Security Features

    The page contains User 1 – 3 Logon Name fields, and User 1 – 3 Password fields. Since you can only access the DockLINK from the local station, you may wish to use only the User 1 Login Name and Password.
  • Page 34 IP Parameters IP Parameters allow you to set up information about the IP Address for the DockLINK. The IP P page contains fields that allow you to set up IP Parameters. The following items are on the IP page: ARAMETERS...
  • Page 35 The IP Address field allows you to designate the IP Address for the DockLINK. The IP Address identifies the DockLINK to the station to which it is connected, but not the wireless Network. The format of an IP Address is a 32- bit numeric address written as four numbers separated by periods.
  • Page 36 250.040.123.243 The DockLINK is set for no DHC by DEFAULT. While operating, the DockLINK does not use a public IP address for use in DHCP functions. If the Ethernet connection is disconnected, then the DockLINK operates on the DHCP by way of the radio interface.
  • Page 37 Acquire system IP Only Radio Button Select this button to cause the DockLINK to automatically search for, and acquire the DHCP Server IP Address. If the DockLINK finds the server address, that address appears in the DHCP Server IP Address field. This is the factory default in version 2.00 units.
  • Page 38: Setting The Docklink's Mode Of Operation

    DockLINK. This screen displays software options that are currently enabled. If you are using DockLINK version 2.0 or higher, the screen allows you to use one choice: Dock Mode...
  • Page 39: Securing The Docklink With Data Encryption

    This selection enables or disables Data Encryption on DockLINK data packets. Checked Enables Data Encryption. Only stations that share the same encryption key can exchange data with the DockLINK. Clear Disables Data Encryption. All users with the same Subnet ID can share network resources.
  • Page 40: Setting Up10Baset Port Parameters

    Entries on this page other than the Port Name field can disable communication with the Network Interface Card: RadioLAN Recommends that you avoid making changes to items on this page. Although unnecessary, if you have a particularly special application, you can edit other items on the screen.
  • Page 41 MAC Address Filter The MAC Address Filter check box allows you to enable or disable the DockLINK’s internal MAC Address Filter. The MAC Address Filter is a database that stores MAC Addresses received by the DockLINK while communicating with the 10BaseT Network Interface Card and RadioLAN Wireless Network. Once information is stored in the database, you can allow or disallow packet flow to or from remote addresses in the database.
  • Page 42 NetBIOS allows you to use the Network Basic Input Output System. Unchecked Clearing a check mark from the check box disables NetBIOS Address filtering. Checked Placing a check mark in the check box enables NetBIOS Address filtering (blocks NetBIOS packets). 890-010 12/04/98 Page 34 © 1998 RadioLAN.
  • Page 43 Block NetBIOS Packets Port Name The Port Name field allows you to enter up to 12 characters that identify the name of the DockLINK. This appears as the DockLINK’s Station Name for users of Radionet Manager or the EZRadio configuration programs. It...
  • Page 44 MAC Address Filter The MAC Address Filter check box allows you to enable or disable the DockLINK’s internal MAC Address Filter. The MAC Address Filter is a database that stores MAC Addresses received by the DockLINK while communicating with the RadioLAN Wireless Network.
  • Page 45 The Block IPX Packets check box allows you to enable or disable communication with Novell IPX protocol networks. Unchecked Clearing a check mark from the check box disables IPX Address filtering. Checked Placing a check mark in the check box enables IPX Address filtering. 890-010 12/04/98 Page 37 © 1998 RadioLAN.
  • Page 46 The Block NetBIOS Packets check box allows you to enable or disable communication to networks that use the Network Basic Input Output System. Unchecked Clearing a check mark from the check box disables NetBIOS Address filtering. Checked Placing a check mark in the check box enables NetBIOS Address filtering. 890-010 12/04/98 Page 38 © 1998 RadioLAN.
  • Page 47 Setting the Baud Rate for the Local Port The DockLINK allows you to connect and manage with a local terminal. This screen allows you to set the baud rate for the terminal. Select from the following available baud rates: 9600 baud...
  • Page 48: Managing Packet Flow Through The Docklink

    Managing Packet Flow through the DockLINK The DockLINK can selectively allow or disallow traffic to or from the 10BaseT Network Interface Card and the RadioLAN wireless network. Proper packet flow management improves the speed of the RadioLAN wireless network by eliminating unwanted network traffic.
  • Page 49 Mask Bytes Source/Dest Accept/Reject Item The Item column shows the order in which the DockLINK stored the database entry. MAC Address The MAC Address column displays the MAC Address for the remote network node. Mask Bytes The Mask Bytes column displays the subnet mask address for the network node.
  • Page 50 DockLINK will not allow a message broadcast from that MAC Address to pass through. If the Source/Dest column contains Destination, and the Accept/Reject column contains Reject, the DockLINK will not allow the message intended for that MAC Address to pass through.
  • Page 51 Choose Destination if you want to filter messages that are broadcast from other nodes and intended for receipt by the MAC Address. 3. Allow or disallow the passage of the packet through the DockLINK, based upon the broadcast type (source or destination) in the Source/Dest Column: Choose Accept to allow the passage of packets to/from the MAC Address.
  • Page 52: Interrogating Docklink For Performance Information

    Interrogating DockLINK for Performance Information Performance is a combination of speed and accuracy. When the DockLINK transmits at higher rates, and retransmits packets fewer times, it has a higher rate of performance. Most users discover performance issues when sending large files from one node to another.
  • Page 53 Pressing the button resets all counters on this page to zero. Total Packets Transmitted Total Packets Transmitted counts and stores the total Figure 23: 10BaseT Port Statistics Page number of packets that the DockLINK sends to local station. This number represents all transmitted packets. 890-010 12/04/98 Page 45...
  • Page 54 Total Packets Received Total Packets Received counts and stores the total number of packets that the local station sends to DockLINK. This number represents all received packets. Total Error Packets This field displays the total number of Ethernet errors accumulated.
  • Page 55 Checking Radio Port Statistics The R ADIO TATISTICS DockLINK’s ability to communicate with wireless stations. The information on this page is automatically updated every ten seconds. This section describes the Page. ADIO TATISTICS The page has two major sections: Packet Transmission Packet Reception The screen also contains a Clear Counters button.
  • Page 56 The Packet Transmission stores information about packets that are sent from the DockLINK to wireless stations on the network. Total Packets Transmitted Total Packets Transmitted counts and stores the total number of packets that the DockLINK sends to wireless stations on the network. The number displayed all transmitted packets. Average Transmit Rate (Packets/Sec.) Sometimes packets are transmitted faster than at other times.
  • Page 57 Packet Reception The Packet Reception indicates the DockLINK’s ability to receive packets from distant wireless stations. Total Packets Received Total Packets Received counts and stores the total number of packets that the remote wireless stations send to the DockLINK. This number represents all received packets.
  • Page 58: Upgrading System Software

    DockLINK. On this page, type in the name of the file that you want to download, then click the download button to download the file from your station’s disk drive.
  • Page 59 This field allows you to enter the file name of the operating system file that you want to download. If you do not know where the file is located, click the Browse button to display a directory hierarchy. 890-010 12/04/98 Page 51 © 1998 RadioLAN.
  • Page 60 Download causes the DockLINK to retrieve the specified software file from the specified location. The downloaded file is written into system memory as the DockLINK receives it. As the DockLINK reboots after downloading, the new operating system runs immediately. 890-010 12/04/98...
  • Page 61: Saving Or Rejecting Configuration Setting Changes

    DockLINK to act. Save All Changes and Reset Radio Button This item causes all changes that you have made during this session to overwrite existing program entries. The DockLINK uses the new configuration after it restarts the system. 890-010 12/04/98 ONFIGURATION...
  • Page 62 This item causes all changes that you have made to change back to their original settings. Reset Configuration to Factory Default Radio Button This item causes the DockLINK to change all configuration items to their factory default settings. The DockLINK uses the new configuration after the next system restart.
  • Page 63: Resetting The Docklink

    DockLINK’s operating system, you must reset the DockLINK. One method of resetting the DockLINK is to remove power from the unit for approximately five seconds. Another method for resetting the DockLINK is found on the R...
  • Page 64: Testing Docklink Connectivity To The Wireless Network

    The Frames to Send field sets the number of packets that will be sent until the Ping session ends. After you start the Ping, the DockLINK sends this number of packets. The test ends when you press the Stop button, or when the count ends, whichever is first.
  • Page 65 This field displays the total number of frames sent during this test. Frames Acked This field displays the total number of times that the target station acknowledged the Ping packets. During best conditions, this number should match the number found in Frames Sent. 890-010 12/04/98 Page 57 © 1998 RadioLAN.
  • Page 66 This button starts the Ping test. After you have entered all selections, press this button to start the Ping test. The test runs until you press Stop, or until DockLINK has sent the same number of test packets as selected in Frames to send.
  • Page 67: Recording Important System Information

    Recording Important System Information Having system information on hand is essential to proper system management. The DockLINK Manager makes it easy to keep information on hand, recording configuration information that was last saved (see Saving or Rejecting Configuration Setting Changes on page 53).
  • Page 68 Subnet Mask Default Gateway 890-010 12/04/98 This information is loaded into the DockLINK from the factory. The information in this field should match the MAC Address noted on the bottom of the DockLINK. This information is loaded into the DockLINK from the factory. The information in this field should match the MAC Address noted on the bottom of the DockLINK.
  • Page 69 System Up Time 890-010 12/04/98 States the Boot Software Version stored in the DockLINK. States the Software Version that the DockLINK is currently using. States the System Software File Name. States the Hardware Version of the DockLINK. States the date when the DockLINK was manufactured.
  • Page 70: Viewing The System Log

    The screen displays a list with the following columns: Item This displays the item number on the list. As new events appear, the DockLINK issues new numbers. Task The Task column lists the task that initiated the message. Error No.
  • Page 71: Managing The Docklink Locally

    DockLINK. Using these methods, you can communicate with the DockLINK to make configuration changes or to interrogate the DockLINK for performance statistics. 890-010 12/04/98 Figure 33: Connecting the VT-100 Terminal to the DockLINK Page 63 © 1998 RadioLAN.
  • Page 72 The DockLINK uses an RJ11 jack for connection to the terminal. Use of this port requires a special interface cable that connects between the Serial Port jack and a DB9F serial connector. The pin-outs for this cable are shown in Table 2.
  • Page 73: Docklink Local Management

    The DockLINK Local Management software program allows you to view screens that contain configuration information about the DockLINK. Using this program, you can assign passwords, set up IP Addresses for the DockLINK, set address filters, test system performance, and view system performance statistics.
  • Page 74: Configuring The Docklink For Use In The Dock Mode

    Configuring the DockLINK for use in the Dock Mode When using the DockLINK in the Dock Mode to transform a hard-wired network station into a wireless station, the following configuration items apply. Prompt For more information, see . . .
  • Page 75: Logging Onto The Docklink Configuration Screen

    S YSTEM ONFIGURATION CREEN Serial Number The Serial Number field is a read-only field that reports the DockLINK’s Serial Number. 890-010 12/04/98 CCESS ECURITY Page 67 Figure 34: Logon Menu...
  • Page 76 If you make entries that do not match those stored in the program, you will remain on the L 890-010 12/04/98 , you will be allowed to view and edit items on the CCESS ECURITY CREEN Page 68 YSTEM ONFIGURATION CCESS ECURITY OGON © 1998 RadioLAN. CREEN...
  • Page 77: Using The Main Menu

    See information about this selection. System Features System Features takes you to the S menu, where you can select the DockLINK unit’s mode of operation and Data Encryption. See S selection. 890-010 12/04/98...
  • Page 78 Configuration Menu on page 71 for more information about this selection. System Statistics System statistics allows you to see the historical performance of the DockLINK. See S about this selection. System Status System Status allows you to interrogate the DockLINK for current system performance information.
  • Page 79: Working With The System Configuration Menu

    Working with the System Configuration Menu After selecting System Configuration on the Main Menu, the System Configuration menu appears, allowing you to setup a number of DockLINK network functions. The menu contains the following items: Administration Parameters IP Parameters 890-010 12/04/98 This selection is not needed for DockLINK.
  • Page 80 This item is not used with the DockLINK Selecting this item displays the S OFTWARE specify the file name for DockLINK software updates. See S on page 80 for more information about this selection. Page 72 10BaseT Port 10BaseT MAC...
  • Page 81 ONFIGURATION HANGES selection. This selection displays the S YSTEM operational characteristics of the DockLINK. S more information about this selection. This selection leads you to the B RIDGING enable Data Encryption and set the encryption key. See D on page 77 for more information about this selection.
  • Page 82: Configuration Manager Menu Items

    Page 74 Notes Allows you to set menu login names and passwords for access to menus. Enter from 1 to 12 letters or numbers. Enter from 1 to 12 letters or numbers. Allows you to set network addresses. © 1998 RadioLAN.
  • Page 83 Subnet Mask on page 27 Default Gateway IP Address on page 27 Page 75 Notes Identifies the DockLINK on a TCP/IP network. Each number can range from 0 to 255. For example, 250.142.15.200 Determines the subnet and IP Address for the DockLINK.
  • Page 84 PC to become a wireless station on a RadioLAN wireless network. If using the Dock mode, see Configuring the DockLINK for use in the Dock Mode on page 66. This selection displays the Bridging Parameters Menu. © 1998 RadioLAN.
  • Page 85 Menu Radio Port Parameters Menu ADIO ARAMETERS 890-010 12/04/98 Refer to: Securing the DockLINK with Data Encryption on page 31 Data Encryption Enabled Check Box on page 31 Encryption Key on page 31 on page 31 Setting up10BaseT Port Parameters on page 32...
  • Page 86 Choose Yes or No. This item leads to the E menu. ILTERS Choose Yes or No. Choose Yes or No. Choose Yes or No. Type the IP Address to filter Enter the subnet mask address for the network Node © 1998 RadioLAN.
  • Page 87 Refer to: Source/Dest on page 41 Accept on page 42 Adding MAC Filters on page 42 Managing Packet Flow through the DockLINK on page 40 Interrogating DockLINK for Performance Information on page Checking 10BaseT Port Statistics on page 45 Page 79...
  • Page 88 47 Checking 10BaseT Port Statistics on page 45 Checking Radio Port Statistics on page 47 Discovering Wireless Nodes Within the DockLINK’s Data Range on page 21 Upgrading System Software on page 50 Upgrading System Software on page 50 Page 80...
  • Page 89 Setting Changes on page 53 Save All Changes and Reset Radio Button on page 53 Page 81 Notes DockLINK does not use this feature. Allows you to enter the file name of the operating system file that you want to download.
  • Page 90 Reload Last Saved Configuration Radio Button on page 54 Reset Configuration to Factory Default Radio Button on page 54 Testing DockLINK Connectivity to the Wireless Network on page 56 Setting the Frames to Send on page 56 Setting the Frame Size on page...
  • Page 91 Information on page 59 Page 83 Notes Choose Start or Stop Indicates the total number of packets transmitted by the DockLINK to the stations during Ping testing Counts and stores the average number of retransmissions based upon the total number of packets transmitted...
  • Page 92 Viewing the System Log on page Page 84 Notes Displays the System Information menu, where you can collect version, contact, and other information about the DockLINK Displays the S . The YSTEM log stores and displays system events such as system start, warm start, or password authentication.
  • Page 93: Troubleshooting

    The DockLINK bridges traffic between the local station and the wireless network. The unit provides several indicators of its status and, with either a serial terminal or Web based access, a user may use the tools built into the DockLINK to further examine the network connection and help troubleshoot a problem report.
  • Page 94 If the problem persists and you have access to another radio, try replacing the radio. If this makes a difference, it is possible the radio may have become damaged, reducing its effectiveness. Contact your distributor for assistance. 890-010 12/04/98 Page 86 © 1998 RadioLAN.
  • Page 95: Glossary

    MIB. For example, the manager might instruct the agent to change the system date and time. Client Station A wireless 10Mbps computer that receives and originates Ethernet data. Client stations may exchange data directly and/or send to other hard-wired network devices by using an access point service. 890-010 12/04/98 Page 87 © 1998 RadioLAN.
  • Page 96 Internet by a specific extension attach to the location’s IP Address which is shared among all devices within the domain. Gateway A door in the Internet that allows a member of one domain to access another domain. (The domains have different IP Addresses.) 890-010 12/04/98 Page 88 © 1998 RadioLAN.
  • Page 97 MIBs and troubleshooting. Node Any device connected to a network. It is assigned either a MAC Address (IEEE 802 Standard network) or a DLC address (OSI Reference network). 890-010 12/04/98 Page 89 © 1998 RadioLAN.
  • Page 98 IP Address is a member. TCP/IP Transport Control Protocol/Internet Protocol or TCP/IP is the combination of protocols that are used on the Internet to transfer data from one address to another. 890-010 12/04/98 Page 90 © 1998 RadioLAN.
  • Page 99: Appendix A: Indicators, Switches, And Connectors

    The Activity LED (green) is active when receive activity is detected or during a packet transmission. Power LED The Power LED (green) is active when power is provided to the unit. Fault LED The Fault LED (amber) is active when a fault is detected during power up diagnostics. 890-010 12/04/98 Page 91 © 1998 RadioLAN.
  • Page 100: Mdi/Mdi-X Switch

    Generally, 10BaseT ports on an adapter card are configured as MDI, and 10BaseT ports on a repeater/hub are configured as MDI-X. The DockLink allows you to configure its 10BaseT port as an MDI (switch out position) or MDI-X (switch in position) port. The abbreviation MDI stands for Media Dependent Interface, and is specified by the IEEE 802.3i 10BaseT standard to be the electrical and mechanical interface to the UTP wire.
  • Page 101: Io Connectors

    Signal (MDI-X configuration) RX+ (Receive from UTP) RX- (Receive from UTP) TX+ (Transmit to UTP) No connection No connection TX- (Transmit to UTP) No connection No connection Page 93 8 7 6 5 4 3 2 1 © 1998 RadioLAN.
  • Page 102: Serial Port Connector

    Serial Port connector RadioLAN Part Number 910-011 is a Serial port interface is provided through a 4-pin shielded RJ-11 connector. The pin-out is described in the following table and figure: Signal Description Ground Serial Out (from computer) Serial In (to computer)
  • Page 103: Appendix B: Technical Specifications

    Appendix B: Technical Specifications Network Protocol 10 Mb/s Manchester encoded (IEEE 802.3 CSMA/CD) RadioLAN /10™ Pulse Modulated (CSMA/CA) Standards Support IEEE 802.3i Type 10BaseT Electrical Specifications Input Power: AC Line Frequency: Input Voltage: Volt Amperes Rating: 890-010 12/04/98 Domestic International...
  • Page 104: Physical Specifications

    Operating Temperature: 5 C to 40 C Storage Temperature: -25 C to 70C Operating Humidity: 85% max. relative humidity, non condensing Storage Humidity: 95% max. relative humidity, non condensing Operating Attitude: 10,000 ft (3,000m) maximum 890-010 12/04/98 Page 96 © 1998 RadioLAN.
  • Page 105: Electromagnetic Emissions

    FCC Part 15, subparts A and B, Class A EN55 022 (CISPR 22:1985), Class A General License VDE 0871, Class A (AmtsblVfg No. 243/1991 and Vfg 46/1992) VCCI Class 1 ITE Safety Agency Approvals UL-listed, ULC-listed, CSA-certified, TUV-licensed 890-010 12/04/98 Page 97 © 1998 RadioLAN.
  • Page 106: Getting Technical Support

    Getting Technical Support If you have technical questions, or have determined that your equipment is damaged, RadioLAN offers a number of ways to get assistance: 1. Contact your local RadioLAN reseller where you purchased the product. 2. See the RadioLAN Web Site for technical assistance: http://www.radiolan.com...
  • Page 107: Index

    · 95 antenna assembly · 10 assigning IP Address · 13, 15, 27 · 66 · 66 baud rates · 39 BBL · See DockLINK bridge · 21 browsers · 16 system requirements · 4 Page 99 © 1998 RadioLAN.
